Page 1: Installation Instructions
Installation Instructions & User Guide A&A Manufacturing Rev. 20200108 © Copyright 2020 A&A Manufacturing. All rights reserved. - Page 2 (Blank Page)
-
Page 3: Prior To Installation
The installer must read this manual completely before attempting installation. Consult A&A Manufacturing with any question regarding this product. This guide must be left with the pool owner or operator. ABS to PVC transitional glue must used between the QuikDekClor body and PVC schedule 40 pipe. NOTE :... - Page 4 IMPORTANT DO NOT install over steps or benches. Locating the QuikDekClor Position the QuikDekClor using the following image (Figure 2). Top of Canister Ø 8.25” (210mm) 1.50” (38mm) 19.39” 2.08” (493mm) (53mm) 1.40” 17.39” (36mm) Ø 6.96” (442mm) (177mm) 1.00”...
- Page 5 1. To ensure a proper height for poured concrete decks, the top of the QuikDekClor canister should be set 2” above the top of the bond beam and as close to the form as possible. This setting will position with the 1” balance line approximately 15” below the top of the form (Figure 3).
- Page 6 Plumbing the Balance Line 1. Using 1” PVC the balance line can be installed by gluing a 2 inch long piece of pipe into the bottom of the canister and once that joint has set, dry-fit a 90° elbow (Figure 5a). 2.
- Page 7 1. After the filter on the circulation return line, plumb a the main-line that will provide the supply water to feed line for the QuikDekClor. Use a gate-valve just below the Tee in the header (Figure 6). This valve will regulate the amount of water flow through the QuikDekClor and ultimately regulate the amount of chlorine that enters the pool.
- Page 8 2. Install the 1” threaded male adaptor (Figure 7a) and fill the canister with water to gravity test the tank and glue joints. 3. At start-up, the 1” PVC stand-pipe, inside the QuikDekClor canister, should be cut so that it extends approximately one inch above the pool’s water level. Once trimmed to the appropriate length, push the stand-pipe into the supplied female adapter at the bottom of the canister (Figure 7b).
-
Page 9: Limited Warranty
Limited Warranty To original purchasers of this equipment, A&A Manufacturing will warrant the QuikDekClor from defects in materials and workmanship for a period of one year from the date of purchase. The limited warranty excludes damage from freezing, negligence, improper installation, improper use or care or any Acts of God. Parts that fail or become defective during the warranty period shall be repaired or replaced, at A&A Manufacturing’s option, within 90 days... - Page 10 A&A Manufacturing QuikDekClor Warranty Registration Card Directions: Please Fill out bottom portion completely and mail within 30 days of purchase or register your product online at www.amfg.com Please Mail to: ATTN: WARRANTY DEPT, A&A Manufacturing 3750 W Indian School Dr, Phoenix AZ 85019...
