Summary of Contents for Nexus Rota-pro CB3RP-210-90
- Page 1 June 2015 Edition Electrically powered rotational profiling chair bed USER MANUAL Product Code: CB3RP-210-90...
- Page 2 SAFETY NOTICE This manual contains important information regarding the safe & proper setup and use of the bed. It is important that anybody involved should have read and understood its contents. Failure to do so could result in damage to the bed and may invalidate the warranty. Please be aware that elements of the bed are heavy.
- Page 3 Each caster has a simple, individually foot operated brake. ACCESSORIES / CONFORMITY Nexus brand accessories are designed to work in harmony with the moving parts of our beds and, in conforming to BS EN 60601-2-52 Safety Standard, reduce the risk of entrapment.
- Page 4 SECTION TWO: PRODUCT IDENTIFICATION Each bed carries a CE Mark label which identifies the bed’s model and its unique Serial Number. Where advice or spare parts are required, it is essential to quote the Serial Number, as this enables us to match parts and advice to your particular bed. The identification label, similar to the one in the picture, is located on the metalwork of the bed Bed model...
- Page 5 FITTING THE LIFTING POLE The lifting pole can be fitted into the sockets on either the left- or right-hand-side of the mattress support, at the head end. Rotate the pole until the locator-pin slots securely into the corresponding groove in the socket. This prevents the pole from rotating and holds it centrally above the user, ensuring it is securely positioned for use.
- Page 6 APPLYING AND RELEASING THE BRAKES Each caster has its own individually-operated brake. To apply each brake, push the brake lever down with your foot. To release the brake, use the top of your foot to lift the spring-loaded lever back up. Push to lock PLEASE NOTE: •...
- Page 7 USING THE HAND CONTROL (continued) PLEASE NOTE: Please refer to the Safety Notice on Page 2 before using any powered functions. Lift functions Lower functions...
- Page 8 • Bed linen can weigh roughly 12kg the stated Safe Working Load for the bed. NEITHER NEXUS DMS LTD, NOR ANY OF ITS EMPLOYEES, CAN ACCEPT RESPONSIBILITY FOR ANY ISSUES ARISING FROM OVERLOADING A BED. SHOULD DAMAGE RESULT FROM SUCH ACTIONS,...
- Page 9 MATTRESS INTEGRITY AND CARE If a mattress cover is damaged, bodily (or other) fluids can pass through and contaminate the inner core, creating the potential for cross-infection. This is usually known as strike-through. It is therefore recommended that a frequent inspection of mattress covers is undertaken to inspect for damage, such as holes, cuts or tears.
- Page 10 TECHNICAL DATA Name Rota-Pro® Chair Bed Product Code CB3RP-210-90 Operating voltage ~230V / 240V / 50Hz IEC 601-1 Device Type Safety Class Main control unit IP 54 Hand control IP 54 Actuators IP 54 Continuous use of any powered function (ED) 10% Maximum 6 minutes per hour Safe Working Load 175kg / 28 Stone...
- Page 12 MANUFACTURER DETAILS Nexus DMS Ltd Unit 11 Lovett road Hampton Lovett Industrial Estate Hampton Lovett Droitwich Worcs WR9 0QG www.nexusdms.co.uk sales@nexusdms.co.uk +44 (0)1905 774695 Rota-Pro® is a registered trademark of Nexus DMS Ltd.
