Nordic - 3 Door 5 Drawer Wardrobe
Assembly Instructions - Please keep for future reference
Dimensions
Width : 120,9 cm
Depth : 49,0 cm
Height : 191,3 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
344112050
1517963
0845 640 30 30
- 20-11-2013
Advertisement
Related Manuals for Nordic 1517963
Summary of Contents for Nordic 1517963
- Page 1 Nordic - 3 Door 5 Drawer Wardrobe Assembly Instructions - Please keep for future reference 1517963 Dimensions Width : 120,9 cm Depth : 49,0 cm Height : 191,3 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline:...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Do not stand or put weight on components and tools listed on the product, this could cause pages 3 and 4. damage.
- Page 3 If you have damaged or missing components, call Components - Panels the Argos Customer Helpline: 0845 640 30 30 Please check you have all the panels listed below Bottom V155808 Foot 1179x470x15 mm P500004 90x50x50 mm V155857 1179x470x15 mm Plinth, back x2 P155855 1179x60x15 mm Side, Left...
- Page 4 If you have damaged or missing components, call Components - Fittings the Argos Customer Helpline: 0845 640 30 30 Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fix the drawer sides 12 to the drawer back 13 and 14 as shown, using screws R. Step 2 Knock down the dowels B into the holes indicated on the drawer sides 12, using a small hammer. Step 3 Slide the drawer bottom 15 and 16 into the...
- Page 6 Assembly Instructions Step 5 Push the drawer front 10 and 11 onto the the drawer sides 12 as shown. Push cams C into the holes indicated. Arrow pointing towards the front. Turn the cams C to the right to fix the front 10 and 11.
- Page 7 Assembly Instructions Step 8 Knock down the dowels A into the holes indicated on the back plinths 7, the back plinths 7-1, the top 5 and the bottom 6 using a small hammer. Screw the bolts C into the holes indicated on the top 5 and the bottom 6.
- Page 8 Assembly Instructions Step 10 Slide the top of the drawer runners S backwards. Fix the front end of the drawer runners S to the sides 1 and 2 using screws K into the holes indicated. See details. Step 11 Slide the top of the drawer runners S forwards.
- Page 9 Assembly Instructions Step 12 Slide the top of the drawer runners S backwards. Fix the front end of the drawer runners S to the dividers into the holes indicated 4 using screws K. See details. Slide the top of the drawer runners S forwards.
- Page 10 Assembly Instructions Step Place the dividers 4 onto the bottom 6. Push cams C into the holes indicated. Arrow pointing towards the bottom. Turn the cams C to the right to fix the dividers 4. Step Fix the plinth 7 and the plinth 7-1 onto the dividers 4 using screws Screw the bolts D into...
- Page 11 Assembly Instructions Step 17 Place the divider 4 onto the plinth 7 and the plinth 7-1. Push cams C into the holes indicated. Arrow pointing towards plinths 7 and 7-1. Turn the cams C to the right to fix the divider 4. Step 18 Place the sides 1 and 2 onto the top 5, the...
- Page 12 Assembly Instructions Step 19 Place the backs 21 into the rebates in the sides 1 and 2, the top 5 and into the H-profile 18. Important! Make sure the angle between the top and the sides is 90 when the back is attached Fix the backs 21 to the top 5, the sides 1 and 2,...
- Page 13 Assembly Instructions Step 21 Place the top rail 9 onto the top 5. Fix the top rail to the top using angles W and screws T. Step 22 Warning! The wardrobe is heavy. Lift with care. Its is recommended that the wardrobe is fixed to the wall.
- Page 14 Assembly Instructions Step 23 Place the cup hinges Q into the holes indicated on the doors 19 and 20. Fix the hinges using screws T. Place the magnet catches N into the holes indicated on the doors using a small hammer.
- Page 15 Assembly Instructions Step 24 Fx the supports for hanger-rails L onto the holes indicated on the sides 1 and 2 and on both sides of the divider 3 using screws T. Step 25 Place the hanger rail 22 and 23 into the supports To fix the doors 19 and 20, slide the cup hinges Q onto the crossplates P.
- Page 16 Assembly Instructions Step 26 Adjusting the doors left/right. To adjust the door towards the left hand side - turn the adjusting screw to the right. To adjust the door towards the right hand side - turn the adjusting screw to the left. Adjusting the doors forwards/backwards.
