Dry Contact Closure Interface
LuXout Shades Dry Contact Closure
Contact closure interfaces allows integration of the Automation© systems throughout the house.
The contact closure interface communicates to LuXout Shades via ARC™ RF communication.
Each interface can control one group or one shade using two conductor - one pair #18 AWG
(1.0mm²), class 2 cable.
Many electronic systems and devices have the capability to provide status or control in the form
of dry contact closure (relay/switch) outputs. Each individual device output can be connected to a
contact closure inputs. The contact closure input is programmed from a channel on a LuXout
keypad.
Model Number
Input Voltage
Environment
LuXout
Shades
Job Name:
Job Number:
I N S T R U C T I O N S
Overview
LS-CCI: Wired Contact Closure Input Interface
12V
(from Automation System). 240z12V
Ambient operating temperature: 0°C to 40°C, 32°F to 104°F. Ambient
operating humidity: 0-90% humidity, non-condensing. Indoor use only.
S P E C I F I C A T I O N S U B M I T T A L
Model Numbers:
1221 Admiral Street
Richmond VA 23220
800-817-1204
I-108
LuXoutShades.com
Advertisement
Table of Contents
Summary of Contents for LuXout Shades LSPP-12V-29A-18S
- Page 1 Contact closure interfaces allows integration of the Automation© systems throughout the house. The contact closure interface communicates to LuXout Shades via ARC™ RF communication. Each interface can control one group or one shade using two conductor - one pair #18 AWG (1.0mm²), class 2 cable.
- Page 2 I N S T R U C T I O N S LuXout Low Voltage Plug-In Overview 1). When Do I Charge The Motor? • Our motors are charged when you get them. The charge should last about 500 cycles. (Up-down) •...
- Page 3 I N S T R U C T I O N S Power Panel Installation Instructions Overview LuXout Shade 18 Output Power Panel - For use with LuXout Shades NOTICE: This power supply is built-in fan on/off control circuit. Fan automatically works according to working temperature.
- Page 4 Box Contents: LSPP-12V-29A-18S The Output Power Supply Panel is a surface mount plug in power supply for use with 12 volt powered shades. LSPP-12V-29A-18S simplifies the wiring and organizes installations that require multiple power supplies. 1). Important Notes...
- Page 5 • Mount the Power Panel in a position where it can be easily located and accessed if service or troubleshooting is necessary. • Mount the LSPP-12V-29A-18S in the orientation shown (Mounting Hardware is not provided). Do not mount in any other orientation.
- Page 6 A. SHOCK HAZARD. Risk of serious injury or death. Locate and lock the supply breaker in the OFF position before wiring to the screw blocks. Note: Maximum of 2 LSPP-12V-29A-18S power supplies per 20 A breaker, or 1 per 15 A breaker. 1. Turn power off at circuit breaker.
- Page 7 I N S T R U C T I O N S Power Panel Installation Instructions LSPP-12V-29A-18S 4). Low Voltage Wiring A. SHOCK HAZARD. Risk of serious injury or death. Locate and lock the supply breaker in the OFF position before wiring to the terminal blocks.
- Page 8 I N S T R U C T I O N S Power Panel Installation Instructions LSPP-12V-29A-18S 5). Low Voltage Wiring A. SHOCK HAZARD. Risk of serious injury or death. Locate and lock the supply breaker in the OFF position before wiring to the terminal blocks.
