Vogel E+471 Instructions Manual

Control and Monitoring Units
for Centralized Lubrication Systems
Functions and Operation of the Universal Control Unit
Introduction
The product described in these instructions is a control and
monitoring unit for VOGEL central lubrication systems on station
ary industrial installations. It is supplied either as a constituent
part of VOGEL's compact lubrication units or individually for
installation in a switchgear cubicle.
The Universal Control Unit is the foundation of all our new con
trol and monitoring units, and it can also replace all the
switchgear cubicle units in use to date. Since the control func
tions can differ considerably, depending on the installation and
Application, various models based on the Universal Control Unit
are available with functions corresponding to those of the control
units employed to date. The former designations for the individ
ual models have, for the most part, been retained.
The VOGEL Universal Control Unit for industrial lubrication
systems is built to conform to the generally recognized state of
the art, and it complies with the applicable industrial safety and
accident prevention regulations.
Versions of the VOGEL Universal Control Unit
for industrial installations
Designation Brief description
Model E+471 Housing for installation in switchgear cubicle,
selectable operating voltage
100 .. 120 V AC or 200 .. 240 V AC
Model I+471 Housing installed in compact unit,
selectable operating voltage
100 .. 120 V AC or 200 .. 240 V AC
Model E+472 Housing for installation in switchgear cubicle,
operating voltage 20 .. 24 V AC or DC
Model I+472 Housing installed in compact unit,
operating voltage 20 .. 24 V AC or DC
Our control units conform to the generally applicable standards.
Universal Control Unit
Leaflet overview
Control units for progressive systems
Control units for oil+air lubrication
Control units for single line systems
www.vogelag.com
1 1700 1 US
1 1700 2 US
1 1700 3 US
1 1700 4 US
