PATHLIGHT
LED LUMINAIRE SSL1, ISL1, ISL2 & BOLLARDS
I N S T A L L A T I O N
Before
beginning
installation, disconnect electrical power
at main switch or circuit breaker.
A.
CAUTION
To reduce the risk of fire, electric shock,
and
potential
damage
housing assembly when electrical power
is re-connected, DO NOT ATTEMPT TO
CONNECT the following on branch circuit
serving pathlight assembly:
•Motors •Power tools •Extension cords
•Appliances or similar electronics
Fixtures to be mounted in conditions where
ambient temperatures do not exceed 40°C.
Ensure AC input voltage is protected against
surges & load shifts prior to power supply
input.
B.
SAFETY INSTRUCTIONS
1.
Read
installation
completely
installation.
2.
Failure to follow instructions may
result in improper installation and
void warranty.
Contact Lucifer Lighting Company
3.
with any questions or concerns
before beginning any installation.
4.
Ensure qualified electrician will
perform all electrical procedures.
Disconnect
5.
circuit before attempting to install
pathlight or power supply.
any
pathlight
to
recessed
instructions
before
attempting
electrical
power
This product must be installed in
accordance with applicable electrical
and installation codes by a person
familiar with the construction and
operation of the product and the
hazards involved. "CAUTION– RISK OF
FIRE"
C.
DESCRIPTION
Pathlights are Class II LED luminaires
for
discreet
residential, commercial and hospitality
applications. Durable precision milled
316 stainless steel or brass casting.
D. RECOMMENDED SPACING
Optimum 18" (457mm) above walking
surface;
36"
spacing for SSL1 & ISL1; 60" (1524mm)
on-center spacing for ISL2 .
E.
POWER
Luminaires require factory-supplied
24-Volt DC power supply, specified
separately.
mounted
power
available.
Secondary
dependant of selected power supply.
Fixtures supplied with 6" lead of 18
gauge wire.
1
path
lighting
(915mm)
on-center
Integral
and
supply
run
for
remote
options
lengths

Advertisement

loading
Need help?

Need help?

Do you have a question about the SSL1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LUCIFER SSL1

  • Page 1 PATHLIGHT LED LUMINAIRE SSL1, ISL1, ISL2 & BOLLARDS This product must be installed in I N S T A L L A T I O N accordance with applicable electrical and installation codes by a person Before beginning pathlight familiar with the construction and installation, disconnect electrical power at main switch or circuit breaker.
  • Page 2: Power Supplies

    F. POWER SUPPLIES 1. REMOTE POWER SUPPLIES Class 2 remote power supplies accommodate varying quantities of fixtures. Power supply must be located in a readily accessible location for future servicing. REMOTE POWER SUPPLY OPTIONS PART # Part ID PSA-24V-60-XAT2 PSA-24V-XX-XXXX UBB-JCT-24V-60-XAT2-XXX Class 2 power supply dimmable via 0-10V analog, reverse phase or forward phase.
  • Page 3 2. INTEGRAL POWER SUPPLY When specified with integral power supply, universal back box or Bollard feature mounting for 1 fixture. Universal back box power supply can support multiple fixtures. Separate mounting components required for each fixtures.
  • Page 4 Minimal tolerances exist between fixture and mounting component, cutout dimensions are critical. Part numbers & Images depicted through this guide are applicable of SSL1 & ISL1. 1. MOUNTING PLATES - DRY / DAMP, WET AND CONCRETE POUR LOCATIONS SSL-UMP: Compatible with two-gang switch box or 4-square junction box for Dry / Damp locations and weatherproof single or two gang box for Wet and concrete pour locations.
  • Page 5 SSL-SC3: Stud-mount collar, adjusts from 1/2” to 3”. Features 1/2” knockouts. SSL-SC6: Stud-mount collar, adjusts from 3” to 6”. Features 1/2” knockouts. 0.69”(18mm) SSL-RM SSL1 & ISL1: 2.40” (62mm) Insert collar into cutout flush with square cutout finished substrate; fold tabs over ISL2: 2.40”...
  • Page 6 5. UNIVERSAL BACK BOX - WET AND CONCRETE POUR LOCATIONS Can be specified with integral or remote power supply, supplied with hanger bars or brackets, specified on order. SSL1 & ISL1 mount horizontally or vertically, ISL2 mounts horizontally only. SSL1 & ISL1: 2.40” (62mm) square cutout. ISL2: 2.40” (62mm) H X 4.10”...
  • Page 7 6. BOLLARD - DRY / DAMP AND WET LOCATIONS Freestanding mount, receives luminaire for flush installation, available with integral or remote power supply. Mounting option specified on order. Ensure all wiring is installed prior to bollard installation. 0.88”(22mm) Four 0.28”(7mm) KOs for wiring bolt holes Base is bolted directly to mounting...
  • Page 8 H. WIRING Access wiring compartment by removing lid and lid retaining screws. Insert line, load and control voltage wires with appropriate conduit or strain relief fittings through knockouts. Connect primary and control wiring to power supply. Run secondary low voltage wiring to each fixture location in either home run or parallel method.
  • Page 9 I. LUMINAIRE INSTALLATION Place self-adhesive gasket on back of luminaire for wet locations. Connect pin connector of pathlight to lead wire connector supplied by factory (see wiring on page 8). Note: Gasket not used on Bollard or Surface Mount Box Gasket (Adhesive Side) Push wires into cavity / junction box and insert fixture as shown below, applying...
  • Page 10 Depression Remove 3 hex screws and separate LED assembly from fixture. Replace with OEM LED assembly sourced through Lucifer Lighting. Ensure O-ring seats properly and screws are tightened. Replace gasket, connect pin connector and push fixture into mounting location. If Locking (Wet location), tighten 2 screws located inside fixture aperture.
  • Page 11 SERVICING UBB STEP 1 Wiring Compartment Access Panel Remove fixture from UBB, see Section I. STEP 2 Insert flathead screwdriver through the brackets on the wiring compartment access panel and pry it towards the driver assembly and remove it through the aperture ( Fig.1 ). STEP 3 Brackets Disconnect line/mains and control...
  • Page 12 SERVICING PS-RMT STEP 1 Remove screws securing lid to enclosure ( Fig.4). STEP 2 With lid removed, disconnect line/mains, load and control wiring from driver. STEP 3 Remove power supply retaining clamps/ Fig.4 screws/nuts as apply. STEP 4 Remove and replace driver assembly ( Fig.5).
  • Page 13 DRIVER WIRING DETAIL Red (+) 120-Volt Lucifer Lighting Power Supply Reverse / Forward Hot / Black “AT2” Reverse Phase Driver Phase Dimmer “L22” Light Lutron Hi-Lume A Series Neutral / White Engine Forward Phase Control Driver Ground Black (-) Purple...
  • Page 14: Limited Warranty

    L I M I T E D W A R R A N T Y LUCIFER LIGHTING COMPANY (Seller) warrants that for a period of one (1) year from date of sale to the first non-retail purchaser, Seller will repair or replace, at the Seller’s sole option, free of charge, any defective products purchased from Seller provided that prior authorization is obtained from the Seller and the products are sent prepaid to the Seller’s manufacturing facility.
