HUROM CJ-B01BSS Instruction Manual

Terms of Parts
Handle
A
B Fruit Cover
C Squeezer Cone
Filter
D
E Juice Chamber
Juice Outlet
F
Body
G
Product Name Citrus Squeezer
Model Name CJ-B01BSS, CJ-B01BPP, CJ-B01BPB
Rated Voltage 120 V
Rated Frequency 60 Hz
Rated PowerConsumption 100 W
Rated Operating Hour Less than 15 seconds
Product Weight 2.41 kg
Product Size 240 x 190 x 467.5 mm
Instructions
Juicing
1. Prepare ingredients
Prepare citrus fruits (lemon, grapefruit, orange, etc.). Trim the stem/top of the fruit for easier extraction.
Cut the fruits in half and put it on the squeezer cone C .
2. Prepare juicer
Raise the juice outlet and place a cup in front of it.
F
Without the cup, the juice can be spilt.
3. Juicing
Press handle until the extraction is complete.
A
When the extraction is complete, lower the juice outlet .
F
Lift the back of the juice chamber so that the juice remaining in the juice chamber
E
Note: Always rinse the fruit before extraction. Choose fruits with soft and light colored skin. Avoid
fruits with hard and dried skin. For better protection of your purchase, fill out and mail this
form to a local distributor where you purchased the appliance and keep the original receipt.
Caution: Please be careful not to get your hands or fingers close to moving parts when juicing. If there
are a lot of dregs in filter , they can lower the extraction performance. Remove dregs from
D
the filter and extract. Pressing handle with excessive force may damage the product.
A
Cleaning
1. Disassembly
Once juicing is finished, raise handle and pull fruit cover by turning counter-clockwise.
A B
When the extraction is complete, raise handle and remove squeezer cone
A
filter , and juice chamber , in respective order.
D E
Assemble in reverse order of disassembly.
2. Cleaning parts
Wash parts in running water or with kitchen cleaner.
Wipe body with a damp towel or soft cloth.
G
Use baking soda and water to clean stains and dirt from the body .
G
Sterilize and clean parts by soaking in them in a diluted water mixture of baking soda, citric acid,
or vinegar for 30 minutes before first use.
Note: Do not wash at high temperatures of 80'C(176'F) or higher. Do not put the appliance in a
dishwasher, a dryer or a microwave etc. Do not use steel pot scrubbers, scouring pads,
abrasive material, sink solvents, or sharp cleaning tools.
Caution: Do not immerse or rinse body in water. Take cautions when cleaning squeezer cone
G
or filter because the edge may be sharp.
C D
www.hurom.com |
Copyright© All Rights Reserved by HUROM
can flow out.
E
,
C
Instruction Manual (Warranty Included)
01. Read the instructions carefully before using.
02. Keep these instructions somewhere easily accessible.
03. Use only with 120V AC power supply.
Made in China 04. Design and product development may be upgraded without notice.
05. Any quality improvements are subject to change without notice.
Instruction Manual
ENGLISH
