RCC250T001

VACUUM CLEANER

Model :
RCC-250F
RCC- 250B
RCC-250S
NOV. 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RCC-250F and is the answer not in the manual?

Questions and answers

Related Manuals for DAEWOO ELECTRONICS RCC-250F

Summary of Contents for DAEWOO ELECTRONICS RCC-250F

  • Page 1: Vacuum Cleaner

    RCC250T001 VACUUM CLEANER Model : RCC-250F RCC- 250B RCC-250S NOV. 2005...

  • Page 2: Table Of Contents

    Table of Contents Page 1. Specifications -------------------------------------------------------------- 1 2. External Views ------------------------------------------------------------- 2 2-1. External Components List ---------------------------------------------------- 2 2-2. External Components View -------------------------------------------------- 3 3. Electrical Description (Diagram) ------------------------------------ 4 3-1. Wiring Diagram ----------------------------------------------------------------- 4 3-2. Circuit Diagram ----------------------------------------------------------------- 6 4.

  • Page 3: Specifications

    1. Specification RCC-250B RCC-250F RCC-250S Model RCC-250F RCC-250B RCC-250S Discription Europe 230~240V Rated Voltage 50 ~ 60 Hz Frequency Max.1400 ~ 1800W Input Wattage 486 X 240 X 319 mm Dimension (LxHxD) Cord Length Mirco Filter HEPA Filter Inner Filter...

  • Page 4: External Views

    2. External View 2-1. External Components List Model Name Part Name RCC-250F RCC-250B RCC-250S A : Dust Box ○ ○ ○ B : Main Handle (Cord Rewind Button) ○ ○ ○ C : On / Off Button ○ ○ D : Volume Dial ○...

  • Page 5: External Components View

    2-2. External Components View...

  • Page 6: Electrical Description (Diagram)

    3. Electrical Descriptions 3-1. Wiring Diagram 3-1-1. RCC-250F Wiring Diagram 3-1-2. RCC-250B Wiring Diagram...
  • Page 7 3-1-3. RCC-250S Wiring Diagram...

  • Page 8: Circuit Diagram

    3-2. Circuit Diagram 3-2-1. RCC-250F Circuit Diagram 0.22μ F AC 275V AC 230V 50Hz SWITCH THERMOSTAT MOTOR...
  • Page 9 3-2-2. RCC-250B Circuit Diagram LED PCB LEDJ BTA12 600BW MOTOR 1000μ F 0.22μ F AC 275V AC 230V 200K 50Hz 1N5399 1/2W 1/2W 0.22μ F 5.6V Pressure Switch SWITCH 474K R4 1K THERMOSTAT...
  • Page 10 3-2-3. RCC-250S Circuit Diagram LED PCB LEDJ BTA12 600BW MOTOR 1000μ F 0.22μ F AC 275V AC 230V 200K 50Hz 1N5399 1/2W 1/2W 0.22μ F 5.6V Pressure Switch 474K THERMOSTAT R4 1K...

  • Page 11: Trouble Shooting Guide

    Repair (See 5-1,5-3) or poor contacts in Cord Reel assembly Defective Motor Replace it (See 5-2) Breaking of connections in internal Repair (See 5-1) wiring Breaking of Zener Diode(ZD) Replace it (See 5-1) on PCB Defective Switch (RCC-250F,B) Replace it (See 5-4)
  • Page 12 Trouble Cause Countermeasure Motor does not stop Defective PCB assembly Replace it (See 5-1) even if switch off Power Cord is Broken Reel Spring of Cord Reel Replace it (See 5-3) not wound up assembly Power Cord broke away from Repair (See 5-3) the Bobbin ※...

  • Page 13: Disassembling And Treatment

    5. Disassembling & Treatment 5-1. Cleaner Assembly Cover Top AS Box Dust AS Screw Cover AS Motor AS Cord Reel AS Cap Side AS Body AS Cap Side AS 1) Remove DUST BOX AS - pusing BOX DUST BUTTON 2) Remove 2 CAP SIDE AS - rotating CAP as above 3) Take COVER TOP AS out of COVER AS by using an awl or "-"...

  • Page 14: Motor Assembly

    5-2. Motor Assembly RCC-250B RCC-250F RCC-250S 1) Draw FILTER EXHAUST (#8-9 or #10) in back side of MOTOR AS 2) Unscrew a SCREW (#8) then remove PCB 3) Unscrew 4 SCREWs (#8), Check MOTOR(#1) - whether the motor is burnt out or not.

  • Page 15: Cordreel Assembly

    5-3. Cord Reel Assembly CORD REEL AS 14 15 1) Take CORD REEL AS out of BODY AS -- to be continued in next page...
  • Page 16 2) Before separate BOBBIN(5), CORD PLUG(9) pull out from the pocket of BRACKET(1) and push LEVER CR(2) for reducing the elasticity of REEL SPRING 3) Unscrew a SCREW (#20) and separate BOBBIN(5) from BRACKET(1) and check the contackts between the Y TERMINALS(13,14) and RING TERMINALS(7,8) 4) Check LEVER SPRING(4) 5) If ROLLER BRAKE(3) is worn out and Unscrew a SCREW(5), separate LEVER(2) from BRACKET(1) AND replace ROLLER BRAKE(3)

  • Page 17: Cover Assembly

    5-4. Cover Body Assembly RCC-250B RCC-250F RCC-250B RCC-250B RCC-250S 1) Take HANDLE(#4) out of COVER BODY by using an awl or "-" scerw driver and check them. 2) Unscrew 2 SCREWS (#3) then remove HANDLE ASSY(#2) 3) Take SWITCH(#5), HARNESS SW(#6) out of COVER BODY by using an awl or "-" scerw driver 4) Unscrew a SCREW (#8) then remove SLIDE VOL PCB and check it.

  • Page 18: Hose Assembly

    5-5. Hose Assembly 11 12 1) Unscrew 2 SCREWS (#20) and check whether KNOB(18) is broken or not 2) Check SLIDE VOLUME PCB(#14) 3) Check CONNECTOR & WIRE(#15) 4) Check TERMINALS(#2,#3)

  • Page 19: Brush Assembly

    5-6. Brush Assembly [ Pedal Brush ] 1) Unscrew 4 SCREWS(#15) and separate COVER BRUSH(#1) from BODY BRUSH(#14)

  • Page 20: Exploded View And Part List

    6. Exploded View & Part List 6-1. Cleaner Assembly 6-1-1. RCC-250F Cleaner Assembly...
  • Page 21 Q'nty BODY AS 3620413360 ASSY(RCC-250), NONCURRENT MOTOR CASE AS CORD REEL AS 3629508850 ASSY(RCC-250, EU) PCB POWER CONTROL AS 3624316600 RCC-250F 100~240V SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN COVER AS 3621444580 ASSY(RCC-250A) COVER TOP AS 3621445700 ASSY(RCC-250) HIGH COVER SIDE R ASSY...
  • Page 22 6-1-2. RCC-250B Cleaner Assembly...
  • Page 23 Part Name Part Code Descriptions Q'nty BODY AS 3620413360 ASSY(RCC-250), NONCURRENT MOTOR CASE AS CORD REEL AS 3629508850 ASSY(RCC-250, EU) PCB POWER CONTROL AS 3624316110 RCC-250BN 220~240V/50HZ SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN COVER AS 3621444550 ASSY(RCC-250) LOW COVER TOP AS 3621445800 ASSY(RCC-250E) COVER SIDE R ASSY...
  • Page 24 6-1-3. RCC-250S Cleaner Assembly...
  • Page 25 Part Name Part Code Descriptions Q'nty BODY AS 3620413320 ASSY(RCC-250) HIGH, NONCURREN MOTOR CASE AS CORD REEL AS 3629508850 ASSY(RCC-250, EU) PCB POWER CONTROL AS 3624316040 RCC-2505SN 220_240V/50HZ SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN COVER AS 3621444100 ASSY(RCC-250) HIGH COVER TOP AS 3621444200 ASSY(RCC-250) HIGH...

  • Page 26: Body Assembly

    6-2. Body Assembly 6-2-1. RCC-250F, RCC-250B Body Assembly...
  • Page 27 Part Name Part Code Descriptions Q'nty BODY 3620432100 SOCKET 3629802700 PACKING SOCKET 3624010600 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN BRACKET ROLLER ASSY 3620601900 ASSY BRACKET ROLLER 3620601500 ROLLER FRONT 3624703600 SHAFT ROLLER 3624901000 SWRM SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK ROLLER BACK ASSY 3624708400 ASSY(ABS+PVC)
  • Page 28 6-2-2. RCC-250S Body Assembly...
  • Page 29 Part Name Part Code Descriptions Q'nty BODY 3620432100 SOCKET 3629802700 PACKING SOCKET 3624010600 TERMINAL CASE AS 3628716200 ASSY(RCC-250) HIGH SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN BRACKET ROLLER ASSY 3620601900 ASSY BRACKET ROLLER 3620601500 ROLLER FRONT 3624703600 SHAFT ROLLER 3624901000 SWRM SCREW TAPPING 7128401212...

  • Page 30: Cover Assembly

    6-3. Cover Assembly 6-3-1. RCC-250F Cover Assembly...
  • Page 31 Part Name Part Code Descriptions Q'nty COVER BODY 3621443100 HANDLE ASSY 3622606300 ASSY(RCC-250) HANDLE 3622605900 HANDLE BOTTOM 3622606000 SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN SCREW TAPPING 7128401211 T2S WAS 4X12 MFZN CAP HANDLE 3620905400 SWITCH PUSH 3629002000 7A/250V,(SKT) HARNESS SW 3622716600 ASSY,1015#18,2P...
  • Page 32 6-3-2. RCC-250B Cover Assembly...
  • Page 33 Part Name Part Code Descriptions Q'nty COVER BODY 3621443100 HANDLE ASSY 3622606300 ASSY(RCC-250) HANDLE 3622605900 HANDLE BOTTOM 3622606000 SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN SCREW TAPPING 7128401211 T2S WAS 4X12 MFZN CAP HANDLE 3620905400 SWITCH PUSH 3629002000 7A/250V,(SKT) HARNESS SW 3622716600 ASSY,1015#18,2P PCB S/V AS...
  • Page 34 6-3-3. RCC-250S Cover Assembly...
  • Page 35 Part Name Part Code Descriptions Q'nty COVER BODY 3621443100 HANDLE ASSY 3622606300 ASSY(RCC-250) HANDLE 3622605900 HANDLE BOTTOM 3622606000 SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN SCREW TAPPING 7128401211 T2S WAS 4X12 MFZN CAP HANDLE 3620905400 PCB LED ASSY 3624315950 ASSY(RCC-250) MID SCREW TAPPING 7121301011 T2S PAN 3X10 MFZN...

  • Page 36: Cover Top Assembly

    6-4. Cover Top Assembly 6-4-1. RCC-250F Cover Top Assembly Part Name Part Code Descriptions Q'nty COVER TOP A 3621443100 BUTTON SW 3626609300 SPRING SW 3625114200 HSW3...
  • Page 37 6-4-2. RCC-250B Cover Top Assembly Part Name Part Code Descriptions Q'nty COVER TOP E 3621445100 COVER LED 3621443400 ABS (clear) BUTTON SLIDE VOLUME 3626608900 BUTTON SW 3626609300 SPRING SW 3625114200 HSW3...
  • Page 38 6-4-3. RCC-250S Cover Top Assembly Part Name Part Code Descriptions Q'nty COVER TOP H 3621443300 COVER LED 3621443400 ABS (clear)

  • Page 39: Motor Case Assembly

    6-5. Motor Case Assembly RCC-250B RCC-250F RCC-250S...
  • Page 40 Part Name Part Code Descriptions Q'nty MOTOR UNIVERSAL 396251125Z 220-230V, 50/60Hz, 1500W PACKING MOTOR 3624011000 NR FOAM (ZX) MOUNT MOTOR 3627902100 NR (ZX) CASE MOTOR FRONT 3621109100 CASE MOTOR REAR 3621109200 FILTER CASE 3621912100 PE 3T GUIDE EXHAUST 3622506600 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN FILTER EXHAUST...

  • Page 41: Cordreel Assembly

    6-6. Cordreel Assembly CORD REEL AS 14 15...
  • Page 42 Part Name Part Code Descriptions Q'nty BRACKET CR 3620603500 LEVER CR 3623704200 STOPPER ASSY 3625200200 ASSY SPRING LEVER 3625104300 HSW3 SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK BOBBIN 3629200900 HOLDER TERMINAL 4565A36020 PP(5101SW,V-0) TERMINAL 4565A36024 C2600P-1/2H T0.3 TERMINAL 4565A36034 C2600P-1/2H T0.3 WAX VASELINE 2291140301 VASELINE...

  • Page 43: Cover Side Assembly

    6-7. Cover Side Assembly Part Name Part Code Descriptions Q'nty COVER SIDE R ASSY 3621444300 ASSY(RCC-250) HIGH COVER SIDE L 3621443500 CAP SIDE L 3620905500 COVER SIDE L ASSY 3621444400 ASSY(RCC-250) HIGH COVER SIDE R 3621443600 CAP SIDE R 3620905600...

  • Page 44: Dustbox Assembly

    6-8. Dustbox Assembly 6-8-1. RCC-250F Dustbox Assembly 18-5 18-1 18-4 18-6 18-2 18-3...
  • Page 45 Part Name Part Code Descriptions Q'nty BOX DUST 3620509600 ABS(transparency) HANDLE BOX DUST 3622606100 CLAMP BOX DUST 3621204300 SPRING CLAMP BOX 3625113700 HSW3 CAP ADAPTER 3620905800 ABS(transparency) COVER BOX REAR 3621443700 GASKET BOX REAR IN 3622308500 NR FOAM (PI=3) GASKET BOX REAR OUT 3622308800 NR FOAM(PI=5) BUTTON BOX REAR...
  • Page 46 6-8-2. RCC-250B, RCC-250S Dustbox Assembly 18-1 18-1-5 18-1-3 18-1-4 18-2 18-1-1 18-3 18-1-2...
  • Page 47 Part Name Part Code Descriptions Q'nty BOX DUST 3620509600 ABS(transparency) HANDLE BOX DUST 3622606100 CLAMP BOX DUST 3621204300 SPRING CLAMP BOX 3625113700 HSW3 CAP ADAPTER 3620905800 ABS(transparency) COVER BOX REAR 3621443700 GASKET BOX REAR IN 3622308500 NR FOAM (PI=3) GASKET BOX REAR OUT 3622308800 NR FOAM(PI=5) BUTTON BOX REAR...

  • Page 48: Hose Assembly

    6-9. Hose Assembly 6-9-1. RCC-250F, RCC-250B Hose Assembly [None Current EVA]...
  • Page 49 Part Name Part Code Descriptions Q'nty ADAPTER PIPE 3629101000 CLAMP ADAPTER 3621200900 SPRING 3625102900 HSW3 COVER ADAPTER 3621412400 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK HOSE 3623207200 EVA 1.6M HOLDER HOSE 4569A71021 PP CUFF HOSE 3626800200 HDPE PIPE HOSE 3624408200 VALVE AIR 3625400400...
  • Page 50 6-9-2. RCC-250S Hose Assembly [Current Carrying EVA]...
  • Page 51 Part Name Part Code Descriptions Q'nty ADAPTER PIPE 3629103400 ABS TERMINAL AS 3628710200 TERMINAL+WIRE(YL) TERMINAL AS 3628710400 TERMINAL+WIRE(BR) SPRING 3625102900 HSW3 CLAMP ADAPTER 3621200900 ABS COVER ADAPTER 3621405900 ABS SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK TUBE HEAT SHIRINKAGE 3625700300 TUBE HEAT SHIRINKAGE, 30MM TAPE VINYL 2TU00019BK 19MM BLACK...

  • Page 52: Pipe Assembly

    6-10. Pipe Assembly RCC - 250F RCC - 250B RCC - 250S Part Name Part Code Descriptions Q'nty PIPE EXTENSION 3624408500 PIPE STEEL 3624400910 2 ST, SPC T=0.7(LD=32.6) PIPE STEEL AS 3624411400...

  • Page 53: Brush Assembly

    6-11. Brush Assembly 6-11-1. RCC-250F Brush Assembly [Clean Brush]...
  • Page 54 Part Name Part Code Descriptions Q'nty BODY BRUSH 3620406400 ROLLER-F BRUSH 3624703100 SHAFT ROLLER 3624900900 PICKER LITTER 3622700700 PIPE BRUSH 3624408300 NECK BRUSH 3628001600 ROLLER-B BRUSH 3624703000 COVER BRUSH 3621417200 SCREW TAPPTITE 7171401411 TT2 PAN 4X14 MFZN...
  • Page 55 6-11-2. RCC-250B, RCC-250S Brush Assembly [Pedal Brush]...
  • Page 56 Part Name Part Code Descriptions Q'nty COVER BRUSH 3621420800 PIPE BRUSH 3628304400 NECK BRUSH 3628002100 DUCT BRUSH 3629306300 SWEEPER BRUSH 3629306400 SHAFT SWEEPER 3624901400 HSW3 BUTTON BRUSH 3626604400 SCREW TAPPING 7128408011 T2S 4x8 SPRING BUTTON 3625107300 SK-5, T=0.3 SHAFT ROLLER 3624900900 ROLLER F BRUSH 3624704300...
