FUTABA S9070 Program Manual

FUTABA S9070 Program Manual

Programmable servo
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

USB INTERFACE
S9070 PC-Link Program Manual
The operating parameters of the Futaba programmable servo S9070 can be set and
changed from a PC by using this program. Since the Futaba CIU-2 USB adapter and
power supply (4.8~6V battery) and Y-harness (landing gear adapter) are necessary,
procure them beforehand and place into the state in which the CIU-2 is operated
properly from the PC. (Download and install the CIU-2 driver from the Futaba home
page.)
*Note:The S9070 PC-Link program is for Windows
not compatible with other OS.
Downloaded Zip file extraction (decompression) ..............................P2
CIU-2 and S9070 connection ...............................................................P2
Calling the setting parameters ............................................................P3
Changing the parameters ....................................................................P4
Description of the function of each parameter ..................................P5
Setting range of each parameter .........................................................P6
®
Vista/XP/2000 use and is
1M23Z00702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S9070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FUTABA S9070

Summary of Contents for FUTABA S9070

  • Page 1: Table Of Contents

    S9070 PC-Link Program Manual The operating parameters of the Futaba programmable servo S9070 can be set and changed from a PC by using this program. Since the Futaba CIU-2 USB adapter and power supply (4.8~6V battery) and Y-harness (landing gear adapter) are necessary, procure them beforehand and place into the state in which the CIU-2 is operated properly from the PC.

  • Page 2: Downloaded Zip File Extraction (Decompression)

    With Windows Vista/XP, double click file S9070 PC-Link Eng V100 to display its contents. Click "Extract all files". The Extraction Wizard launches. Extract (decompress) Zip file S9070 PC-Link Eng V100 to the same location as the Zip file storage location. PC-Link.exe file is extracted. CIU-2 and S9070 connection Connect S9070, CIU-2 USB adapter, 4.8~6V battery and Y-harness as shown below.

  • Page 3: Calling The Setting Parameters

    S9070 PC-Link Calling the setting parameters When PC-Link.exe file is executed, the "Futaba PC-Link for S9070" dialog box shown at the right will be displayed. To read the current parameters, click the "Read" button. The currently programmed parameters will be displayed.

  • Page 4: Changing The Parameters

    S9070 PC-Link Changing the parameters Slide Knob Check Box When the slide knob of each item on the screen is changed, the set value is changed. When setting an exact value, the value can be changed in minimum units by PC ← ←...

  • Page 5: Description Of The Function Of Each Parameter

    S9070 PC-Link Description of the function of each parameter • Neutral Offset The neutral position can be changed. • Speed Control Speeds can be matched by specifying the operating speed. The speed of multiple servos can be matched without being affected by motor fluctuations. This is effective for load torques below the maximum torque.

  • Page 6: Setting Range Of Each Parameter

    S9070 PC-Link Setting range of each parameter • Neutral Offset: ±30˚ based on the default position • Speed Control: Max. 0.12sec/60˚ (at 7.2V) ~12sec/60˚ • Dead Band: 0.03~3.98˚ • Travel Adjust: 55~175% • Anti-Fluttering Level: Mode 1~Mode 5 • Reverse: Normal/Reverse •...
