Date
Ref. No.
03.09.08
08TV025R5
Subject
Software Upgrading Procedure [REVISION 5]
SYMPTOM
•
This Technical Bulletin describes the software upgrading procedure for the EG-1L chassis, using a Memory
Stick.
•
Amongst others, the latest software version is needed when exchanging the BE1 board, which requires an
update of the MS DL Digital, VCTP, NVM VCTP & Verd data.
SOLUTION
•
Follow the outlined procedure below for upgrading to the latest software version, using the attachment to
Technical Bulletin 08TV038.
•
An alternative update (cf. "4. Alternative update (when no LED activity)") may be needed. In that case, use the
"eg1l_aep_pkg_103_memorystick.zip" file attached to this Technical Bulletin.
! IMPORTANT !
Only use the attachment "eg1l_aep_pkg_103_memorystick.zip" in case a regular update fails.
1. TT number application
1-1. Apply the TT number depending on the model, referring to the table below.
Model
EG-1L Chassis
Model
TT number
KDL-32E40xx
TT22
KDL-32W40xx
TT24
KDL-32W42xx
KDL-40E40xx
TT23
KDL-40W40xx
TT25
KDL-40W42xx
KDL-46W40xx
TT26
KDL-46W42xx
KDL-52W40xx
TT61
KDL-52W42xx
KDL-26E40xx
TT21
KDL-26V45xx
TT62
KDL-26V47xx
KDL-32V45xx
TT63
KDL-32V47xx
KDL-37V45xx
TT64
KDL-37V47xx
Sony Europe (Belgium) NV
Customer Satisfaction Europe
Quality & Service Engineering
Technical Bulletin
BE1 board
A-1556-411-A
(Complete FHD)
A-1544-103-A
(Complete FHD WCG)
A-1556-412-A
(Complete WXGA)
TD
IRIS
1 / 4
Advertisement
Related Manuals for Sony KDL-32E40 Series
Summary of Contents for Sony KDL-32E40 Series
- Page 1 TT25 KDL-40W42xx A-1544-103-A KDL-46W40xx TT26 (Complete FHD WCG) KDL-46W42xx KDL-52W40xx TT61 KDL-52W42xx KDL-26E40xx TT21 KDL-26V45xx TT62 KDL-26V47xx A-1556-412-A KDL-32V45xx TT63 (Complete WXGA) KDL-32V47xx KDL-37V45xx TT64 KDL-37V47xx Sony Europe (Belgium) NV Customer Satisfaction Europe Quality & Service Engineering 1 / 4...
- Page 2 Take a Memory Stick of at least 16 MB (128 MB recommended). • Format the Memory Stick using a Memory Stick formatter. A special program can be downloaded from: http://support.sony-europe.com/memstick/downloads/downloads_ms.asp?l=en&f=MSFRM#disc. • Windows formatters are not supported. 3. Update of MS DL Digital, VCTP, NVM VCTP & Verd data 3-1.
- Page 3 08TV025R5 3 / 4 3-5. Switch on the TV using the [Power] key. 3-6. The “Digital Micro” will be updated. No download message appears. Only the green LED is ON. 3-7. When finished, the VCTP, NVM VCTP & Verd update will start. An “Update Start” message appears. If no “Update Start”...
- Page 4 4 / 4 08TV025R5 3-17. Check whether the update has been correctly performed. Use the remote commander to enter the Service mode. In standby, press the following key sequence: 3-18. The menu below will appear on the screen. Select [Product Version]. In the example below the PKG number is “103”.
