Deer Fence Access Gate Installation Instructions

Table of Contents

Download this manual

A. (2) 1 3/8" Vertical Side Pipe

B. (2) 1 3/8" Horizontal Top/Bottom Pipe

C. (1) 1 3/8" Center Support Pipe

D. (4) 1 3/8" Black Corner Elbows

E. (2) 1 3/8" Black End Clamp (2-sided)

F. Hardware (nuts, bolts, washers, screws)

G. (2) Monofilament Corner Tension Wire

H. (2) 1/8" Wire Clamp

I. (2) 1 3/8" Black Female Hinge

J. (2) 1 5/8" Black Fork Assembly Gate Latch

K. (100) 8" Black Self-locking Fence Ties

L. (1) 1 5/8" Top Spreader Pole

M. (2) 1 5/8" 9ft Side Pole

N. (2) 1 5/8" Black Corner Elbows

O. (2) 1 5/8" Black Male Hinge

Deer Fence Access Gate

Installation Instructions

Table of Contents

Need help?

Do you have a question about the Access Gate and is the answer not in the manual?

Page 1 Deer Fence Access Gate Deer Fence Access Gate Installation Instructions Installation Instructions A. (2) 1 3/8” Vertical Side Pipe B. (2) 1 3/8” Horizontal Top/Bottom Pipe C. (1) 1 3/8” Center Support Pipe D. (4) 1 3/8” Black Corner Elbows E.
Page 2 Deer Fence Access Gate Deer Fence Access Gate Installation Instructions Installation Instructions STEP 1 Lay out the structure of your gate on the ground, using the vertical side pipes (part A), horizontal top/bottom pipes (part B), and center support pipe (part C) (as shown in figure 1).
Page 3 Deer Fence Access Gate Installation Instructions STEP 3 Secure each corner elbow using two self tapping screws (as shown in figure 4). Figure 4 STEP 4 Hook the turnbuckles, located at the end of the corner tension wires (part G) into the center of the corner elbows on the top of the gate (as shown in figure 5a).
Page 4 (as shown in figure 8). Figure 8 STEP 8 Fasten the Deer Fence (not included) to the gate frame using self-locking fence ties (part K) every 6 to 8 inches. Using a tie puller and cutter tool, tighten the ties and trim the excess plastic (as shown in figure 9).
Page 5 STEP 2 Determine where on the fence line you will install your access gate and lay top spreader pole here. Mark the placement for the two 9 feet side poles (part M) accordingly. STEP 3...
