If the required connector is not included in the list, please send us an email indicating the model and manufacturer of the connector and we Ordering of connectors will inform you whether it is compatible with the Cygnus Pro system.
Its operation is very simple. To carry out the measuring you must connect the Cygnus Pro Main to the point you want to test and the Cygnus Pro Loop in the other end to close the circuit. Signal Specifications...
Cygnus Pro Composition Connector Pinout The Hybrid Fiber Optic Tester CYGNUS PRO have 3 main structures for checking the F.O lines and copper lines. Main Module Main module with the OLED display and printed circuit that manages the operation of the tester.
Errors detection Buttons On ( Power Up) .- Press the button during one second to switch on the CYGNUS PRO. Press it three seconds to switch Error in the optic fiber: If there is a breakdown in the it of.
Picture 1.3 an error occurs it increases the counter. Main Menu Display. Contain the main menu options and the Cygnus Pro status. ( pic. 2 ) Option selection by key up/down. The selected option is highlighted in bright orange color.
Type of Measurement Configuration display (SETUP) Allows to select the type of measuring “MODE”, the status of the auto power-off CURRENT & CONTINUOUS MODE: Test display of the device with the “SAVER” and the calibration of the device “CALIBRATE” (pic measurement configured in continuous mode (CONT) and real time (CURR).
CALIBRATE: It indicates the calibration status, as well as the option to calibrate The Cygnus Pro allows one main module and several headers with the most usual or clear the former calibration to make a new one. For the device recalibration, connectors.
