Summary of Contents for NewLine NEO ANGLE 6MM FRAMELESS
- Page 1 INSTALLATION INSTRUCTIONS DANUBE ACRYLIC NEO ANGLE March 2013 DOOR 2 Page 1 of 5...
- Page 2 INSTALLATION INSTRUCTIONS NEO ANGLE 6MM FRAMELESS AND 4MM FRAMED SHOWER DOOR DANUBE, DELTA, SIGNATURE, OCEANIA, CASCADE GENERAL Do not remove the packers fitted at top and bottom of the door between the door panel and the outer frame until instructed, other packing tapes on the sides of panel ‘C’ may be removed now. Do not let the door swing open unsupported during installation.
- Page 3 STEP 1Place wall profiles vertically on wall to STEP 2Place fixed panel on tray and slide over the straddle the drain channel on NEWLINE trays only. outside of wall profile. Push panel back firmly to Silicone the rear face of the wall profile. Secure to wall but do not secure.
- Page 4 the outer door frame and the corner post of the fixed panel to a distance of 300mm, refer Diagram 1. Silicone on the outer edge only. Fix the frame to the corner posts by drilling into the corner post using the predrilled holes in outer frame as a guide.
- Page 5 (not turpentine), reposition the clamp, and refit the door glass. CONTACT US NEWLINE HELPLINE 0508 NEWLINE (0508 639 5463) Phone: 09 444 2053 Fax: 09 4430044 Email: info@ newline.co.nz www.newline.co.nz...
