Summary of Contents for Cab Technology PX Series
- Page 1 Service Manual Print Module Made in Germany...
- Page 2 Deliveries and performances are effected under the General conditions of sale of cab. Germany Taiwan China cab Produkttechnik GmbH & Co KG cab Technology, Inc. cab Technology Co., Ltd. cab (Shanghai) Trading Co., Ltd. Karlsruhe Chelmsford, MA Taipei Guangzhou Phone +49 721 6626 0...
-
Page 3: Table Of Contents
Table of Contents Important Information ..........................4 Instructions ............................... 4 General Safety Instructions ........................4 Protective Devices ........................... 5 Handling Electricity ..........................5 Procedure in Case of Accidents ......................5 Preparation ............................. 6 Tools ................................. 6 Removing and Installing the Backside Cover ................... 6 Cleaning .............................. -
Page 4: Important Information
Important Information Instructions Important information and instructions in this documentation are designated as follows: Danger! Draws your attention to an exceptionally grave, impending danger to your health or life. Warning! Indicates a hazardous situation that could lead to injuries or material damage. Attention! Draws attention to possible dangers, material damage or loss of quality. -
Page 5: Protective Devices
Important Information Protective Devices Warning! There is a risk of injury if protective devices are missing or defective. Replace all protective devices (covers, safety notices, grounding cables etc) after maintenance work has been completed. Replace parts that have become defective or unusable. Wear protective goggles for: •... -
Page 6: Preparation
Preparation Tools Do not use any worn of damaged tools. Only use tools and testing devices that are suitable for the task at hand. cab special tools: • Test collar for transfer ribbon winder (cab item number: 5534199) •... -
Page 7: Cleaning
Cleaning Cleaning by the Operator The following cleaning work is described in the “Operator's Manual“: • cleaning the device • cleaning the printhead • cleaning the print roller Cleaning the Label Sensor Fig. 2 Cleaning the label sensor Danger! Risk of death via electric shock! ... -
Page 8: Replacing Assembly Units
Replacing Assembly Units Replacing the Printhead 4.1.1 Replacing the Printhead PX4 The printhead can be replaced without the need for fine adjustment. The printhead must be replaced if worn or when switching to a printhead with higher or lower resolution. For better differentiation, the printheads have a label stating the resolution. 1 Printhead 2 Plug connection 3 Plug connection 4 Screw 5 Printing line 6 Pin... -
Page 9: Replacing The Printhead Px6
Replacing Assembly Units Removing the printhead 1. Lift the printhead. 2. Remove labels and transfer ribbon from the printer. 3. Lightly keep printhead mounting bracket (8) on the print roller, screw out screw (7) with the Allen key (9) and remove screw and washer. - Page 10 Replacing Assembly Units Fig. 6 Replacing the printhead PX6 Removing the printhead 1. Lift the printhead. 2. Remove labels and transfer ribbon from the printer. 3. Lightly keep printhead mounting bracket (7) on the print roller and loosen screws (6) with the Allen key (8). 4.
-
Page 11: Replacing The Rollers And The Dispense Edge
Replacing Assembly Units Replacing the Rollers and the Dispense Edge 7b 9 Fig. 8 Replacing the rollers and the dispense edge 1. Unlock levers (1,3) to lift the printhead and the pinch roller. Open the locking system (8) and swing it down. 2. -
Page 12: Replacing The Slipping Clutches
Replacing Assembly Units Replacing the Slipping Clutches The rewinder for the transfer ribbon is coupled to the main drive using a slipping clutch in. The supply hub of the transfer ribbon is braked with a slipping clutch during printing. Replace a slipping clutch when it can no longer be set 5.1 on page 19. Removal and installation of the slipping clutch is also required for replacement of a winder. - Page 13 Replacing Assembly Units Installing the slipping clutch on the ribbon take up hub 1 Collar of the belt wheel 2 Winder axis 3 Coupling disks 4 Slipping clutch 5 Snap ring Fig. 10 Slipping clutch on the ribbon rewinder 1. Slide coupling (4) onto the winder axis (2). 2.
-
Page 14: Replacing Label Sensor
Replacing Assembly Units Replacing Label Sensor Notice! Soiling of the label sensor can also cause malfunctions. Before replacing the label sensor, check whether it is soiled and clean it if necessary. 3.2 on page 7 Cleaning the label sensor. Danger! Risk of death via electric shock! ... -
Page 15: Replacing The Pcb Cpu
Replacing Assembly Units Replacing the PCB CPU Danger! Risk of death via electric shock! Before opening the housing cover, disconnect the device from the mains supply and wait at lease one minute until the power supply unit has discharged. Removing the PCB CPU 1. -
Page 16: Replacing Pcb Ribbon Saver And Pcb Ribbon Saver Sensor
Replacing Assembly Units Replacing PCB Ribbon Saver and PCB Ribbon Saver Sensor Danger! Risk of death via electric shock! Before opening the housing cover, disconnect the device from the mains supply and wait at lease one minute until the power supply unit has discharged. 1. -
Page 17: Replacing Pcb I/O Interface And Pcb Usb Hub
Replacing Assembly Units Replacing PCB I/O Interface and PCB USB Hub Danger! Risk of death via electric shock! Before opening the housing cover, disconnect the device from the mains supply and wait at lease one minute until the power supply unit has discharged. 1. -
Page 18: Replacing The Power Supply Unit
Replacing Assembly Units Replacing the Power Supply Unit Danger! Risk of death via electric shock! Before opening the housing cover, disconnect the device from the mains supply and wait at lease one minute until the power supply unit has discharged. Removing the power supply unit 1. -
Page 19: Adjustments
Adjustments Measuring and Adjusting the Winding Torques The rewinder for the transfer ribbon is coupled to the main drive using a slipping clutch in. The supply hub of the transfer ribbon is braked with a slipping clutch during printing. The correct setting of the torques of these slipping clutches is necessary for: •... - Page 20 Adjustments The set values for the winding torque and the resulting pulling force at the test collar are: Slipping clutch on Direction of rotation Winding torque M Pulling force F Ribbon take up hub against winding direction 12,9 - 13,5 Ncm 4,3 - 4,8 N in winding direction 2,1 - 3,0 Ncm...
-
Page 21: Adjusting The Winding Torques
Adjustments 5.1.2 Adjusting the Winding Torques The winding torque of a winder can be changed at the knurled ring of the respective slipping clutch. The numbers on the knurled ring stand for the value of the winding torque: • 1: Lowest winding torque •... -
Page 22: Adjusting The Printing Mechanism
Adjustments Adjusting the Printing Mechanism Major adjustment of the printing mechanism beyond format-based settings is only required if the printhead assembly has been removed or parts in this area have been replaced. Excluded from this is the replacement of the printhead, after which readjustment is generally not required. -
Page 23: Adjusting The Printhead Position
Adjustments 5.2.2 Adjusting the Printhead Position In order to achieve the best possible print image the following printhead settings are necessary: • Align the heating line with the highest point of the print roller. Density of the print image is the greatest at this point. -
Page 24: Adjusting The Printhead Pressure
Adjustments 5.2.3 Adjusting the Printhead Pressure The printhead pressure can be changed with the screws (1a) and (1b) at the inside and outside of the printhead. Increasing the head contact pressure leads to an improvement of the print image density on the corresponding side and to a shifting of the ribbon feed path to the opposite side. -
Page 25: Adjusting The Transfer Ribbon Feed Path
Adjustments 5.2.4 Adjusting the Transfer Ribbon Feed Path You can adjust the transfer ribbon feed path by changing the head contact pressure and adjusting the transfer ribbon deflection. Increasing the head contact pressure with the screws (3a) and (3b) shifts the ribbon feed path in the corresponding direction. The skew of the transfer ribbon deflection is used to suppress wrinkles in the transfer ribbon feed path. Wrinkles which cannot be remedied with the skew of the transfer ribbon deflection can be suppressed by bowing the printhead. Attention! The printhead assembly can be damaged when bowing the printhead. Turning the adjustment screw (1) too hard can cause damage to the printhead assembly. -
Page 26: Adjusting The Belt Tension At The Main Drive Motor
Adjustments Adjusting the Belt Tension at the Main Drive Motor Danger! Risk of death via electric shock! Before opening the housing cover, disconnect the device from the mains supply and wait at lease one minute until the power supply unit has discharged. Fig. -
Page 27: Adjusting The Head Switch
Adjustments Adjusting the Head Switch The head switch prevent printing from occurring when the printhead is open or the retraction roller isn't closed. Adjust the head switch if the error message Head open appears in the display even though the printhead is locked. Danger! Risk of death via electric shock! ... -
Page 28: Adjusting The Magnetic Clutch
Adjustments Adjusting the Magnetic Clutch A misaligned magnetic clutch can cause a very high and not adjustable torque at the ribbon supply hub. The distance between chassis of the magnetic clutch (2) and the armature disk (3) must be 0.1 mm . Danger! Risk of death via electric shock! ... -
Page 29: Adjusting The Ribbon Saver Mechanics
Adjustments Adjusting the Ribbon Saver Mechanics The saver automatic reduced the consumption of color ribbon, because in case of the saver mode the movement will interrupted by lifting the printhead. This operated by a eccentric, which is controlled by a light sensor. A failure in adjustment is possible if the transport of the ribbon is stopped generally or it will make all movements like the label material. -
Page 30: Configuring The Power Source For The Oem I/O Interface
Adjustments Configuring the Power Source for the OEM I/O Interface The OEM I/O interface can be used with the internal or an external 5 V power source. When the module is delivered the interface is configured for the internal power source of the module. In order to isolate the interface from the internal power source, an external voltage must be connected. To adapt the power source mode the setting of the jumpers at JP4 and JP5 must be altered. -
Page 31: Troubleshooting And Error Treatment
Troubleshooting and Error Treatment Failure of Device Functions Functional error Possible remedy Medium is not transported Check electrical connections between PCB CPU and motor Check drive mechanism Replace the PCB CPU Replace the motor No print image with medium Check plug connections at the print head transport Examine print head cable for damage and replace if necessary Replace the print head... -
Page 32: Hardware Faults
Troubleshooting and Error Treatment Hardware Faults Error message Cause Fault recovery ADC malfunction Fault on the PCB CPU Replace the PCB CPU FPGA malfunction Fault on the PCB CPU Replace the PCB CPU Invalid setup Fault on the PCB CPU Replace the PCB CPU Voltage error Voltage of the battery on the... -
Page 33: Block Diagram
Block Diagram No.1 No.2 No.3 No.4 No.5 No.6 PX4L/200 5955384 5956381 5956242 5956241 5965035 5952586 PX4L/300 5955384 5956382 5956242 5956241 5965035 5952586 PX4L/600 5955384 5956383 5956242 5956241 5965043 in Nr. 5 PX4R/200 5955385 5956381 5954067 5956241 5965035 5952587 PX4R/300 5955385 5956382 5954067 5956241... - Page 34 Block Diagram Fig. 34 Block diagram - Part 2 - Version with cab I/O interface Fig. 35 Block diagram - Part 2 - Version with OEM I/O interface...
-
Page 35: Layout Diagram Pcb Cpu
Layout Diagram PCB CPU Fig. 36 Layout diagram PCB CPU - components side... - Page 36 Layout Diagram PCB CPU Fig. 37 Layout diagram PCB CPU - soldering side...
-
Page 37: Index
Index Printing Mechanism ......22 Protective Devices ......5 Accidents ..........5 Ribbon Saver Mechanics....29 Belt Tension ........26 Ribbon Supply Hub.....13, 20 Block Diagram ........33 Ribbon Take Up Hub ....13, 20 Brake ..........13 Roller ..........11 Cleaning ..........7 Safety Instructions ......4 Clutches..........12 Sensor Ribbon Saver .......29 Cover ..........6 Slipping Clutch......12, 21 Dispense Edge ......... - Page 38 This page is intentionally left blank.
