  • Page 1 IVS SDA-909 Mounting and Connections...
  • Page 2 Notice Copyright © 2013 RMG Enterprise Solutions, Inc. All Rights Reserved. This publication is protected by copyright and all rights are reserved. No part of this book may be reproduced or transmitted by any means or in any form, without prior written consent from RMG Enterprise Solutions, Inc.

  • Page 3: Table Of Contents

    Important Safety Instructions ....5 Mounting the IVS SDA-909 ..... 6 Attaching the Mounting Plate Simple Wall Mount .

  • Page 4: Fcc Verification, Industry Canada & European Ce Information

    WARNING: Changes or modifications to this device not expressly approved by RMG Networks could void the user's authority to operate the equipment. Industry Canada This Class A digital apparatus meets all requirements of the Canadian Interference Causing Equipment Regulations.

  • Page 5: Important Safety Instructions

    • It is important that your IVS SDA-909 be properly ventilated. Do not fully enclose the IVS SDA-909 in any type of recess, cabinet, kiosk, hole, nook, or enclosure unless there are fans or a passive thermal exhaust that can constantly bring in new air to replace the trapped air in the space around the outside of the device.

  • Page 6: Mounting The Ivs Sda-909

    Mounting the IVS SDA-909 The IVS SDA-909 includes hardware for installing the unit in a simple wall mount configuration or at the back of a VESA-compliant display. Do not throw away any cables, adapters, or other hardware that you might receive with the product—you may need them for future use if you should ever upgrade the IVS SDA-909.

  • Page 7: Attaching The Mounting Plate

    Attaching the Mounting Plate You can attach the mounting plate to the IVS SDA-909 on either its top or bottom side. The orientation in which you want to mount the IVS SDA-909 determines which side to attach the mounting plate.

  • Page 8: Simple Wall Mount

    Simple Wall Mount It is important that your IVS SDA-909 be properly ventilated and placed in a location with the ambient temperature between 32 °F to 104 °F (0 °C to +40 page 5 °C). See for specific details. To install the IVS SDA-909 on a wall,...

  • Page 9: Vesa-Compliant Display Mount

    VESA-Compliant Display Mount It is important that your IVS SDA-909 be properly ventilated and placed in a location with the ambient temperature between 32 °F to 104 °F (0 °C to +40 page 5 °C). See for specific details. The IVS SDA-909 mounting plate is...
  • Page 10 2. Use a Phillips screwdriver and four M9 bolts (supplied) to secure the mounting plate to the back of the display. page 3. Attach the IVS SDA-909 to the mounting plate using the steps on Connections on Top Exhaust Vents...
  • Page 11 4. (Optional) If you are using wireless Leave antennas communications, attach the two fully extended or bend to 90°. antennas to the connections at the top of the unit. (Pages illustrate the space requirements for the antennas when fully extended or bent at a 90°...

  • Page 12: Connecting The Ivs Sda-909

    Connecting the IVS SDA-909 IVS SDA-909 Diagram The following diagram demonstrates how to connect your IVS SDA-909 model. (A key Table 1 on page 13.) to the numbered parts is shown in Left Side View Front View Right Side View...
  • Page 13 TABLE 1: IVS SDA-909 Functions Item # Description USB 2.0 x (2) 2a, 2b Intake Vents Power Indicator (White) Power Button HDD Indicator (Blue) AC Input RS-232 Serial Connector 8a, 8b Wireless Antenna Connectors 9a, 9b Exhaust Vents USB 2.0 x (2)

  • Page 14: Step-By-Step Connections For The Ivs Sda-909

    HDMI connector on a display device. 3. Connect the female end of the power cord to the three-prong connection at the back of the IVS SDA-909 (6). Plug the other end of the power cord into a standard AC outlet.

  • Page 15: Ivs Sda-909 Specifications

    IVS SDA-909 Specifications Physical Dimensions Without Antennas or Mounting Plate Dimensions (W) x (H) x (D): Weight: .90 kg (1 lb., 15.8 oz.) 165.1 mm x 41.28 mm x 108 mm (6.50” x 1.625” x 4.25”) 165.1 mm (6.5") Front View 165.1 mm...
  • Page 16 117.48 mm (4.625") 108 mm (4.25") Left Side View 9.5 mm (.375") 117.48 mm (4.625") 108 mm (4.25") Right Side View 9.5 mm (.375")
  • Page 17 With Mounting Plate & Antennas Fully Extended Dimensions (W) x (H) x (D): Weight: 1.07 kg (2 lbs., 5.8 oz.) 165.1 mm x 41.28 mm x 222.25 mm (6.5” x 1.625” x 8.757”) 114.3 mm (4.5") 108 mm 108 mm (4.25") (4.25") 6.35 mm...
  • Page 18 With Mounting Plate & Antennas Bent at 90° Dimensions (W) x (H) x (D): Weight: 1.07 kg (2 lbs., 5.8 oz.) 166 mm x 95 mm x 194 mm (6.53” x 3.75” x 7.625”) 114.3 mm (4.5") 108 mm (4.25") 22.23 mm (.875") 6.35 mm...
  • Page 19 With Mounting Plate Dimensions (W) x (H) x (D): Weight: 1.05 kg (2 lbs., 5.1 oz.) 177.8 mm x 41.28 mm x 117.5 mm 7.0” x 1.625” x 4.625”) 6.35 mm 6.35 mm (.25") (.25") 9.53 mm (.375") 165.1 mm (6.5") 177.8 mm (7.0")

  • Page 20: Hardware Components

    Hardware Components Front Panel IO Power Button: Disk Activity Indicator (blue): Power indicator (white): USB 2.0 Port: Audio Type: HDMI LAN: 10/100/1000 Gigabit Rear Panel IO DC Jack: HDMI port: USB 2.0: Serial DB9 (COM Port): x1 (For RS-232 Screen Control) Wireless Antenna Connection: 802.11 a,b,g,n (2 x rear external antennas)

  • Page 21: Power Requirements

    Power Requirements AC Input Frequency: 50/60Hz AC Input Voltage: 100 ~ 240VAC Current: 1.3-0.8A Power Consumption: (Maximum) 42W Operating Specifications Air Flow Volume (cubic feet/minute): @ 50% System Loading 1.6CF, @ 100% System Loading 2.89CFM Heat Dissipation: 143 BTU (Maximum) Mean Time Between Failures (MTBF) MTBF (Hour): 30,000 hours (continuous operation)

  • Page 22: Getting Help And Support

    Getting Help and Support Contacting Technical Support If you experience problems using your IVS SDA-909, please contact RMG Networks. Our main Web site is http://www.rmgnetworks.com. • North American Customers - Contact RMG Networks Technical Support between 7:00 a.m. and 7:00 p.m., Central Standard Time (CST).
