Summary of Contents for Unimes U1
- Page 1 SUZHOU UNIMES INFORMATION & TECHNOLOGY CO.,LTD...
-
Page 2: Table Of Contents
Table of Contents 1 Introduction..................................... 1 1.1 Appearance of U1................................1 Figure 1-3 Rear view of U1............................1 1.2 Installing an SD Card................................ 2 Figure 1-3 Inserting an SD card............................2 1.3 Installing a SIM Card.................................3 Figure 1-4 Inserting a SIM card.............................3 1.4 Installing a Battery................................ -
Page 3: Introduction
U1 User Manual 1 Introduction 1.1 Appearance of U1 Figure 1-1 Front view of U1 Figure 1-2 Front view of U1 Figure 1-3 Rear view of U1 - 1 -... -
Page 4: Installing An Sd Card
U1 User Manual 1.2 Installing an SD Card To install an SD card, do as follows: 1. Push the card cover along the direction marked on the cover and open the cover. 2. Insert an SD card. 3. Press the SD card downward and lock the card along the IN direction marked on the cover. -
Page 5: Installing A Sim Card
U1 User Manual 1.3 Installing a SIM Card To install a SIM card, do as follows: 1. Insert a SIM card along the direction, as shown in Figure 1-4. 2. Press the card cover downward. 3. Push the SIM card along the LOCK direction to lock the card cover. -
Page 6: Disassembling The Battery Cover
U1 User Manual Figure 1-5 Installing a battery 1.5 Disassembling the Battery Cover To disassemble the battery cover, do as follows: 1. Insert your left forefinger into the upper left part of the battery cover and push the lock to the left by using the thumb. -
Page 7: Charging
The battery can be charged for more than or less than three hours. The battery will not be damaged if charging is interrupted. The duration of the battery depends on different applications of the U1, for example, selected functions of U1, usage mode, and data transmission. -
Page 8: Instructions On The U1
U1 User Manual 2 Instructions on the U1 2.1 Power-on and Power-off After installing a SIM card and a battery and fully charging the U1, you can use the U1. 1. To power on the , press and hold the On/Off key for some time. -
Page 9: Home
Home key Menu key Return key 2.4 Home The U1 has five home pages. Slide to the left or right to switch among the pages. Click any application on the home page to start the application. Application tray ★ Tips You can add application icons in blank space of the home page. -
Page 10: Basic Settings
Connect to Pea ★ Note The applications of the U1 are often upgraded. Therefore, the status icons may be different from those on the U1. The actual status icons prevail. 2.6 Basic Settings 2.6.1 Date and Time Setting... -
Page 11: Display Settings
U1 User Manual 2.6.2 Display Settings Find the following icon: Select Settings > Display and set display options such as Brightness, Wallpaper, Auto- rotate screen, and Font size. 2.6.3 Ringtone Setting Select Settings > Audio Profiles and click General/Silent/Meeting/Outdoor to set the ringtone in the corresponding mode. -
Page 12: Security Setting
U1 User Manual 2.6.4 Security Setting Select Settings > Reset > Factory date reset. Click Clear all. The U1 starts to restore the factory settings. ★ Caution This operation will clear the following data in the U1: Account Data and settings of the system and applications ... -
Page 13: Language And Input Setting
Click Default and select the desired input in the list. 2.6.6 Shortcuts You can add shortcut icons on the home page of the U1. On the home page, click the application tray icon, select and drag the icon to be added to the home page. -
Page 14: Call Function
U1 User Manual 3 Call Function 3.1 Making a Call Find the following icon: 1. Enter a telephone number by pressing number keys. Click 3. Click to terminate the call. Contact Call record Voice call Virtual numeric keypad 3.2 Contacts Find the following icon: 1. -
Page 15: Sms And Mms
U1 User Manual 3.3 SMS and MMS Find the following icon: 1. Click and enter the message recipient and the text to be sent. 2. Click to send the message. 3. On the message editing page, press the menu key to open the menu and click Add Subject. -
Page 16: Email
You can send or receive emails. ★ Note To create an email account on the U1, you need to set the account on a PC. For example, to create a QQ email account, log in to the QQ mailbox, click Settings in the upper right corner of the mailbox to access the account options. - Page 17 U1 User Manual To delete an account, do as follows: 1. On the mailbox page, press the menu key and click Settings. 2. Click the email account to be deleted and access the setting page. 3. Click Remove account. - 15 -...
-
Page 18: Data Connection
U1 User Manual 4. Network and Connection Synchronization 4.1 Data Connection By default, the network is configured for the device upon delivery. If you delete the network configuration by mistake, you can manually select a network through software configuration. In hardware, different antennas are used in two network modes. In software, you need to perform the following configuration: Select Settings >... - Page 19 After a GPRS data connection is established, you can access the Internet. To establish a GPRS data connection, ensure that a SIM card is installed in the U1. Generally, the U1 has configured Internet access. If you delete the default configuration by mistake, set the network as follows (assume that China Mobile’s network is used):...
-
Page 20: Wi-Fi Network Connection
Click to connect to the network 4.3 GPS The U1 is equipped with a high-performance navigation chip and can obtain position information quickly and accurately. The manufacturer of the U1, SUZHOU Unimes Technology Co.,Ltd. provides GPS Test, which is a GPS demonstration program. Before using the GPS, install GPS Test. -
Page 21: Connecting U1 To A Computer
U1 User Manual 4.4 Connecting U1 to a Computer Connect the U1 to a computer by using a USB cable so that files in the memory card, for example, pictures, videos, and music, can be transferred to the computer and processed in the computer. -
Page 22: Synchronization
U1 User Manual 4.5 Synchronization Select Settings > Accounts & sync. 1. Click ADD ACCOUNT to set a new account. 2. Click Company or Email, enter the email address and password, and click Next. Wait until the connection is completed (for details about mailbox settings, see section 3.4 Email). -
Page 23: Installing And Using Iscan
First of all, install iScan on the U1 (for details on how to install iScan, see 6.1 Installing Software). After iScan is installed, the iScan icon is displayed on the application page. Click the icon to start the software (by default, Barcode Scan is selected). -
Page 24: Installing Software
U1 User Manual 6 Managing U1 6.1 Installing Software The U1 uses Google’s Android platform whose suffix is apk. To install software on the U1, use the following methods: 1. Download and install software through the online software store provided by Google (Google Play) or Android software download platform (HiMarket) used in China. -
Page 25: Managing Applications
U1 User Manual 6.3 Managing Applications Press the menu key (yellow scan key) and click Manage apps. You can view the status of download applications, applications in the SD card, and running applications and click any application to access the application information page where you can stop, uninstall, or suspend the application. -
Page 26: Precautions For U1
Do not store the U1 in a place that is too hot. High temperature will shorten the service life of electronic components. Do not store the U1 in a place that is too cold. When the temperature inside the U1 rises, moisture is generated inside the 1, which may damage the circuit board. -
Page 27: Troubleshooting
7.2 Troubleshooting Table 7-1 U1 troubleshooting Fault Cause Solution The battery volume is too Charge the U1 or replace the battery. low or the battery is not After the power key is charged. pressed, the U1 is not The battery is incorrectly powered on. - Page 28 SD card. Too many applications are Remove applications installed on the U1. installed on the U1. The scan application is not Load iScan in the U1.
- Page 29 U1 User Manual Table 7-2 Cable troubleshooting Fault Cause Solution Charging fails. The cable is in poor Replace the cable. contact. synchronization The cable is in poor Replace the cable. software cannot contact. connected. Table 7-3 Wi-Fi connection troubleshooting Fault...
-
Page 30: Appendix
Optional 4-slot charger Optional Silicone case Optional Smart pen Optional Bottom charging cable U 95E(Optional), iData 95W,iData 95V(Standard) Table 2 Technical specifications of U1 Item System configuration Processor 1.3 GHz high-performance 1 GHz high-performance dual-core quad-core processor processor Operating system Android 4.4... -
Page 31: Laser Scanner
U1 User Manual Item iData 95W iData 95V Operating environment Development tool Android SDK+JDK+Eclipse Supported language Java, C Management tool U Tools Operating -10C–50C temperature Operating environment Storage temperature -20C–60C Humidity 0%–95% (non-condensing) Drop specification 1.5-meter drop on cement floor Tumble specification 500 0.5-meter tumbles (1000 hits) -
Page 32: Rfid
U1 User Manual Item Interface Initial rate: 1200 bps, supported rates: 1200, 2400, 4800, and 9600 bps RFID Frequency 13.56 MHz Reading distance Within 50 mm Communication ISO14443A(B)/15693 protocol Optional Optional - 30 -... - Page 33 U1 User Manual ©Suzhou Unimes Information & Technology Co.,Ltd All Rights Reserved. This guide is prepared by Suzhou Unimes Information & Technology Co.,Ltd. according to the existing information. The content in this document is subject to update without notice. Without written approval of Suzhou Unimes Information & Technology Co., no one shall copy, extract, back up, modify, spread, or translate any part of this document in any form or method or use the whole or part of this document for business purposes.
