Suros ATEC Easy Manual

RECOMMENDATION: Once the Suros
®
ATEC console is in position in the
procedure room, the console casters should
be locked by depressing the caster levers.
Locking the console casters will minimize
movement during the procedure.
ATEC ® Set Up and Use
The ATEC
handpiece tray
is designed to
fit comfortably
into the top of
the console.
Spike the saline bag and gently squeeze saline
to ensure unobstructed flow. (Saline can be
viewed in the clear section of tubing on
the saline line.)
Connect the red
handpiece line to
the handpiece
red
receptacle located
on the user
interface. If you
are performing an
ultrasound or stereotactic-guided biopsy, connect
to the red receptacle marked US/STX. If you are
performing an MRI-guided breast biopsy,
connect to the red receptacle marked MRI.
LEGEND
Set Up
®
ATEC Suction Canister Set Up
®
™
Locate both the canister and lid.
red
®
Unfold blue CSR wrap and fold down the
1 edges to expose the console user interface.
Hang the saline bag on the hook located on
the side of the console above the ATEC
5
Footswitch Cord Management Plate.
Power the system on.
Note: The switch is illuminated
green
9
when in the ON "|" position.
Test Biopsy Lavage
ATEC ® Easy-Guide Console Instructions Card
Make sure the
canister lid is tightly
sealed and the large
cap is snapped into
the proper opening.
1
Locate the 4 connection lines at the
®
2 end of the ATEC handpiece tubing.
Insert clear section of saline tubing
®
6
into Saline PV (pinch valve).
Upon system initialization,
10
console defaults to "BIOPSY."
Manual Aspiration Retest Handpiece
The canister and lid assembly
fits into the holder on top of
the console. Connect the blue
®
fitting of the ATEC Vacuum
Line Assembly to the
"VACUUM" port located
on top of the canister lid.
(Make sure the fitting is
blue
2 seated against the canister lid.)
®
Connect the ATEC
handpiece vacuum line
to the "PATIENT"
port of the canister
lid.
3
Connect the black handpiece line to the
black handpiece receptacle located on the
7
user interface.
Choose "SET UP"
and the green
"VACUUM
READY"
light will illuminate
when adequate
vacuum is achieved.
(At this time, verify
the presence of saline
in the tissue filter
and needle aperture.)
11
Vacuum/
Return to Set Up
Vacuum Ready
3
4
8
12
Patient
