Summary of Contents for Manhattan T3-R
-
Page 1: Get Started
GET STARTED For assistance, Check Freeview HD coverage call us on 020 8450 0005 in your area by visiting or visit manhattan-tv.com/support freeview.co.uk For assistance, Check Freeview HD call us on 020 8450 0005 coverage in your area by or visit manhattan-tv.com/help... - Page 2 INSTALLING YOUR T3•R Unpack the following from your Giftbox: 2x AAA batteries Remote control Manhattan T3•R HDMI cable Power adapter You Need • A TV with an HDMI input. • A TV aerial and cable. While some indoor (portable) aerials may pick up Freeview channels, for best results use a rooftop aerial.
- Page 3 • Turn on the wall socket you connected your T3•R to and the T3•R will switch on. • Turn on your TV set and choose the HDMI input you connected your Manhattan T3•R to. Most TV remotes use a button labelled ‘AV’, ‘SOURCE’, ‘INPUT’ or , with each press cycling through the TV’s inputs.
-
Page 4: How To Use Menus
BASICS The T3•R makes it easy to watch and record TV as well as access on demand programmes and apps. Home The Home screen shows all the menus and apps on your T3•R. Press HOME on your remote control at any time to go there. An internet connection is required for apps, catch-up from the TV Guide and to use the Featured, Watchlist and Search menus. - Page 5 WATCHING TV The Channel Browser While watching TV, press OK to display the Channel Browser, then use the directional pad to browse what’s on. Favourite channels can be quickly browsed by pressing to cycle through them. See page 17 for details of how to add and remove them. •...
- Page 6 TV GUIDE Press GUIDE or select ‘TV GUIDE’ from the Home screen to browse what’s on over the next seven days and (for supported channels and programmes) catch up with the last seven days: • Press OK to watch a programme on now or add a reminder for a programme on later. For on demand programmes pressing OK gives you the choice to play it or add it to your Watchlist.
-
Page 7: Programme Info
PROGRAMME INFO Press INFO when watching TV to display detailed information about the programme you’re watching. You can also press INFO to view detailed information for a programme whenever you see next to its name or description. Icons Part of a series Subtitles On Demand Audio Description... -
Page 8: Live Pause
LIVE PAUSE The T3•R is always recording the channel you’re watching and will store (‘buffer’) up to the last 2 hours. When you change channel, what had previously been recorded is cleared and recording starts again. There are many ways to take advantage of Live Pause: •... - Page 9 RECORDINGS Press RECORDINGS or select ‘RECORDINGS’ from the Home screen to display a list of all your recordings. Use UP/DOWN to browse the list and LEFT/RIGHT to select a section: • SCHEDULE – Your planned recordings and reminders • SERIES – Recordings that are part of a series •...
- Page 10 FEATURED Press FEATURED or select ‘FEATURED’ from the Home screen to browse top picks from all the UK’s on demand players, neatly organised by genres such as Comedy, Movies and Sport. To play a programme or add it to your Watchlist, press OK and select the option. Further information about the programme is also shown including when the programme will expire and no longer be available.
- Page 11 SEARCH Press SEARCH or select ‘SEARCH’ from the Home screen to find programmes from all the UK’s on demand players. Use the on-screen keyboard to enter a programme’s name and as you type the T3•R will suggest what you’re looking for. Select a suggestion or your search term to display the results.
- Page 12 WATCHLIST The Watchlist lets you save on demand programmes to watch later (see page 4, ‘How to Use Menus’). Programmes can be watched at any time until they expire – this varies from programme to programme and is shown when a programme is highlighted. To browse your Watchlist, select ‘WATCHLIST’...
- Page 13 REMINDERS When an upcoming programme is highlighted in the TV Guide or the Channel Browser, press OK to add a reminder. To cancel it, press OK again. Reminders are displayed just before a programme is scheduled to start. The T3•R has a setting called ‘Reminder Auto Watch’...
-
Page 14: Picture And Sound
SETTINGS You can view and change your T3•R’s settings by pressing HOME and selecting the button located at the top right of the screen. Picture & Sound Resolution The T3•R supports resolutions up to 4K ‘Ultra HD’ (3840 x 2160 pixels or 2160p), which is four times the resolution of ‘Full HD’... -
Page 15: Menu Transparency
Models vary, check the manual for ‘HDMI ULTRA DEEP COLOR’ and turn on. Menu Transparency Adjusts the transparency of Manhattan menus and how clearly TV can be seen underneath. The default is ‘Light’ but if you prefer you can set it to ‘Dark’ or off completely. -
Page 16: Recording And Playback
SETTINGS (CONT’D) This normally works well but there can be issues when a TV doesn’t correctly identify its capabilities. Issues can also occur when using other devices in the chain such as an AV Receiver, Sound Bar or HDMI splitter. If necessary you can manually change the mode: Surround: Passes through and outputs surround sound when available and stereo when not. -
Page 17: Edit Favourites
Format Hard Drive Wipes the Hard Drive and erases all recorded programmes. Requires your PIN. Channels Edit Favourites Add or remove channels on your favourites list. Favourites can be quickly browsed in the Channel Browser (see page 5) and used to filter the TV Guide (see page 6). Protected Channels Select ‘Protected Channels’... - Page 18 SETTINGS (CONT’D) System Standby Options Auto Standby → The T3•R will automatically go into standby if no buttons are pressed for 3 hours. The length of Auto Standby can be changed or it can be disabled altogether. Standby Options Standby Mode →...
-
Page 19: Software Updates
Software Updates The T3 will automatically check for an update each night using its internet connection and install one if it’s available. This can be disabled by turning ‘Automatic Updates’ to off. To check for an update straight away, select ‘Check for Update Now’. If you can’t connect your T3 to the internet, updates can be installed using a USB stick by following the instructions on our website. -
Page 20: Your Remote
YOUR REMOTE Show the Recordings menu Standby on/off Pause live TV/playback Swap to the last channel viewed Show the Settings menu Fast Forward Rewind Skip forward 24 hours in Guide Skip back 24 hours in Guide Stop playback or live pause Set recordings &... -
Page 21: Control Your Tv
T3•R will always be lower than it should be. • Some TV’s use non-standard remote signals and may not be supported. Program your Manhattan Remote To start, lay the T3•R and TV remotes flat on a table facing each other 2cm apart. -
Page 22: Troubleshooting
Check the HDMI connections between the sound and the T3•R’s disconnected. T3•R and your TV. menus can’t be seen The input the Manhattan T3•R Select the correct HDMI input (see your TV’s is connected to may not be manual for guidance). selected on your TV. - Page 23 PROBLEM POSSIBLE CAUSE WHAT TO DO Video in apps Your broadband is not fast Check your broadband speed with your buffers, stutters or enough. A minimum speed internet provider and try running an online stops altogether of 3Mbps is recommended speedtest on a computer or mobile device.
- Page 24 The details in this guide are correct at the time of going to print and are for guidance only. Product features outlined are subject to change at any time without notice. © 2019 Manhattan TV Limited. Manhattan is a registered trademark of Manhattan TV Limited; registered company no. 2247629. The...
Need help?
Do you have a question about the T3-R and is the answer not in the manual?
Questions and answers
Initial scan for channels failed how do I rescan?
To rescan channels on the Manhattan T3-R, go to the Retune option in the settings. You have two choices:
1. Smart Retune – This keeps your favourites, protected channels, scheduled recordings, reminders, and regional selection.
2. Full Retune – This clears all settings and is necessary if you have moved to a new address.
Both options will restore any deleted channels. You can also use Manual Tune to scan a specific UHF channel, which is quicker than a full or smart retune.
This answer is automatically generated
