- Page 1 FirstLine P FirstLine P 924 BATTERY CABINET USER MANUAL 003-2551 REV B...
- Page 2 No reproduction of any part of this manual, even partial, is permitted without the authorization of Staco Energy Products Company. The Staco Energy Products Company reserves the right to modify the product described herein, in order to improve it, at any time and without notice.
-
Page 3: Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS This manual contains important instructions for FirstLine P Battery Cabinets that should be followed during installation and maintenance of the battery cabinet. Please read all instructions before operating the BATTERY CABINET and save this manual for future reference. - Page 4 DANGER This Battery Cabinet contains LETHAL VOLTAGES. All repairs and service should be performed by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER SERVICEABLE PARTS inside the Battery Cabinet. WARNING To reduce the risk of fire or electric shock, install This Battery Cabinet in a temperature and humidity controlled, indoor environment, free of conductive contaminants.
-
Page 5: Firefighting Measures
Emergency Interventions The following information is of a general nature. First aid interventions Company regulations and traditional procedures should be followed for any first aid intervention that may be required. Firefighting measures 1. Do not use water to put out a fire, but only fire extinguishers that are suitable for use with electrical and electronic equipment. -
Page 6: Table Of Contents
7 Specifications............................ 13 Figures Figure 1 – Battery Storage Duration ......................1 Figure 2 – FirstLine P Battery Cabinet Layout ..................2 Figure 3 - Pallet Mounting Hardware ....................... 3 Figure 4 – Electrical Connections ......................4 Figure 5 - Circuit Breaker Interface Board Assembly Location ..............7 Figure 6 - Circuit Breaker Interface Board Assembly ................ -
Page 7: Battery Cabinet Setup
1 Battery Cabinet Setup 1.1 Storage The batteries in your Staco system were shipped from the factory fully charged. If you plan to place the batteries in storage for any period of time prior to installation and startup then the following precaution should be followed. -
Page 8: Floor Loading
The approximate weights are shown in Table 9. 1.4 Clearances The following clearances are recommended for the FirstLine P Battery Cabinet. From Front of Cabinet 36” (91.4 cm) working space From Back of Cabinet 0”... -
Page 9: Installation
2 Installation 2.1 Unpacking The following tools are required for unloading the cabinet(s): Wrenches for 3/8” lag bolts. Forklift or pallet jack Phillips screwdriver WARNING The Battery Cabinets are heavy (see Table 9). Unloading the cabinets requires at least two people to safely remove the cabinets from the pallet. -
Page 10: Electrical Installation
2.2 Electrical Installation The FirstLine P Battery Cabinet has the following power connections: 2-pole (positive, negative) terminal block and ground connection for battery power input and output. Each pole has compression lug holes. One connection goes to the UPS or to the next Battery Cabinet closer to the UPS. -
Page 11: Wiring Preparation
5. Before working within the UPS cabinet, verify that the UPS has no power applied. Refer to the UPS manual. Repeat procedures 3 and 4 to the FirstLine P UPS Battery connector located in the right side of the UPS. We recommend that the wires be marked as to which is positive (+) and negative (-) to ensure that the wires are not accidentally crossed. -
Page 12: Circuit Breaker Interface
2.3 Circuit Breaker Interface Figure 5 shows the location of the circuit breaker interface terminal blocks in the Battery Cabinet. The circuit breaker interface must be connected to the UPS if it is desired to have the Battery Cabinet circuit breaker trip when the Remote Emergency Power Off (REPO) signal is applied to the UPS. Additional Battery Cabinets must connect to the pass-through connection provided for this function (see Figure 8). -
Page 13: Figure 5 - Circuit Breaker Interface Board Assembly Location
Figure 5 - Circuit Breaker Interface Board Assembly Location ATTENTION ELECTROSTATIC SENSITIVE DEVICE R1 R2 FLU-P SHUNT TRIP BOARD ASSY NO.: 825-0593-LF PRODUCTS CO. Figure 6 - Circuit Breaker Interface Board Assembly Figure 7 - UPS REPO Connections P a g e... -
Page 14: Figure 8 - Battery Cabinet To The Ups Remote Emergency Power Off (Repo) Switch Interface
Figure 8 - Battery Cabinet to the UPS Remote Emergency Power Off (REPO) Switch Interface P a g e... -
Page 15: Operation
3 Operation Refer to the UPS manual for operating instructions. Please note that the breaker in the battery cabinet must not be operated until the UPS has started and the display no longer shows the message: "Wait: DO NOT connect the BATTERY". If the breaker has been improperly operated, a qualified service person needs to check for blown fuses or other damage. -
Page 16: Battery Removal, Installation, And Service
5 Battery Removal, Installation, and Service Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions. Keep unauthorized personnel away from batteries. Always wear eye protection and have eye wash near at hand. Never work on any connections that have not been disconnected from all other sources of voltage. -
Page 17: Maintenance
6 Maintenance The FirstLine P Battery Cabinet is designed to be virtually user maintenance free, requiring only the occasional wipe with a damp cloth or non-abrasive cleaner. Spare parts kits are available for the FirstLine Battery Cabinet series, please contact Staco Energy Products Co. -
Page 18: Figure 10 - Cabinets Schematic
Figure 10 – Typical Cabinets Schematic 12 | P a g e... -
Page 19: Specifications
7 Specifications Table 5 – Factory Breaker & Fuse settings MODEL Breaker Fuse FLU-P-BAT-200-1 FLU-P-BAT-200-2 (2) 150 FLU-P-BAT-390-1 FLU-P-BAT-540-1 FLU-P-BAT-620-1 I1: Set to max I3: set to max Table 6 - Input / Output Cable Size and Torques Wire Size Torque Hardware (2) 350kcmil...
