PLEASE RETAIN THIS INSTRUCTION SHEET IN YOUR FILES.
PARTS INFORMATION.
INSTRUCTIONS.
IT IS IMPORTANT TO USE AND MAINTAIN ALL PUBLIC PLAYGROUND EQUIPMENT PROPERLY.
EQUIPMENT, WHICH IS IMPROPERLY MAINTAINED, CAN CAUSE SERIOUS INJURY.
INSPECTIONS, MAINTENANCE, REPAIR AND/OR REPLACEMENT OF DAMAGED PARTS IS NECESSARY FOR
SAFE OPERATION OF EQUIPMENT AND SAFETY OF USERS.
UNDER ALL PLAYGROUND EQUIPMENT.
THE CONSUMER PRODUCT SAFETY COMMISSION, INCLUDE "A HANDBOOK FOR PUBLIC PLAYGROUND
SAFETY."
YOU CAN RECEIVE YOUR FREE COPY BY CALLING 1-301-504-7908.
PACKING LIST
1 CTN
4 PIPE
1 563-604
4 PIPE
1 563-215
4 WF
1 563-314
4 PIPE
1 596-614
1 CTN
SportsPlay Equipment, Inc
561-505 Junior Soccer Goal (Pair)
* IMPORTANT *
ALL EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THESE
APPROPRIATE PUBLICATIONS, AVAILABLE AT NO CHARGE, FROM
Hardware Bag
Net Support Posts
Goal Post
Cross Frame
Post Support
4 PIPE
5 TOTAL PCS
., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
IT CONTAINS IMPORTANT REPLACEMENT
RESILIENT SURFACING SHOULD BE USED
HARDWARE BAG
4
105-017
2 3/8" Pipe Plug
4 pr
425-517
1 7/8" T-Clamps
4
116-511
5/16" x 1 ¾" Hex Head Bolt
16
196-802
½" x ½" Socket Set Screw
6
116-604
338" x 1" Hex Head Bolt
6
226-601
3/8" Lock Nut
4
226-501
5/16" Lock Nut
1
416-400
¼" Socket Key
WT 110#
Page
Rev 04/04/03
PLAYGROUND
PERIODICAL
CLASS 70
1 of 1
