Tek Nek Toys International Rockin's Rider HORSE Manual

PARTS AND TOOLS LIST

1) Horse Body
5) Locking
Washers
1
(1)
(3)
Step 1:
Screw handles (3) into
horse's neck(1).
Step 2:
Align screws on the horse's
hooves (1) with the holes on
the base (2). You may have
to pull horses legs to align
with the holes on the base.
Secure, in this order, the flat
washers (4), locking washers
(5) and then acorn nuts (6)
to the bottom of the base.
Tighten with wrench and
check that all nuts, washers,
and handles are secure
before giving to child.
ROCKING HORSE MANUAL
2) Base
x1 x1
6) Acorn Nuts
x4 x4
2
In this order:
1 Flat Washers
2 Locking Washers
3 Acorn Nuts
(2)
(4)
(5)
3) Handles 4) Flat Washers
x2
Tools Required for
Assembly (not included)
(1)
1
x4
(6)
