SHELTER SLRK Instruction Sheet

INSTRUCTION SHEET FOR MODEL SLRK
TOOLS REQUIRED: Screw Driver or Power Screw Driver
STEP 1: Determine desired length and height of your Log Rack. Cut four (4) 2 x 4's to the desired height to be-
come the four (4) verti cal supports. Cut two (2) additional 2 x 4's to the desired length to become the bottom
horizontal supports.
STEP 2: Carefully remove all contents from the package. The package will contain two (2) End Brackets and a
package of twenty (20) screws.
STEP 3: Place the End Brackets on the ground with the opening of the "U" shapes facing each other. The dis-
tance between them should be approximately the length of the 2 x 4's that are the bottom supports.
STEP 4: Insert a vertical support 2 x 4 into the inside corner in one of the End Brackets. While holding the 2 x 4
vertical, insert two (2) screws through the predrilled holes in the End Bracket and tighten to firm up the 2 x 4.
Insert two (2) screws into the predrilled holes on the backside of the End Bracket and tighten.
STEP 5: n the same corner which you have installed the vertical 2 x 4, insert a horizontal 2 x 4 support and butt
it to the vertical 2 x 4. Insert one (1) screw into the predrilled hole on the side of the End Bracket and tighten to
the horizontal support.
STEP 6: Repeat STEP 5 on the opposite side of the End Bracket you are working on, and then repeat STEP 4 and
5 on both corners of the other End Bracket.
End Bracket
HY-C Company, LLC • Saint Louis, MO 63132
For at look at HY-C's complete catalog of chimney and fireplace accessories, visit us at www.hyccompany.com.
Model SLRK
(screws included)
Four 2 x 4 Vertical
Supports (not included)
Two 2 x 4 Horizontal
Supports (not included)
(Optional)
Diagonal support shown are not necessary on most applications.
For additional support and stability you may add
Four 2X4 diagonal corner supports.
End Bracket
SLRKI
Revised 1-25-2013
