Summary of Contents for Zeny WED-B250B-4
- Page 1 Meat Slicer Series Users’ Manual Model:WED-B250B-4...
- Page 2 Honorific customer: Please cautiously read usage manual before use my plant product. Moreover and specially notice: The first: In the manual of whet knife and regulation, particularly notice the method that the front whets knife: Wanting to slightly press to fix the knife emery wheel hand handle about a second can immediately, the most long can't over 2 seconds, the hair of razor blade stabs to throw away then, otherwise the razor blade will change bluntness.
-
Page 3: Table Of Contents
This users’ manual provides this product’s detailed information of how to use, install, maintain and repair it for customers, ensuring that this product can be used in the best and most effective way. Please keep the users’ manual well and make sure that when you need to read it, you can find it out soon. -
Page 4: Main Technology Parameter And Packing List
1. Technology parameter Characters: Fully automatic Cut-off journey: 185 mm Slice Thickness: Blade Diameter: 0-13 mm Φ250 mm 110V/ 60Hz Rated Voltage: Power: 240W 220V/ 50Hz Net Weight: Gross Weight: 14kg 16kg Product Size: 470×420×390mm Carton Size: 520×375×460mm 2. Framework diagram for the Product A. -
Page 5: Before Starting The Examination And Preparation
2). It is easy and convenient to use and operate it. 3). It is convenient to adjust the thickness of the meat slices. The meat slices cut by this product are very nice. 4). the structure of this product is concise. It is convenient to grind the slicing knife. And it is easy to be repaired and maintained. -
Page 6: Clean And Maintain
adjusting button to " 0 " position. 2). Put the meat or other food onto the food carrier (at the degree about –5℃, the best nail pressure meat indentation is appropriate), and then use the movable food pressing board to press the food and push the food towards the food stopping board. - Page 7 ③ Strictly prohibit to clean the slicing knife before cutting off the electric power. 6). When finished cleaning, start the machine and let it run for 3 minutes cutting nothing, make sure that it could work normally. B. To make sure this product could work long enough, you must maintain it termly: 1).
-
Page 8: Sharpening The Matters Needing Attention
agilely or not. ③ Each time before and after grinding the knife, clean the grinding wheel. 7. Sharpening the matters needing attention: To ensure that the service life of the microtome, must be timed regular maintenance on the machine: 1). Cut off the electric power and clean the slicing knife. 2). -
Page 9: Notice And Safety Rules
of the grinding wheel. 11). The grinding wheel would be dusty and smeary when it has been used for several time, please use detergent and brush to wipe them off, so that next time you can use it again. 12). clean the product again. 8. - Page 10 Prohibit standing at the direction that the slicing knife is running toward. ※ The slicing knife may not run because the knife supporting pan was locked or there was something wrong with this product. In that case, please cut off the electric power first, and then repair and maintain it.
-
Page 11: Malfunction And Maintenance
9. Malfunction and maintenance Possible malfunctions and maintenance methods malfunction malfunction analysis Maintenance methods A. the fixing screws of the frame and A. correct positions of the frame and the Food carrier Shakes the food carrier become loose food carrier, tighten the screws fixing plastic nail of the sliding B. - Page 12 C. the slicing knife is deformed C. change the slicing knife D. the locking ring of the strap wheel D. tighten the locking ring or change the has become loose or has been strap wheel damaged food stopping A. the distance between the food A.
-
Page 13: Breakdown Drawing
C. the copper set was damaged or C. change the copper set was not in its right position 10. Breakdown drawing... -
Page 14: Fittings List
11. Components list... - Page 15 Components list 1 whole frame 26 adjusting sliding board 2 scraping meat plate 27 the copper set screws M6×18 3 pan head screws with cross recessed 28 copper set 1215 M6×10 29 compression spring 4 the copper pan head screws with cross 30 guiding axle of the sliding part recessed M5×16 φ14×371...
- Page 16 51 cross recessed countersunk head 77 main axle of the slicing knife screw M6×16 78 belt pulley of razor blade 52 food carrier 195×192 79 poly V-belt 370 53 protecting cover of the food carrier 80 ball bearing 6004-2RS 54 slotted countersunk head screws 81 hole elastic φ42 M6×25 82 axle elastic φ20...
-
Page 17: Electrical Circuit Diagram
grinding parts 107 hexagonal screw M6×50 103 pan head screws with cross recessed 108 motor 240W M5×25 109 electric capacitor 7μF 104 adjusting handle of the frame of the 110 hexagon socket cap screws M6×25 grinding parts 111 connecting cushion of the motor 105 wing nuts M8 12. -
Page 18: The Poly V-Belt Adjust
The poly V-belt adjust When the poly V-belt has got loose, first and upward loosen the M6 nut A, then adjust the M6 nut B upwards, until the elasticity of the poly V-belt adjust to be suitable; If the poly V-belt is too tightly, the adjustment then is contrary. hexagonal screw M6 M6 nut A M6 nut B... - Page 19 EC Standard; accord with relative regulations. Please kindly forgive us that we will not make a notice in addition once we have made some changes to this users' manual Product quality guarantee Product Name WED-B250B-4 series meat slicer Customer's Address Customer's Name Tel: Purchase Date...
