A
技术要求 ：
B
1.
2.该用户手 册 里 的彩色图片 也 按 黑白色制 作
3.
4.如果供应 商 的 排版需要加 空 白 页，请加 在 最 后
5.本说明书 参 考 的电控洗涤 时 序 表版本号 为 ：
C
处数 分区
标记
分 区
D
编 制
审 核
许 平平
审 定
邹京津
批 准
熊好平
1
1
所有印刷 颜 色 均为黑色
纸张规格 为
A4
DKGF-SX201-2014b A2平台美洲 高 内 胆 （区域洗 ）
洗 涤时序 （2 0 1 5能 源之星）
签 名
更改文件号
校对
刘冬慧 杨明检
,
性能
马松武
排版
日期
2018.1.3
:PANTONE BLACK C
WQP12-6502
用户手册
(MIDEA)( 标准版 )
日 期
阶 段 标 记
REV. C
数
量
重
1
共
张
第
1
2
比 例
80G双胶
1:1
量
佛山市顺德区美的
张
洗涤电器制造有限公司
1
2
A
B
C
D
D
Advertisement
Table of Contents
Related Manuals for Sunpentown SD-6502SS
Summary of Contents for Sunpentown SD-6502SS
- Page 1 技术要求 ： 所有印刷 颜 色 均为黑色 :PANTONE BLACK C 2.该用户手 册 里 的彩色图片 也 按 黑白色制 作 纸张规格 为 4.如果供应 商 的 排版需要加 空 白 页，请加 在 最 后 5.本说明书 参 考 的电控洗涤 时 序 表版本号 为 ： DKGF-SX201-2014b A2平台美洲 高 内 胆 （区域洗 ） 洗...
-
Page 2: Table Of Contents
Dishwasher Use & Care Manual Dishwasher Use & Care Manual SD-6502SS & SD-6502W Table of Contents Important Safety Instructions-----------------------2 Features of your new dishwasher--------------3-5 Operating Instructions-----------------------------6-8 Preparing and loading dishes------------------9-14 Care & cleaning----------------------------------15-17 Troubleshooting----------------------------------18-19... -
Page 3: Important Safety Instructions
Important safety instruction For your safety, please follow the information in this manual to minimize WARNING the risk of fire, explosion, electric shock, and to help prevent property damage or personal injury. Proper installation Please install your dishwasher properly, follow the installation guide. Water supply inlet temperature should be between 120℉... -
Page 4: Features Of Your New Dishwasher
Features of your new dishwasher Specification Capacity 14 place settings Dimension 23.89 x 25.6 x 33.74 inches W x D H Power Supply 1 2 0 v o lts , 6 0 H z Rated power usage Wash motor 50 W Heater 840 W Water Feed Pressure 20 ~ 120 psi (138 ~ 828kPa) Top light... -
Page 5: Filter System
Features of your new dishwasher Features Filter System Adjustable Upper Rack Your dishwasher has a multiple Filter The Upper Rack can be raised or lowered to accommodate loading taller dishes in either System. In the System there are four rack. The Upper Rack clearance height H1 filter-meshes. - Page 6 Features of your new dishwasher How your dishwasher cleans Getting Started Your dishwasher cleans by spraying a 1.Load dishwasher (See preparing and loading mixture of hot water and detergent through dishes). the spray arms against soiled surfaces. 2.Add detergent (See Fill detergent to the dispenser).
-
Page 7: Operating Instructions
Control panel HEAVY DELICATE WASH WASH Steam wash NOTE For use with heavily soiled items, this STEAM option adds 30 minutes t o the This model is built-in models, all the buttons can only be operated in the cycle time. The option is available with open state. - Page 8 Operating dishwasher Start/Cancel Delay Open the door , select a wash cycle you To delay the start of a selected cycle, open the desired, the indicator light will turn on. Press door, press the Delay Start pad until the desired the Start/Cancel button and close the door delay time shows in the LED display screen, it within 4 seconds, then the selected program...
-
Page 9: Status Window
Operating dishwasher Status Window Error indication H:01-H:24 If the Delay Start option is selected, the In certain situations which are critical to the number of delay start hours shows in the machines function and safe operation, the Status Window. control shall shut down and indicate an error code (See Error Codes on page 18). -
Page 10: Preparing And Loading Dishes
Preparing and loading dishes Adjustable Upper Rack The upper rack height can be easily adjusted to accommodate loading taller dishes in either rack. To accommodate taller dishes in the bottom rack, there are 2 positions available: 1. Lift the rack for upper position Upper rack The upper rack in the upper position Lower rack... -
Page 11: Loading The Upper Rack
Preparing and loading dishes Loading the Upper Rack Loading the Bottom Rack The upper rack is designed for cups, glasses, The bottom rack is designed to load plates, soup small plates, bowls and plastic items marked bowls, plates, saucers and cookware. The safe etc. -
Page 12: Loading The Top Rack
PREPARING AND LOADING DISHES Adjusting the top rack This dishwasher has a convenient top rack for silverware, cutlery, and small items. This rack can be adjusted to accommodate varying loads, as shown below. Left and right racks aligned Left rack adjusted to lower position and right rack angled Left rack adjusted to lower position and right rack to upper position Left rack adjusted to lower position and right rack moved to the left Left rack adjusted to lower position and right rack removed... -
Page 13: Loading The Silverware Basket
Preparing and loading dishes Loading the Silverware Basket Adding A Dish The silverware basket could be divided into To add or remove items after wash cycle starts: three separate modules that can be used in 1. Open door slightly and wait a few seconds both upper and lower racks. -
Page 14: Filling The Detergent Dispenser
Preparing and loading dishes Filling the rinse aid dispenser Your dishwasher is designed to use a liquid rinse aid. The use of rinse aid greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month, try to keep it full,but do not over fill. - Page 15 Preparing and loading dishes 3. Close the dispenser cover.
-
Page 16: Care & Cleaning
Care & cleaning Cleaning the exterior door and panel 1. Stainless steel panel 2.Control panel Clean the stainless steel door and handle Clean the control panel with a lightly dampened regularly to remove the debris with cleaning cloth, clean it gently. soft cloth. -
Page 17: Clean The Fine Filter
Care & cleaning Clean the Fine Filter Take out the Cylinder Filter and remove the Fine Filter from the dishwasher tub bottom. To remove the Fine Filter you must first remove the bottom spray arm as shown below. Flush the Fine Filter by holding it under running water and replace. - Page 18 Care & cleaning Clean the door gasket Air gap Clean the door gasket with a damp cloth to If there is an air gap installed with your remove food particles regularly. dishwasher, make sure it is clean so the dishwasher will drain properly. Air gap is not part of your dishwasher.
-
Page 19: Troubleshooting
Troubleshooting Before calling for service Solution Problem Po ibl ss e cause Shut the door completely make sure it is Door may not be closed properly Power supply or power line is not connected latched Check and connect the power supply Dishwasher won't start Delay Start option has been selected Refer in this manual to rese... - Page 20 Troubleshooting Solution Problem Possible cause Detergent dispenser Add the detergent and rinse aid as Improper operation of the detergent cover will not shut indicated by the manual Water remains in the Previous cycle has not finished or has been Select the proper cycle as introduced by interrupted the manual dishwasher...
- Page 21 INSTALLATION INSTRUCTIONS Read the installation instructions clearly, and futher more, pay attention to the following lists: 1. The power-supply receptacle for the appliance shall be installed in a cabinet or on a wall adjacent to the undercounter space in which the appliance is to be installed. 2.
- Page 22 This guarantee is subject to the following terms: Sunpentown must be notified of the fault. Proof of purchase must be presented to Sunpentown’s nominated representative. The warranty will be void if the product is modified, misused or repaired by an unauthorized person. ...
