- Page 1 SCP Cube New-Generation Supercapacitor Industrial Power Backup Solution User’s Manual Version 1.0 P/N: 4019000000100P 2018.10...
-
Page 2: Revision History
Revision History Version Date Description 2018.10 Initial release - II -... -
Page 3: Table Of Contents
1.4 Dimensions ..................3 1.5 Specifications ..................3 Chapter 2 - Installation & Configuration ..........5 2.1 Getting to Know the SCP Cube ............6 2.2 Connection ..................7 2.3 Ensure Your PC Restart Automatically After a Power Outage ..9 2.3 DIN-Rail Mounting ................ -
Page 4: Contents
Contents - ii -... -
Page 5: Preface
Preface Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such damages. - Page 6 (PBDE) in electrical and electronic products. Member states of the EU are to enforce by 7/1/2006. ARBOR Technology Corp. hereby states that the listed products do not contain unintentional additions of lead, mercury, hex chrome, PBB or PBDB that exceed a maximum concentration value of 0.1% by weight or for cadmium exceed...
-
Page 7: Important Safety Instructions
Preface Important Safety Instructions Read these safety instructions carefully 1. Read all cautions and warnings on the equipment. 2. Place this equipment on a reliable surface when installing. Dropping it or letting it fall may cause damage 3. Make sure the correct voltage is connected to the equipment. 4. -
Page 8: Technical Support
Preface Warning The Box PC and its components contain very delicately Integrated Circuits (IC). To protect the Box PC and its components against damage caused by static electricity, you should always follow the precautions below when handling it: 1. Disconnect your Box PC from the power source when you want to work on the inside. - Page 9 Preface Warranty This product is warranted to be in good working order for a period of one year from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.
- Page 10 This page is intentionally left blank. - viii -...
-
Page 11: Chapter 1 - Introduction
Chapter 1 Introduction Chapter 1 - Introduction - 1 -... -
Page 12: Product Highlights
Upon opening the package, carefully inspect the contents. If any of the items is missing or appears damaged, contact your local dealer or distributor. The package should contain the following items: 1 x SCP Cube 1 x Accessory Box that contains the following items: •... -
Page 13: Dimensions
Introduction 1.4 Dimensions 2-M3x0.5 THREAD (20) (60) Unit: mm 2-M3x0.5 THREAD 1.5 Specifications System Chip High current supercap backup controller Supercapacitor Capacity 400 Farads / each Power Requirement Power Input DC 12~28V input support Power Output DC 12V / 24V output with switch support Power In 1 x 3-pin terminal block Power Out... - Page 14 Introduction Switch 1 x slide switch for power output control 1 x Type-A connector 1 x COM with RS-232 Environmental Operating Temp. -20ºC ~ 70ºC (-4ºF ~ 140°F) Storage Temp. -30ºC ~ 80°C (-22°F ~ 158°F) Operating Humidity 10 ~ 95% RH @ 70°C (non-condensing) Vibration 0.5 Grms/5~500Hz/random operation Shock...
-
Page 15: Chapter 2 - Installation & Configuration
Chapter 2 Installation Chapter 2 - Installation & Configuration - 5 -... -
Page 16: Getting To Know The Scp Cube
Displays power & charging status. See below for details. RS-232 COM Port COM Port To connect to industrial PC system for monitoring SCP Cube power status. USB 2.0 Port USB Port To connect to industrial PC system for monitoring SCP Cube power status. -
Page 17: Connection
Installation & Configuration The following is a depiction of some different states of the SCP Cube: The SCP Cube is The SCP Cube is The SCP Cube is connected to a power disconnected from a connected to a power source. - Page 18 B. Connecting the SCP Cube to Your Industrial PC System 1. Connect the power input of your IPC to the power output of the SCP Cube. 2. Slide the PWR OUTPUT VOLTAGE switch on the SCP Cube to 24V or 12V according to the power input of the connected system.
-
Page 19: Ensure Your Pc Restart Automatically After A Power Outage
Installation & Configuration Connect to industrial PC system via USB or COM port Power Input Power Input Power Source Power Output Connection Diagram Example 2.3 Ensure Your PC is On Automatically When Power Resumes To ensure that your industrial PC restarts automatically after a power outage is over, you have to enable the computer to "see"... -
Page 20: Din-Rail Mounting
Installation & Configuration 2.3 DIN-Rail Mounting The DIN-rail mounting clip is screwed on the SCP Cube in the factory. To DIN mount the SCP Cube: 1. Snap the DIN Rail clip to the upper edge of the DIN Rail. 2. Press the SCP Cube firmly downward towards the DIN Rail until the DIN Rail clip tab engages and snaps to the bottom edge of the DIN Rail. - Page 21 SCP Cube Utility and save it to the industrial PC. Monitoring SCP Cube Power Status Run the exe file of the SCP Cube Utility to launch the utility, and then on the Status tab you can view the SCP Cube power information.
-
Page 22: Configuring The Scp Cube (Optional)
Output voltage: The SCP Cube's output voltage. 2.5 Configuring the SCP Cube (Optional) The SCP Cube utility allows you to configure the shutdown mode and timeout settings in case of power loss. If you need to make the configuration: 1. Launch the SCP Cube monitoring utility. On the Status tab, click the Disconnect button. - Page 23 This option is enabled by default to force the PC to hibernate/shut down in case the remaining power is not enough. When power outage occurs, the SCP Cube keeps monitoring if the remaining capacity is enough for the IPC operation. If the capacity reaches a low limit, the SCP Cube will hibernate/ shutdown the IPC after 10 seconds anyway, regardless of the shutdown timeout settings.
- Page 24 Installation & Configuration It is recommended that you enable this option to ensure the IPC can be safely shut down. 3. After completing the settings, click the Status tab and click the Connect button to restore the connection. After connection, the power information will be displayed again on the Status tab.
-
Page 25: Chapter 3 - Operation Mode
Chapter 3 Operation Mode Chapter 3 - Operation Mode - 15 -... -
Page 26: Operation When Dc Power Is Available
Charge voltage: 10V Charge current: 2.9A Max. Figure 3-1 SCP Cube Operation on DC Power When DC power is available to the SCP Cube: • The DC power supply provides both charging current for the supercapacitors and the load current for the connected IPC at the same time. -
Page 27: Operation When Dc Power Is Not Available
The supercapacitors start providing power to the connected IPC to maintain its operation. • After the shutdown timeout expires (60 seconds by default), the SCP Cube starts to hibernate (default) or shutdown your IPC. If the power resumes during this phase, the countdown timer will automatically stop counting. -
Page 28: Operation Mode
Time for S4 (default) / S5 Power Off If low capacity detected S4/S5 Power Off Starts S4/S5 Power Off Finished Time for S4 (default) / S5 Power Off secs Figure 3-3 SCP Cube Event Timeline during Power Outages - 18 -... -
Page 29: Operation When Dc Power Resumes
Operation Mode 3.3 Operation When DC Power Resumes When the power resumes, the connected PC will restart automatically. If not, please make sure to configure the PC's BIOS settings as described below: 1. Open your computer's BIOS settings menu. 2. Look for the Power Settings menu. Ensure the "Power on after Power Loss"...
