- Page 1 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R www.sigagroup.eu...
- Page 2 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R WARNINGS THE MANIFACTURER DO NOT RESPOND TO CHANGES AND ERRORS OF HYDRAULIC AND ELECTRICAL CONNECTIONS. Carefully read this manual before installing and operating the appliance. Keep the manual attentively to be able to consult it to have information about the use and maintenance of the unit.
- Page 3 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R UNIT DESCRIPTION AND DIMENSION HW 070 -090 HW 180 ATING LIMITS um temperature of flow: 70°C um temperature of flow: 4°C um working pressure: 10bar um room temperature: 4° www.sigagroup.eu LLATION ant notice...
- Page 4 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R HW 070 -090 HW 180 HW 070 -090 HW 180 070 / 090 OPERATING LIMITS OPERATING LIMITS OPERATING LIMITS - Maximum temperature of flow: 70°C - Minimum temperature of flow: 4°C - Maximum working pressure: 10bar ...
-
Page 5: Condensate Drain Connection
- Select a location where children can no reach. - Select the place where is strong enough to withstand the full weight and vibrations of the unit and will CSF_HW_TUBE_R_R not increase the noise. - Be sure to leave enough space to allow access for routine maintenance; the height of the installed location should be 2,5m or more from the floor. -
Page 6: Hydraulic Connection
Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R CONDENSATE DRAIN CONNECTION For a good drainage , the exhaust pipe must be positioned with a downward inclination of at least 1-2 For a good drainage , the exhaust pipe must be positioned with a downward inclination of at least 1-2 %. ... - Page 7 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R The incorrect connection and/or the failure to respect the National regulations void the guarantee and any other responsibility of the manufacturer. CLEANING AND MAINTENANCE Before maintenance, make sure the power of the unit is turned off. ...
- Page 8 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R Is the power cord specificed? It may cause electric malfunction or damage the part Is the inlet and outlet pipes beed covered? It may cause insufficiant cooling (heating) capacity MALFUNCTIONS AND CORRECTIVE ACTIONS FAN DOES NOT RUN CORRECTIVE ACTIONS: ...
- Page 9 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R POMPA SCARICO CONDENSA - CONDENSE DRAIN PUMP POMPA SCARICO CONDENSA - CONDENSE DRAIN PUMP POMPA SCARICO CONDENSA - CONDENSE DRAIN PUMP - check that the chiller/boiler and circulation pump are turned on; - bleed the water pipes;...
- Page 10 010817/CSF/HW/BI/EU Инструкция по монтажу MANUALE DI USO TELECOMANDO IR CSF_HW_TUBE_R_R USE MANUAL FOR WIRELESS REMOTE CONTROL USE MANUAL FOR WIRELESS REMOTE CONTROL Il presente telecomando IR è di tipo universale e viene impiegato per il controllo di diverse tipologie di unità...
- Page 11 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R (dehumidification): in this mode, the unit alternates cycles of cooling and ventilation; the operation is automatic: it set alone the fan speed. - FAN (ventilazione): il questa modalità, l'unità funziona solo in ventilazione.
- Page 12 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R LIGHT è utilizzato spegnere/accendere la retroilluminazione dei simboli sul pannello dell'unità; is used ro turn on o turn off the backlight of symbols on front panel of unit. TIMER ON or TIMER OFF sono utilizzati per impostare l'orologio per l'accensione o spegnimenti dell'unità ad orari desiderati, una volta impostati appaiono sul display del telecomando.
- Page 13 010817/CSF/HW/BI/EU Инструкция по монтажу Serie “HW” – SE 10.1-2 + A70/A70D + 1V 01.05.2015 CSF_HW_TUBE_R_R 2015 The constructor’s policy is of continuous improvement, it reserves the right to change design and specifications without notice SE 10.1 (A70) SE 10.2 (A70D)
- Page 14 Installation manual 010817/CSF/HW/BI/EU Инструкция по монтажу CSF_HW_TUBE_R_R SE 10.2 (A70D) www.sigagroup.eu...
