Summary of Contents for Shark Shield Techology Ocean Guardian Freedom+ Surf

Page 2: Table Of Contents
FREEDOM+ Surf User Manual v2.0 Table of Contents 1 Introduction 2 How to Use the Documentation 3 Warnings & Safety Information 4 Quick Start FREEDOM+ Surf Install 5 Attach the Power Module and Turn On 6 Operational LED Status Indications 7 Charging the FREEDOM+ Surf 8 Essential Maintenance and Testing 9 Product Specifications...
Page 3: Introduction
FREEDOM+ Surf User Manual v2.0 1 Introduction Ocean Guardian is for ocean lovers. It is the world’s only scientifically proven and independently tested electrical shark deterrent technology. Sharks have small short-range electrical receptors in their snouts used for finding food. Ocean Guardian’s unique three-dimensional electrical waveform instantly turns sharks away by causing unbearable spasms in these sensitive receptors.
Page 4 FREEDOM+ Surf User Manual v2.0 The all-important antenna electrodes have been designed as a sticker thin adhesive decal, which is applied to the underside of the surfboard. With the Power Module weighing just 250 grams, and the near zero drag of the 500 microns thin adhesive Decal Antenna, there is no impact on surfing performance.
Page 5 When a shark approaches an Ocean Guardian, these electroreceptors are over-sensitized, causing the shark to turn away. Ocean Guardian FREEDOM+ Surf Electrical Fields Ocean Guardian has been scientifically proven and independently tested to be effective at turning sharks away. The following image displays the electronic fields surrounding the FREEDOM+ Surf when active.
Page 6: How To Use The Documentation
FREEDOM+ Surf User Manual v2.0 2 How to Use the Documentation Overview of this User Manual Use this manual to learn how to: Mount your Ocean Guardian unit. · Turn the Ocean Guardian on and monitor operational status. · Manual Conventions Warnings: Instructions that, if ignored, could result in death or serious personal injury caused by dangerous voltages or incorrect operation of the equipment.
Page 7: Warnings & Safety Information
FREEDOM+ Surf User Manual v2.0 3 Warnings & Safety Information 1. Sharks can be dangerous and often unpredictable creatures and we encourage people to use an Ocean Guardian when working in, or enjoying the sea, to minimize the risk of shark attack.
Page 8 FREEDOM+ Surf User Manual v2.0 6. Some bottom-dwelling and non-predatory sharks such as the Wobbygong, Carpet and Port Jackson sharks have limited active Ampullae of Lorenzini. Therefore, the Ocean Guardian may have limited or no effect on these sharks. 7. Power Module Battery Warnings: Do not use any charger other than that specifically provided ·...
Page 9 FREEDOM+ Surf User Manual v2.0 Disclaimer Whilst every effort has been made to ensure the accuracy of this manual we are not responsible for any errors or omissions within it. The product specifications and descriptions within this manual will be subject to improvements and modifications over time without notice, as changes to software and hardware are implemented.
Page 10: Quick Start Freedom+ Surf Install
FREEDOM+ Surf User Manual v2.0 4 Quick Start FREEDOM+ Surf Install Before getting started, ensure you have the following Ocean Guardian FREEDOM+ Surf bundle items: 1. FREEDOM+ Surf Transferable Power Module. 2. Charging Dock with international power adapter charging options. 3.
Page 11 FREEDOM+ Surf User Manual v2.0 Step 3. Slide the antenna down the board and ensure the part of the ribbon cable that wraps around the board rail to the tail pad is no more than 25mm (1”) in front of the most forward left fin. Now peel off the backing of the tape that has an A on it for the bottom electrode.
Page 12 Support when the FREEDOM+ Surf Power Module is not fitted to the kicker. Adjusting Electrode Power Output The power output from the Ocean Guardian FREEDOM+ Surf decal antenna electrodes may affect users in different ways. If an individual is overly sensitive to transmissions from the decal...
Page 13: Attach The Power Module And Turn On
FREEDOM+ Surf User Manual v2.0 5 Attach the Power Module and Turn On 1. Use the supplied hexagonal Allen key to unscrew the two bolts holding the Tail Pad Kicker Support in place if installed and remove 2. Ensure the Power Module is Off, pull back the tail pad and place the Transferable Power Module down (do not slot in) on to the ANTENNA CONNECTOR positioned under the tail pad.
Page 14 FREEDOM+ Surf User Manual v2.0 4. Slide the ON/OFF switch to the left to turn the Power Module On. GREEN LED flashes indicate the charge level of the battery. RED LED flashes indicate low battery and are accompanied by warning tone beeps.
Page 15: Operational Led Status Indications
FREEDOM+ Surf User Manual v2.0 6 Operational LED Status Indications The FREEDOM+ Surf Transferable Power Module has a GREEN LED and RED LED to indicate operation states and the battery charge level. It also provides warning tone beeps in various operation states. LED State LED Indication Start-up Self-check RED LED illuminates for 1 second and then...
Page 16 FREEDOM+ Surf User Manual v2.0 LED Charging Indications LED State LED Indication Charging RED and GREEN LED illuminated Fully Charged RED LED illuminated GREEN LED Off © Ocean Guardian 2018...
Page 17: Charging The Freedom+ Surf
FREEDOM+ Surf User Manual v2.0 7 Charging the FREEDOM+ Surf The FREEDOM+ Surf can be charged using two methods: 1. FREEDOM+ Surf Charging Dock, or 2. FREEDOM+ Surf 12VDC Car Charger. Caution: Thoroughly dry the charger pin area on the Ocean Guardian Power Module before connecting it to the charger.
Page 18 FREEDOM+ Surf User Manual v2.0 External Power Pack 1. Attach the Car Charger to a 12VDC power source and connect it to the FREEDOM+ Power Module. 2. A RED LED illuminates when the power pack is connected to power. 3. A solid RED and GREEN LED illuminates while the Power Module is charging.
Page 19: Essential Maintenance And Testing
FREEDOM+ Surf User Manual v2.0 8 Essential Maintenance and Testing 1. The Ocean Guardian FREEDOM+ Surf electronics should be rinsed in fresh water after use, dried, and stored in a cool, dry place out of the sun. 2. Both connectors should be kept free of dirt and sand at all times.
Page 20 FREEDOM+ Surf User Manual v2.0 Warning: · Thoroughly dry the charger pin area on the Ocean Guardian before connecting the charger. Be especially vigilant when charging the Ocean Guardian immediately after it has been used in water. Under no circumstances should you attempt to repair the ·...
Page 21: Product Specifications
FREEDOM+ Surf User Manual v2.0 9 Product Specifications Product Feature Specification Maximum Operating Depth 50 meters (164 feet) Storage Temperature 0°C - 60°C (32°F – 140°F) Operating Temperature 12°C - 40°C (53.6°F – 104°F) Lower temperatures will reduce operating time Battery pack life Nominal 1000 charges Operating Time (in water)
Page 22: Warranty
FREEDOM+ Surf User Manual v2.0 10 Warranty For Ocean Guardian Products Purchased in Australia & New Zealand: CONSUMER PRODUCT WARRANTY When you purchase an Ocean Guardian product, you have the peace of mind in knowing that your product is covered by Ocean Guardian's Standard Warranty.
Page 23 FREEDOM+ Surf User Manual v2.0 (a). Contact Ocean Guardian to register your claim and provide the details to enable Ocean Guardian to assess the claim. Or visit the Ocean Guardian support section located on the internet, contact details listed below. (b).
Page 24 FREEDOM+ Surf User Manual v2.0 2.2 Ocean Guardian disclaims liability for range, coverage, or operation of the Product and ancillary equipment as a whole under this warranty. Ocean Guardian reserves the right to make changes or improvements in Products, during subsequent production, without incurring the obligation to install such changes or improvements on previously manufactured Products.
Page 25 FREEDOM+ Surf User Manual v2.0 3.0 To the full extent permitted by law but subject always to section 1.1: 3.1 Ocean Guardian will not be liable for any loss, damage or alterations to (1) third party hardware or software; or (2) programs, data or information stored on any media or any part of the product, no matter how occurring;...
Page 26: Accessories
FREEDOM+ Surf User Manual v2.0 11 Accessories Part number: Ocean Guardian FREEDOM+ Transferable Power FRSS-OOA Module Powers the scientifically designed antennas that generate our proven protective shark deterrent E- field. Includes FREEDOM+ Power Module and Charging Dock. Part number: Ocean Guardian / Ocean & Earth Tail Pad SUOE-SBA Ocean &...
Page 27 FREEDOM+ Surf User Manual v2.0 Part number: NSN Ocean Guardian Tester 4220/661582994 Ensure your FREEDOM+ is in perfect working order at all times. Part number: Additional 2 Year Extended Warranty WASS-03A Extend the standard One Year Warranty on your FREEDOM+ to a Three Year Warranty. (excludes accessories) ©...
