Sealey VS907 Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Warning!
instructions laser Beam
1. SAFETy
1.1. GENERAL SAFETy
WARNING! ensure that Health & Safety, local authority and general workshop practice regulations are adhered to when using this
‰
equipment.
WARNING! DO NOT aim the laser beams at your or another person's or animal's eye and beware of reflections from mirrors or other
‰
shiny surfaces.
Familiarise yourself with the applications, limitations, and potential hazards of the thermometer.
9
Keep the thermometer clean and in good condition.
9
Protect the thermometer from the following:
9
electro-magnetic fields from engine components, arc welders and induction heaters closer than 125mm.
Static electricity.
Thermal shock caused by large and/or rapid ambient temperature change.
High temperatures.
DO NOT get the thermometer wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT take readings through transparent materials such as glass or clear plastic. The surface temperature of these materials will be
8
measured.
DO NOT use the thermometer in areas where there is steam, dust or smoke. These conditions will result in erroneous readings.
8
DO NOT use the thermometer for any purpose other than that for which it is designed.
8
DO NOT allow untrained persons (particularly children) to operate the thermometer.
8
DO NOT operate the thermometer when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
1.2. LASER SAFETy
The VS907 utilises a Class II laser that emits low levels of visible radiation (i.e. wavelengths between 400 and 700
nanometres) which are safe for the skin but not inherently safe for the eyes. The Class II emission limit is set at the
maximum level for which eye protection is normally afforded by natural aversion responses to bright light. Accidental eye
exposure is therefore normally safe, although the natural aversion response can be overridden by deliberately staring into
the beam, and can also be influenced by the use of alcohol or drugs.
WARNING! DO NOT look or stare into the laser beam as permanent eye damage could result.
‰
Be aware that reflections of the laser beam from mirrors or other shiny surfaces can be as hazardous as direct eye exposure.
9
2. INTRODuCTION
High resolution laser thermometer that detects energy emission in the infrared spectrum and converts
reading into a display of temperature. Features laser pointer, Maximum/Minimum/Average/difference
readings, data storage and data hold function, high/low alarm setup, auto power off. Temperature is
displayed on a large 29mm lCd panel with back-lit display for use in low light areas. Temperature can be
shown in either °C or °F. Powered by 9V cell (supplied). Storage case included.
3. SpECIFICATION
Temperature Range ..................................................... -50°C to +700°C (-58°F to +1292°F)
Accuracy(0°C to +550°C) ...................................... +/-1.5°C or +/-1.5°C whchever is greater
(-50°C to 0°C) ............................................................................................................+/- 3°C
Response Time ...................................................................................................... 500mSec
Focal Range................................................................................................................... 12:1
operating Temperature ..............................................................
Storage Temperature ................................................................
4. SET up
4.1. INSTALLING/CHANGING BATTERy (FIG.2)
4.1.1. on either side of the trigger, where the handle moulding meets the main body there are two very
shallow recesses. Place thumb and finger into these recesses and pull the front section of the handle
forward and down to reveal the battery compartment.
© Jack Sealey limited
INFRARED LASER THERMOMETER 12:1
VS907
Model no:
0°C to +40°C (+32°F to +104°F)
-20°C to +60°C (-4°F to +140°F)
Original Language Version
fig.1
VS907 Issue 3 (HF) 05/10/18
