07060EZ/07970C/07060F
Please read the following instructions carefully.
Keep this instruction manual and save for future reference.
For technical support, contact us at 1-401-671-6551
or www.summerinfant.com/contact
Tools required: Phillips-head screwdriver,
measuring tape (not included),
and wrench (included).
For use with children from 6 - 24 months.
Keep small parts away from children.
Adult assembly required.
Fits openings from 29" - 48" wide.
Text "Extra Tall" to 38344 for a demo & install video.
Have questions? We're here to help. For technical support please
contact us at 1-401-671-6551 or www.summerinfant.com/contact.
Multi-Use Extra Tall
Walk-Thru Gate
INSTRUCTION MANUAL
Thank you for purchasing the Multi-Use Extra Tall Walk-Thru Gate from Summer Infant.
This gate allows you to create and maintain a secure environment for your child just about anywhere in
your home. It has a hinged swinging door that opens easily in either direction with one hand,
as well as hold-open and auto-close features for added convenience.
Advertisement
Summary of Contents for Summer 07970C
- Page 1 Walk-Thru Gate INSTRUCTION MANUAL Thank you for purchasing the Multi-Use Extra Tall Walk-Thru Gate from Summer Infant. This gate allows you to create and maintain a secure environment for your child just about anywhere in your home. It has a hinged swinging door that opens easily in either direction with one hand,...
- Page 2 WARNING Children have died or been seriously injured when gates are not securely installed. • ALWAYS install and use gate as directed using all required parts. Install according to manufacturer’s instructions. • Stop using when a child can climb over or dislodge the gate. •...
- Page 3 gate configurations (choose which best fits your scenario) WARNING Measure the width of the opening where you intend to install the gate. • Refer to the following illustrations to determine the correct installation NEVER install two extension configuration. frames on the same side of the •...
-
Page 4: Installation
installation... - Page 5 installation (continued) Make sure door stop is facing desired direction. For top of stair use, door stop must be on stair side of gate. Gate door must open away from stairs. Make sure the bottom IMPORTANT of the gate is completely flush Check locations A and B.
- Page 6 STOP! wall cup/top of stairs installation WARNING Follow these wall cup installation instructions when using gate at TOP OF STAIRS (MANDATORY), or if using wall cups for a standard opening (optional). If opting not to use wall cups for a standard opening, skip ahead to step For use at top of stairs, wall cup installation is MANDATORY.
- Page 7 wall cup/top of stairs installation (continued) Note: If mounting into plaster or drywall, follow this step and use the wall anchors provided.
- Page 8 wall cup/top of stairs installation (continued) Note: The bottom wall cups should rest on the floor.
- Page 9 wall cup/top of stairs installation (continued) IMPORTANT NEVER open gate door over stairs.
- Page 10 wall cup/top of stairs installation (continued) FINISHED!
-
Page 11: Operation
testing the installation operation to unlock gate: hold-open feature:... -
Page 12: Troubleshooting
If you have any questions or need assistance, contact our Consumer Relations Team at 1-401-671-6551 or www.summerinfant.com/contact Summer Infant (USA), Inc. 1275 Park East Drive Woonsocket, RI 02895 USA Colors and styles may vary. 1-401-671-6551 Made in China © 2019 Summer Infant (USA), Inc. 1/19...
