Summary of Contents for Syride Sys'ky
- Page 1 ® Sys’ky User Guide Guide d’utilisation Guíadelusuario...
- Page 2 As a member of the community, you'll be a key player in the evolution and continuous improvement of the product. The range of innovative sensors included in the Sys'ky allows the development of future functions... We encourage you to share your suggestions for your greater satisfaction.
-
Page 3: Table Of Contents
Contents Installing Syride communication software Mounting the product on the sail III. Recharging the battery Configurations Advanced configurations Tracking a flight VII. Knowing the GPS Status VIII. Deleting a flight Warning message Transfering flight data Parameters XII. Suggestion of use... -
Page 4: Installing Syride Communication Software
Follow the instructions to install it on your Windows PC / Linux or MAC OS. An icon is located in the task bar to 10:39 detect the connection of the Sys'ky on a USB port. The software will automatically start with your operating system. -
Page 5: Mounting The Product On The Sail
Position the base the lowest possible to avoid messing with the accelerator. You can secure the Sys'ky at the base from a strap in the hole provided for this purpose. The position of the Sys'ky makes maneuvering possible in flight with gloves and without letting go. -
Page 6: Recharging The Battery
III. Recharging the battery Simply connect your Sys’ky USB cord behind the cache on a the USB outlet to a computer. You can view the status directly on the CHARGING… screen of your SYS. The full charge lasts 2 hours. When your battery... -
Page 7: Configurations P5
Configurations Press the Central button and the right arrow to access the main menu. START In the main menu, press the central key once you're on "SETUP".. SETUP The "Info" screen informs you of the Sys - ky State of battery charge, the amount of Battery : 80% Memory : 87% memory remaining, the GPS reception... - Page 8 "BEEPER CONFIG" screen changes the sound parameters of the Beep down : OFF variometer: Beep up : ON Beep down = enable the pager when you get down Accelero. : ON Beep up = activate the pager when you get up Accelero.
-
Page 9: Advanced Configurations P7
Advanced configurations In the main menu, press the central key once you're on "SETUP”. SETUP In the setup menu, press the central once you're on "ADVANCED SETUP”. ADVANCED SETUP You can change the up sensitivity. You can settle it by pressing the center 0.5m/s button. - Page 10 The filtering smoothes the variometer informations to make it more reliable. Medium The reaction time will be impacted. low = filtering on 0.5sec (reagent but risk of FILTERING nuisance tripping.) medium = filtering on 1sec (normal configuration) high = filtering on 1.5sec (less reactive, little nuisance tripping)
- Page 11 Flight tracking Press on the central key and the right arrow to access the main menu. START Before taking off, press on the central key once you are on « New Flight ». the recording starts… NEW FLIGHT Fly and give it the best! The screen «...
- Page 12 « ALTERNATIVE SCREEN » indicates G-force (see 1856m http://paragliding.syride.com/support.ph 0h13m p?faqCat=3&faqQuestion=5 Flight time depends on your configuration : ALTERNATIVE SCREEN altitude, speed and smoothness. 4,3m You can record a geographical point by pressing the central key when on +250ft «...
-
Page 13: Knowing The Gps Status
VII. Knowing the GPS Status The very first GPS reception can take up to 20 minutes (only outside). We recommend turning on your Sys’ky on a few minutes before taking off until you have GPS reception. GPS status is trackable permanently on the top right of the screen: blinking : searching for reception NEW FLIGHT... -
Page 14: Deleting A Flight
VIII. Deleting a flight In the main menu, press on the central key when you are on « Delete Flight ». FLIGHT INFO FLIGHT #1 DATE 25 nov. Choose with the directional arrows START TIME 13h56 which flight you wish to delete. DURATION 0h13m12s DEL FLIGHT Validate by pressing the right key. -
Page 15: Warning Message P13
Warning message Posts at the start of use or during usage. The battery is at 10% and recharging is necessary. Memory < 10% Posts if the Memory is 90% full. You need to transfer or delete flights. Posts when the Memory is full. Transfer or delete flights. Memory FULL If the temperature flickers, it means the temperature exceeds 50°C/120°F. -
Page 16: Transfering Flight Data P14
Click on Options and Setup. To use the advanced flight analyzer on syride.com, you muste enter your email and password of your Syride account ( http://paragliding.syride.com Otherwise check "Keep a copy of IGC files on my computer” and click “OK”. - Page 17 Validate sending the data by clicking « send flights ». Go on your profile on the Syride website to input the flight information. Click the « visible » box if you do not wish to show this flight in the public profile.
- Page 18 You can look at your personal evolution on the flight page through locaiton and time. You can also compare your stats and performances to the other riders!
-
Page 19: Parameters
Parameters Here is a list of parameters preprogrammed in your Sys’ ky in order to imrpove its use and autonomy: The maximum flight time is 10 hours. When recording, in case of no mouvement at all of the Sys’ky for more than minutes, your Sys’ky will go back to the main menu. -
Page 20: Suggestion Of Use
XII. Suggestion of use We recommend turning on your Sys’ky on a few minutes before taking off until you have GPS reception. Click « New Flight » to record only when you are going to take off. Holes on each side of your Sys’ky allow you to secure it on its base using a string. - Page 21 The soaring in the Antarctic is not guaranteed!! check with local authorities Ensure that the product is well in position before taking off. Syride cannot DO NOT ATTEMPT RECHARGING THE DEVICE WITH A DIFFERENT be held responsible for the loss of the product during the flight (takeoff USB CORD THAN THE ONE PROVIDED.
- Page 22 2.0/1112...
