Installation Instructions: RADIO-900M
Installation: RADIO-900M
Part Number:
P01-04941
1. Purpose
This instruction sheet describes the procedure to install a RADIO-900M into an IPC-8000,
HPSA-8100 Series, or ACU-8411. Additionally, this instruction sheet provides
specifications and guidelines for the RADIO-900M approved antennas.

2. Cautions and Warnings

The following are specific Cautions and Warnings that must be followed when installing or
operating equipment.

Please read all instructions before attempting to install any equipment. Failure to
follow directions can cause bodily injury and/or damage to the equipment.

Ensure that precautionary measures are employed to prevent applying power to
equipment at any time maintenance work is in progress.

Do not make any unauthorized alterations to equipment or components. Changes or
modifications not expressly approved by Cooper Notification can result in damage
to the equipment and will void the warranty.

When working near electricity do not use metal rules, flashlights, metallic pencils, or
any other object having exposed conducting material.

Ensure all electrical connections are secure before applying power to a unit. Failure
to secure connections may cause an electrical arc resulting in physical shock or
damage to the equipment.

Do not touch electronic components.

When possible, avoid installing equipment during severe or wet conditions.
Handling equipment with wet hands may cause slippage resulting in bodily injury
and/or damage to equipment.

Comply with all electrical codes per the local authority having jurisdiction.
3. Introduction
The RADIO-900M provides wireless communications for Mass Notification. The Wireless
Ethernet Radio provides a wired-to-wireless communication bridge between Mass
Notification units when it is not feasible to physically wire into a facility's network.
The RADIO-900M drives audible, visual and data devices via the 900 MHz ISM band using
Direct Sequence Spread Spectrum (DSSS). When used with a Cooper Notification approved
compatible antenna, communication is available for line of site distances of up to 6 miles.
A site survey must always be conducted by a qualified, factory trained
technician prior to determining the radio and antenna locations.
Installation Instructions: RADIO-900M
P/N P01-04941 Rev-A
1
