VH5C Collet Air Valve
Fadal
VH5C Three Position Collet Air Valve
Lever in Horizontal or Neutral position.
Remove and adjust Collet.
Lever in Down position.
Loosen Collet—Relieves the tension on Collet allowing
removal of part.
Lever in Up position.
Tighten Collet—Holds work in position.
See back of sheet for additional information.
August 2001
VH5C Three Position Collet Air Valve
1
Advertisement
Table of Contents
Summary of Contents for FADAL VH5C
- Page 1 VH5C Collet Air Valve Fadal VH5C Three Position Collet Air Valve Lever in Horizontal or Neutral position. Remove and adjust Collet. Lever in Down position. Loosen Collet—Relieves the tension on Collet allowing removal of part. Lever in Up position. Tighten Collet—Holds work in position.
- Page 2 All new VH5Cs being shipped will have these modifications to the Collet Closer system. In addition, units returned for service to the Collet Closer System will be updated upon request. Installation of a VH5C unit with these modifications is similar to previous procedures: 1) Connect fittings as show below in the diagram.
