Introduction:
The SmartPro Configuration Interface is a handheld flash
pattern programming device for use with Code 3 Ligthbars and
Microsoft PC based systems.
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
Smart Pro Software Installation
Install on Windows version 7, or higher.
1.
Insert flash drive into the computer's USB port.
2.
After locating the flash drive on your computer screen, click on the SmartPro_Configuration_Interface-x.x.x.x (latest version)
executable (.exe) file.
3.
After the program opens, follow the prompts on the screen to complete the installation.
920-0451-00 Rev. A
Operation Instructions
SmartPro Configuration Interface
TM
800-951
Series
Cable
1000+ Series
Cable
USB Cord
Contents:
Software Installation.........................................................01
Configuration....................................................................02
Set-Up Configuration...............................................02
Saving a Configuration File.....................................02
Loading a Configuration File...................................02
Writing Configuration to the Handheld Unit.............02
Reading Configuration to the Handheld Unit...........02
Programming...................................................................03
Programming a Lightbar..........................................03
Reading a Lightbar..................................................03
Troubleshooting...............................................................03
Glossary...........................................................................04
Notes...............................................................................05
Warranty..........................................................................06
Smart Pro
Flash
Drive
Page 1 of 6
Advertisement
Table of Contents
Summary of Contents for Code 3 SmartPro
-
Page 1: Table Of Contents
Operation Instructions SmartPro Configuration Interface Introduction: 800-951 Series Smart Pro The SmartPro Configuration Interface is a handheld flash Cable pattern programming device for use with Code 3 Ligthbars and Microsoft PC based systems. Flash 1000+ Series Drive Cable USB Cord Contents: Software Installation............01... -
Page 2: Configuration
Loading Configuration File Loading a previously saved configuration file can be done in two ways: Double click the .c3c file (also shows the C3 logo) you wish to load and the SmartPro application will launch with that configuration loaded. To manually load a file, go to menu tab File -> Load Configuration and select the file you wish to load. -
Page 3: Programming
Make sure USB is not connected to the computer when Smart Pro is reading from lightbar. Make sure there is no connection to lightbar when USB is connected to the computer and computer is reading the SmartPro. Make sure USB is firmly connected when computer is reading from device Make sure lights on pushbuttons are lighting when pressed. -
Page 4: Glossary
Read Device: SmartPro Configuration Interface reads configurations from the SmartPro handheld device into the PC. Read from Device: SmartPro handheld device reads configurations from the lightbar into the SmartPro. Save Configuration: SmartPro Configuration Interface saves any changes you made to any of the drop down pattern options. -
Page 5: Notes
Notes: Page 5 of 6 920-0451-00 Rev. A... -
Page 6: Warranty
Manufacturer Limited Warranty Policy: Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specifications for this product (which are available from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase. DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA- TIONS, FIRE OR OTHER HAZARD;...
