Summary of Contents for FPG IL-C-DRW-A003
- Page 1 Refrigerated Milk Drawer...
- Page 2 Copyright © May 2018 Future Products Group Limited. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of Future Products Group Ltd.
-
Page 3: Table Of Contents
Table of Contents INTRODUCTION ........................ 6 Welcome ................................6 Future Products Group (FPG) ........................6 Guidance and Help ............................ 6 Warranty ................................6 Warranty Period ............................6 Liability Exceptions ............................ 7 Specific Exclusions ............................ 7 Assessment ............................... 7 Time Limit ..............................7 Caution .............................. - Page 4 Interior ................................14 Empty the Drawer ............................ 14 Lift Out Plastic Guides ..........................14 Lift Out Sloping Base Tray ........................14 Lift Out the Baffle Plate ........................... 14 Cleaning Routines ............................15 Schedules..............................15 Removable Filter ............................. 15 Condenser Radiator ..........................15 Inspection ..............................
- Page 5 On-going Development ........................... 30 ELECTRICAL CIRCUIT DIAGRAMS ................31 Model: IL-C-DRW-A001/A003 ......................... 31 SPARE PARTS ........................ 32 Cabinet Serial Number ..........................32 MECHANICAL DRAWINGS ..................... 33 Model: IL-C-DRW-A001 .......................... 33 Model: IL-C-DRW-A003 .......................... 34 IL-C-DRW-A001/A003 - 5 - © Future Products Group...
-
Page 6: Introduction
INTRODUCTION Welcome REFRIGERATED CABINETS INTRODUCTION Future Welcome to the world of FPG! Our products are designed and engineered to Products give you the optimal performance that you deserve with innovative visual Group (FPG) merchandising appeal. We are confident that you will be delighted with your state of the art inline food service cabinet, and that it will become a valued appliance in your store. -
Page 7: Liability Exceptions
• Fair wear and tear. Assessment The liability under this warranty is dependent on an assessment by FPG, to determine the defect in workmanship or materials. Time Limit FPG does not guarantee that any service to be performed under this warranty will be carried out within any particular time limit. -
Page 8: Operation
OPERATION Cabinet Features REFRIGERATED CABINETS OPERATION Large Capacity The drawer has a large storage capacity. It can be configured for an asortment of product packaging. Adjustable The inclined, gravity feed base has Guides adjustable guides, so that products can be consistently organised. -
Page 9: Control Panels
Controls REFRIGERATED CABINETS OPERATION Control Panels The control on the front of the cabinet is fitted with: • A mains Power Switch • A refrigeration controller Temperature The controller regulates the cabinet temperature Controller and controls the automatic defrost cycles. Only to be The display indicates the temperature of the adjusted by a... -
Page 10: Power Supply
Preparation cont. REFRIGERATED CABINETS OPERATION Power Supply Ensure that power is connected to the cabinet. Close the It is important to keep the drawer closed. Drawer If the drawer is not fully closed, an even temperature will not be maintained within the cabinet. -
Page 11: Trouble Shooting
TROUBLE SHOOTING FAULT POSSIBLE CAUSE REMEDY The mains isolating switch on Turn isolating switch circuit the wall, circuit breaker or fuses breaker or fuses on are off at the power board Switch cabinet off and on. High pressure switch tripped Cabinet does not Clean condenser and radiator operate/start... -
Page 12: Fault Alarm Procedure
Fault Alarm Procedure REFRIGERATED CABINETS TROUBLE SHOOTING Dixell CA Fault If a “CA” fault alarm appears on the Dixell controller screen, take the following action: 1. Turn off the power supply to the cabinet 2. Clean the condenser pre-filter or the condenser coil if the cabinet is not equipped with a pre-filter 3. -
Page 13: Cleaning
CLEANING Cautions REFRIGERATED CABINETS CLEANING Power ALWAYS TURN THE POWER SUPPLY OFF BEFORE CLEANING. Water THIS UNIT IS NOT WATERPROOF. DO NOT USE A WATER JET SPRAY TO CLEAN THE INTERIOR OR EXTERIOR OF THIS CABINET. Exterior REFRIGERATED CABINETS CLEANING Plastic and Plastic or stainless steel surfaces should be cleaned with hot soapy water or a Metal Surfaces... -
Page 14: Interior
Interior REFRIGERATED CABINETS CLEANING Empty the Do NOT remove the drawer for routine Drawer cleaning. Open the drawer fully, and remove all products. Lift Out Plastic The plastic guides just rest on the inclined Guide base tray, and can be lifted out for cleaning. Individual sections may be unclipped from the acrylic strip if required. -
Page 15: Cleaning Routines
Cleaning Routines REFRIGERATED CABINETS CLEANING Schedules Regular cleaning schedules are required to maintain optimum performance. Failure to carry out routine cleaning/servicing schedules will void the warranty on the refrigeration equipment. Removable The air pre-filter must be kept Filter clean, to maintain efficient refrigeration performance. -
Page 16: Installation
INSTALLATION Regulations REFRIGERATED CABINETS INSTALLATION Compliance It is very important that your cabinet is installed correctly and that the operation with Local is correct before use. Installation must comply with local electrical, health & Requirements safety and hygiene requirements. Setting Up REFRIGERATED CABINETS INSTALLATION Unpacking... -
Page 17: Condensate Drain
Setting Up cont. REFRIGERATED CABINETS - INSTALLATION Condensate The condensate drain outlet must be connected to a suitable drain. Exit holes Drain are provided underneath, and on either side of the cabinet. A P-trap must be included in the piping, to prevent contaminated air from entering the cabinet. -
Page 18: Servicing
SERVICING Control Gear REFRIGERATED CABINETS SERVICING Control Gear All control gear is located in the box behind the mains Location switch. Hinge down the spring loaded front panel to access it. Remove two screws to release the back panel. Control Gear The chassis houses the connecting blocks for the Chassis refrigeration equipment, a fuse for the low power... -
Page 19: Refrigeration
Refrigeration REFRIGERATED CABINETS SERVICING Caution DO NOT attempt to service the refrigeration equipment without isolating the cabinet at the main switch or unplugging it from the wall. Removable The cabinet is fitted with a removable Filters filter, which will catch most of the dust and fluff, before it reaches the condenser radiator. -
Page 20: Support Bolt
Refrigeration cont. REFRIGERATED CABINETS - SERVICING Support Bolt The support bolt must be unscrewed if the cabinet is to be removed from the joinery, or access to the evaporator fans, coil or probes is required. Evaporator The drawer must be removed to access Access the evaporator fans, coil and temperature probes. -
Page 21: Temperature Regulator Xr40Cx
Refrigeration cont. REFRIGERATED CABINETS - SERVICING Temperature Model XR40CX is a microprocessor based Regulator controller. XR40CX It is has two NTC probe inputs, the first one for temperature control, the second one, located onto the evaporator, to control the defrost termination temp. The indicated temperature will be slightly higher than the temperature inside the drawer, because the refrigeration condenser is controlled in response to the temperature of the return air entering the cooling coils. -
Page 22: Xr40Cx Key Functions
Refrigeration cont. REFRIGERATED CABINETS - SERVICING XR40CX Key FUNCTION Functions To display target set point; in programming mode it selects a parameter or confirm an operation (DEF) To start a manual defrost (UP): To see the max. stored temperature; in programming mode it browses the parameter codes or increases the displayed value (DOWN): To see the min stored temperature;... -
Page 23: Xr40Cx Display The Set-Point
Refrigeration cont. REFRIGERATED CABINETS - SERVICING XR40CX Press and release the key. Min & Max Lo will be displayed followed by the minimum temperature recorded. Recorded Press the key again or wait 5s to restore the normal display. Temperature Press and release the key. - Page 24 Refrigeration cont. REFRIGERATED CABINETS - SERVICING XR40CX The The hidden menu includes all the parameters of the instrument. Hidden Menu TO ENTER THE HIDDEN MENU • Enter the Programming mode by pressing the keys for 3s, (the °C or °F LED starts blinking). •...
-
Page 25: Fpg Settings
Refrigeration cont. REFRIGERATED CABINETS - SERVICING FPG Settings Note that the following settings are Dixell factory defaults. Refer to the Specification section for the correct FPG settings for your cabinet. Dixell Default Label Name Range Default Settings Set point LS÷ US -5.0... -
Page 26: Xr40Cx Hot Key
Refrigeration cont. REFRIGERATED CABINETS - SERVICING Label Name Range Default Dixell Default Settings cont. Differential for temperat. alarm recovery (0,1 °C÷25,5°C) (1 °F÷45°F) Temperature alarm delay 0 ÷ 255 min Delay of temperature alarm at start up 0 ÷ 23h e 50’ Probe for temperat. -
Page 27: Xr40Cx Alarm Signals
Refrigeration cont. REFRIGERATED CABINETS - SERVICING XR40CX Message Cause Outputs Alarm Signals Room probe failure Compressor output acc. to par. Con and COF Evaporator probe failure Defrost end is timed Third probe failure Outputs unchanged Fourth probe failure Outputs unchanged Maximum temperature alarm Outputs unchanged. -
Page 28: Specifications
SPECIFICATIONS Mechanical REFRIGERATED CABINETS SPECIFICATIONS CABINET MODEL IL-C-DRW-A001 IL-C-DRW-A003 Height overall mm Adjustment mm +30-0 mm 0 mm Width mm Depth mm Dry Weight kg Cabinet Well Material Stainless Steel Stainless Steel Storage Drawers Drawer Capacity 24 x 2 litre bottles... -
Page 29: Controller Settings
Controller Settings REFRIGERATED CABINETS SPECIFICATIONS Changes from The following table specifies the controller settings which differ from the Dixell Dixell Defaults default values. Parameters not listed in this table should remain at the default values specified in the XR40CZ Parameters listed in the Servicing section. XR40CX Settings Parameter Description... -
Page 30: Compliance
25°C Ambient with 60% RH Improvements REFRIGERATED CABINETS SPECIFICATIONS On-going FPG reserves the right to change specifications and construction, as part of on- Development going product improvement. Part No. 26984 Rev. C May 2018 - 30 - Refrigerated Milk Drawer... -
Page 31: Electrical Circuit Diagrams
ELECTRICAL CIRCUIT DIAGRAMS Model: IL-C-DRW-A001/A003 Refrigerated Milk Drawer IL-C-DRW-A001/A003 - 31 - © Future Products Group... -
Page 32: Spare Parts
Number the label fixed to the control panel. This serial number will enable FPG to trace details of the build specification of your particular cabinet, and hence ensure that spare parts are fully compatible. To satisfy warranty conditions, and ensure optimum performance, use only FPG supplied spare parts. -
Page 33: Mechanical Drawings
MECHANICAL DRAWINGS Model: IL-C-DRW-A001 IL-C-DRW-A001/A003 - 33 - © Future Products Group... -
Page 34: Model: Il-C-Drw-A003
Model: IL-C-DRW-A003 Part No. 26984 Rev. C May 2018 - 34 - Refrigerated Milk Drawer... - Page 35 IL-C-DRW-A001/A003 - 35 - © Future Products Group...
- Page 36 Part No. 26984 Rev. C May 2018 For full contact details please visit the Contacts page on FPGWORLD.COM or email us at support@fpgworld.com In line with policy to continually develop and improve its products, Future Products Group reserves the right to change specifications and design without notice. AUSTRALIA CHINA | ASIA EUROPE...
