Summary of Contents for ATLA COOP GAMMA
- Page 1 OPERATING AND MAINTENANCE INSTRUCTIONS PNEUMATIC CRIMPING MACHINE GAMMA Built in year: 2008 Rev. 00...
-
Page 2: Table Of Contents
List of contents HOW TO USE AND KEEP THIS INSTRUCTIONS HANDBOOK Purpose and Allocation of these Instructions Definitions and Terminology Handbook's Layout How to keep the instructions handbook Updating Terminology GENERAL DESCRIPTION Overall Dimensions and Technical Data Duty Standard Equipment Guidelines for Safe Use Suitable User SPECIFICATIONS... - Page 3 OPERATING INSTRUCTIONS Operating Commands and Control Devices Other Commands on the Crimping Machine How to start and stop the Machine 5.3.1 Start 5.3.2 Stop Machining cycle How to work a profile 5.5.1 How to adjust the Vertical Cylinder 5.5.2 How to adjust the Eccentric Guides 5.5.3 How to mount and adjust the Bracing Clamp 5.5.4...
- Page 4 Technical Service DISMANTLING AND SCRAPPING INSTRUCTIONS Removal of the Connections Scrapping ENCLOSED DOCUMENATION List of the enclosed documents Rev. 00...
- Page 5 LIST OF THE VALID PAGES Section Total pages Date Preliminary Text From pag. i to pag. vii July 2003 From pag. 1-1 to pag. 1-4 July 2003 From pag. 2-1 to pag. 2-3 July 2003 From pag. 3-1 to pag. 3-5 July 2003 From pag.
- Page 6 LIST OF THE REVISED AND/OR ADDED PAGES Rev. Description Page Date Rev. 00...
- Page 7 MANUFACTURING DATA MANUFACTURER ________ ATLA COOP SCRL _________________________ _______ Via Bolognese, 5 - Loc. TaiutiS. Piero a Sieve - ADRESS ______________________________________________________________ _______________________________________________________________ Firenze (Italy) tel. 055/8498428 - fax 055/8498430 TELEFON N° _________________________________________________________ The same rating is fixed on the machine with indication of the machine data and the manufacturer's data.
- Page 8 OPERATING AND MAINTENANCE INSTRUCTIONS PNEUMATIC CRIMPING MACHINE GAMMA Built in year: 2005 Rev. 00...
-
Page 9: How To Use And Keep This Instructions Handbook
These instructions cannot be used as a point of reference for adaptations, changes or adjustments to upgrade the machine from its normal purpose. If this happens ATLA COOPshall be released from any liability. ATLA COOP shall not be liable for circumstances other than defects in materials or workmanship. -
Page 10: Definitions And Terminology
The person will reach this qualification by means of thorough reading of these instructions and training by ATLA COOP Service. -
Page 11: Handbook's Layout
Machines and he/she is qualified for electric works. This qualification enables the person to perform installation, regulation, routine or remedial maintenance works. The person will reach this qualification by means of thorough reading of these instructions and training by ATLA COOP Service. -
Page 12: Updating
It may be also necessary to update the list of the revised pages. In this case, ATLA COOP undertakes to provide the updated revised pages, together with a new copy of their list and the updated table of the revisions there contained. -
Page 13: General Description
GENERAL DESCRIPTION Overall dimensions and technical data The overall dimensions of the complete crimping machine GAMMA are shown in fig. 2-1. The measures are in millimeters. ! NOTE ! While installing ensure 100cm clearance all around the machine to allow user's free movement. - Page 14 1221 Fig. 2.1 Rev. 00...
-
Page 15: Duty
— n° 2 support profiles. Guidelines for Safe Use The crimping machine GAMMA is designed and constructed in compliance with the relevant CE Directives and the safety standards there quoted. In case of malfunctions not forseen or foreseeable in these instructions, please, contact ATLA COOP Service, before operating with the machine. -
Page 16: Specifications
SPECIFICATIONS General Description The machine is designed and constructed for crimping and correct assembly of aluminium profiles through the pneumatically controlled system. The machine operating is semiautomatic, the machining cycle of various units are manual controlled by user who always stays outside danger's area. The macchina is equipped with the foot pedals for the operation control during the machining cycle. - Page 17 1 Machine bed 7 Clamp unit with bracing clamp 2 Air connection- pressure regulator 8 Reference forks unit 3 Safety guard for work area 9 Crimping head 4 Foot pedals 10 Eccentric guide 5 Vertical cylinder for clamping - Support profiles (not shown) 6 Crimping knives Fig.
-
Page 18: Operation
Operation The crimping machine GAMMA is designed and constructed to join and close profile corners through crimping. The entire machining cycle is controlled by pneumatic cylinders built inside the machine bed, exclusive of the vertical cylinder (5, fig. 3.1) put on the worktable. For this reason the machine is supplied exclusively with air supply from outside (6÷7 bar). -
Page 19: Pneumatic System
Pneumatic System The machine is fitted only with pneumatic system whose diagrams are enclosed in this handbook in order to allow complete training and knowledge of the machine (the diagram is complete with the table which describes the parts of it ). Rev. - Page 20 Rev. 00...
-
Page 21: Installation
INSTALLATION Introduction This section contains transport, handling, storage and installation modes of the crimping machine GAMMA. Each of the following paragraphs reviews one of the above-mentioned operations describing the procedures essential to their implementation. Transport and handling Before transporting the machine you must carefully fasten it to a pallet ( fig. 4.1) or pack it in a caseor. -
Page 22: Storing
Pallet Fig. 4.1 Storing In case of storage the machine is designed and constructed for the following climatic conditions: — Storage temperature: min. -25°C and max. +55°C for long-term storage min. -25°C and max. +70°C for short-term storage (max. 24 hours) —... -
Page 23: Installation
! ! CAUTION ! ! ATLA COOP shall not be liable for incidental or consequential damages resulting from the failure to use the machine in accordance with these environmental conditions or in conditions not foreseen in these instructions. Contact ATLA COOP for assistance in case of use under different climatic conditions. -
Page 24: Operating Instructions
OPERATING INSTRUCTIONS Operating commands and control devices The crimping machine is operated exclusively by means of the relevant foot pedals (fig. 5.1). In the legend below you find a description of the pedals functions. Fig. 5.1 Command description fig. 5.1: 1. -
Page 25: Other Commands On The Crimping Machine
Other commands on the crimping machine Besides the foot pedals the machine is equipped with a pressure regulator (1, fig. 5.2) for the regulation of the inlet pressure. The operator can regulate the pressure through the adjusting knob (2) and control his value with the gauge. (3). Fig. -
Page 26: Machining Cycle
Machining cycle The machining cycle to carry out for working different profiles is the following: — Open the safety guard. — Adjust all tools(reference forks, eccentric guides, vertical cylinder for clamping, position of crimping heads and crimping knives) according to the sizes and features of profile to be machined. —... -
Page 27: How To Work A Profile
How to work a profil The machine can work profiles with various sizes and features. Therefore, the user must carry out the machine set up in order to adjust the various tools according to the profile to be machined. The machine adjustings are the following: —... -
Page 28: How To Adjust The Eccentric Guides
5.5.2 HOW TO ADJUST THE ECCENTRIC GUIDES — Open the safety guard. — Loose the screws (1, fig. 5.4) and swing outwards the eccentric guides (2). — Insert a sample profile into the machine and press it against the reference forks. —... -
Page 29: How To Mount And Adjust The Bracing Clamp
5.5.3 HOW TO MOUNT AND ADJUST THE BRACING CLAMP — By closed safety guard activate the bracing clamp through the left pedal (1, fig. 5.1) locking it. — Open the safety guard to move backward the bracing clamp. ! ! ! WARNING ! ! ! Do not interfere in the area of bracing clamp's movement, by opening the safety guard the bracing clamp goes back without re-entering in the machine bed. - Page 30 5.5.4 HOW TO MOUNT AND ADJUST THE CRIMPING KNIVES — Open the safety guard. — Loose four screws (1, fig. 5.6) on the crimping head (2) and adjust the position of head by swinging the screw (3) according to the crimping point of corner's chamber (dimension «d», fig. 5.7) where the reference forks will press.
- Page 31 Upper corner Lower corner Press surface r e f e r e n c e forks Lower corner Fig. 5.7 Rev. 00...
-
Page 32: How To Adjust The Reference Forks
5.5.5 HOW TO ADJUST THE REFERENCE FORKS — Swing the ring nut (1, fig. 5.8) to move the holder (2) of reference forks (3) till you read on the graduated scale (4) the measure that represents the distance («d», fig. 5.7) in mm from the crimping point on the corner. -
Page 33: Guidelines For Safe Use
GUIDELINES FOR SAFE USE General The crimping machine GAMMA is designed and constructed in compliance with the relevant CE Directives and the harmonized safety standards. Therefore, risks have been eliminated or reduced as far as possible during the designing and constructing of the machine, furthermore, these instructions inform the user about every residual risk. -
Page 34: Protective Devices
Protective devices The machine is equipped with fixed guards and interlocking protective devices (safety guards). The fixed guards are made of sheet iron. The interlocking protective device (safety guard) is made of glass and sheet iron in order to allow the visibility of the production process also by closed safety guard. - Page 35 — during the clamp rotation when the clamp goes out from the machine bed and especially when she re-enters still persists the crush hazard between the clamp side and the borders of worktable; for this reason never hold the hands next to the clamp during the rotation (the rotation takes place exclusively with the closed safety guard);...
-
Page 36: Maintenance
MAINTENANCE General This section describes the routine and remedial maintenance operations to be carried out on the machine and contains useful information about possible working defects you might encounter while operating the machine. Routine maintenance operations are planned interventions to be regularly carried out, whereas remedial maintenance operations are interventions to be carried out in order to restore the correct machine working after ruptures, failures and/or malfunctionning. -
Page 37: How To Clean The Machine
7.2.1 HOW TO CLEAN THE MACHINE Clean the whole outside surface of the machine and the pedals using soft cloth slightly dampened with soapy water. Clean the worktable with an aspirator in order to remove dust and scrap . ! ! WARNING ! ! Do not use any type of solvent, such us alcohol or gasoline as they may harm the surface;... -
Page 38: Control Of The Oil Level In The Air Regulator And Filling Up
7.2.3 CONTROL OF THE OIL LEVEL IN THE AIR REGULATOR AND FILLING UP — Through the openings (1, fig. 7.2) of the oil tank (2) check the oil level. — If the oil level is visible (<5 cm) it is necessary to fill the tank as described below: —... -
Page 39: How To Lubricate The Machine
7.2.4 HOW TO LUBRICATE THE MACHINE — Disconnect the machine disconnecting the air pipe from the connection (quick coupling). — Remove the fixed protective devices for access to the leverage system. — Smear with a brush all joints with a small quantity of oil for automatic transmission (use «A.T.F.D. II°... -
Page 40: Troubleshooting
The remedial maintenance( or not programmed maintenance) permits to replace most of the machine components. See the tables enclosed in this handbook for the complete list of spare parts. In case of difficulty in replacing spare parts or in case they may not be available, please, contact ATLA COOP Assistance Service. -
Page 41: Removal Of The Connections
DISMANTLING AND SCRAPPING INSTRUCTIONS Removal of the Connections According to the section 4.4 it is necessery to proceed previously by disconnecting the machine and in particular by disconnecting the pneumatic supply through the quick coupling provided for the purpose. Scrapping Once the machine is out of use it is necessary to dispose it as waste characterized by mechanical components of alloy steel, aluminium, plastic and pneumatic components, which require to be disposed through specialized firms in accordance with the regulations in force in the purchaser's country. - Page 42 ENCLOSED DOCUMENTATION List of the Documents Enclosed in this Handbook These Operating and Maintenance Instructions of the pneumatic crimping machine GAMMA come complete with the following documents, which are separately enclosed because of the possibility of personalizing the machine operating: —Assembly drawing with reference to the components.
