Avani Natural Fold Installation Instructions

Inside or Ceiling Mount & Valance (cont'd)
Step 4: Install the track underneath the valance.
NOW tighten the screws to secure the track.
Tighten Screw
IM INSTALL IS NOW COMPLETE.
Inside or Celing Mount Without Valance
Follow steps 2 through 4 for Inside Mount
with valance, mounting your IM bracket into the
top of the window/soffit or ceiling.
IM INSTALL IS NOW COMPLETE.
End Stop Installation (Optional)
Your Avani Natural Fold™ is designed to open
both ways. IF one way only operation is
preferred follow the steps below:
Step 1: When sliding the round
carrier wheels into the track,
slide an End Stop between the
first and second carrier wheel.
Step 2: Slide the first carrier and the End Stop all
the way to the end of the track and then tighten
the end stop in place so that the first carrier
wheel does not slide.
Splicers can be used with ceiling or wall mount
applications and with all types of brackets.
Prepare the two pieces of track, snap the splice
onto one half then snap the
other half into place (tip: place
track face up, so you can use
your body weight to snap the
track in place). Make sure that
there are brackets close to the
splice (2"- 4" on each side).
This splice is NOT a bracket.
Note: The hole in the splice is
not for ceiling mount. It was used
during the powder coating process.
WindowFashionsofAmerica.com warrants
that our products when properly installed in a
residential dwelling will be free from defects
in materials and workmanship for as long as
the original purchaser owns the product. All
fabric colors tend to lose their original
intensity over time, and pull cords eventually
wear out. This is considered normal wear and
tear and is not covered by this warranty.
Abuse and misuse are not covered. Color lots
vary and may not exactly mach a previously
ordered product. Repair is the purchaser's
End Stop
sole remedy under this guarantee. This
warranty does not cover incidental or
consequential damages, installation or
service calls.
Care and Cleaning
Splicing Rails (Optional)
Splicer
Warranty
Installation Instructions for
Avani Natural Fold
Congratulations on
the purchase of your new
Avani Natural Fold
