Special Page Function 5: MIDI Channel Select
This function sets the MIDI channel on which the SansAmp PSA receives MIDI
data. It can be set to Omni (receive on any or all channels), or specific channels 1
through 16. Push the Save button, and the display shows the current setting. Press
the Up or Down buttons to select either Omni (the default value, indicated by a
small "o" in the right digit), or any number between 1 and 16. Push Save to store
your selection.The display will then flash 00 to indicate you're still in the Special
Page menu.You may now choose either a new Special Page function, or press
Save again to exit. If you don't make a choice in about 15 seconds, the display
stops blinking, indicating the SansAmp PSA is in Bypass Program 00.
Digits Push Current Select "o"
Blink the Setting
Save "Omni"
is
Switch
Shown
Channel
Special Page Function 6: Software Revision Number
This function tells you which version of software is in your SansAmp PSA.You
cannot alter this, but the information may come in handy in the future if soft-
ware upgrades become available.When you select Special Page Function 6, the
display will show a two-digit number.After showing you the software version,
the display will flash 00 to indicate you're back in the Special Page menu.You
may now choose either a new Special Page function, or press Save again to exit.
If you don't make a choice in about 15 seconds, the display stops blinking, indi-
cating the SansAmp PSA is in Program 00, bypass.
Digits Push Display
Blink the Shows
Save
Soft-
Switch
ware
Version
Display Digits
Push
Flashes 00
for the
Upon Blinking
Save
Return to
or Switch
Special Return
Again
Page
1-16
Function Program
Automati-
cally exits
to Special
Display
Page Menu
Flashes 00
after 15
Upon Blinking
seconds
Return to
or when
Special Return
the Save
Page
Switch is
Function Program
pushed
13
Special Page Function 7: Edit Pot Display Mode
For finding presets, you can change how the information is displayed for a
stored pot's position.You can choose to use digits, dashes or the numerical
value of the pot. When you select Function 7, the display will show either 00,
01 or 02.
00: Digits (as shipped)
01: Dashes
02: Numerical Value (0-127)
Digits Push
Current
Blink the
Stop
Save
Switch
Upon
to
00
To change the setting, use the Up and Down buttons to select 00, 01, or 02.
Then push Save to store your selection.The display will then show a flashing 00
to indicate you're back in the Special Page menu.You may now choose either a
new Special Page function, or press Save again to exit. If you don't make a
choice in about 15 seconds, the display stops blinking, indicating that the
SansAmp PSA is in Program 00, bypass.
Special Page Function 8: Disengage All Pots
This function renders all eight front panel potentiometers inactive.This ad-
vanced feature prevents accidental setting changes during performances.All
presets remain in the memory and are accessible via MIDI, however, you cannot
edit the programs while in this mode. Select function 08 and press Save.
Digits
Stop
Digits Push
Upon
Blink the
Save
to
Switch
00
Use the Up and Down buttons to select between two options:
00: All pots engaged (normal operation, as shipped)
01: All pots disengaged
Then push Save to store your selection.The display will then flash 00 to indi-
cate you're back in the Special Page menu.You may now choose either a new
Special Page function, or press Save again to exit. If you don't make a choice in
about 15 seconds, the display stops blinking, indicating that the SansAmp PSA is
in Program 00, bypass.
Special Page Function 9: Reserved for Future Use
Select 00, Push
01 or 02 the
Setting
is for Display Save
Mode Switch
Shown
Desired Again
Select 00 Push
or 01 for the
Desired Save
Mode Switch
Again
14
Display Digits
Flashes 00 Stop
Upon Blinking
Return to Upon
Special Return
Page to
Function Program
00
Display Digits
Flashes 00 Stop
Upon Blinking
Return to Upon
Special Return
Page to
Function Program
00
