Kojack® Leveller – Introduction:
The Kojack® Leveller is made from high strength tubular steel and designed to raise one
wheel off the ground to level a vehicle.
The Kojack® Leveller has a load capacity of 680kg and is suitable for most wheel and tyre
combinations. It is suitable for levelling most Caravans, Camper Trailers, Tent Trailers, Boat
Trailers and General Purpose Trailers.
Kojack® Leveller – Schematic Diagram 1:
More information https://www.caravansplus.com.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Purpleline Kojack
- Page 1 The Kojack® Leveller is made from high strength tubular steel and designed to raise one wheel off the ground to level a vehicle. The Kojack® Leveller has a load capacity of 680kg and is suitable for most wheel and tyre combinations. It is suitable for levelling most Caravans, Camper Trailers, Tent Trailers, Boat Trailers and General Purpose Trailers.
- Page 2 Kojack® Leveller – Table of Components: Item No Diagram Description 40L-B Bolt 40L-N Nut – 13mm 40L-W Washer 40L-R Rod Threaded 40L-P Pivot 40L-LA Arm - Left 40L-RA Arm - Right 40L-CAU Centre Arm - Upper 40L-CAL Centre Arm - Lower Kojack®...
- Page 3 Once all assembled tighten each nut with a 13mm spanner and 5MM Allen-Key. 13. The Kojack® Leveller is now ready to operate. Kojack® Leveller – Operating Instructions: CAUTION: Use the Kojack® Leveller on a firm surface to prevent it sinking. Where the surface is less than firm place Kojack®...
- Page 4 Photographs used are for illustration purposes only and may differ for the product. Purple Line reserves the right to alter product specifications without prior notice. Kojack® Leveller – Warranty Policy: Kojack® Leveller (Goods) is guaranteed for 12 months from date of purchase and subject to Australian Consumer Law.
