- Page 1 INSTRUCTIONS AND HINTS FOR THE USE, INSTALLATION AND MAINTENANCE OF GAS FUELLED BUILT-IN HOBS 220-240V~, 1-2W, 50Hz, Class I ELS-A-HG-SS60-02...
-
Page 2: Table Of Contents
TECHNICAL ASSISTANCE AND SPARE PARTS Before this appliance left the factory it was tested and set by specialized, expert personnel to guarantee the best functioning results. Authorised personnel must do any subsequent repairs or adjustments that may be necessary with the maximum care and attention. -
Page 3: Important Notes And Precautions For Use
1. IMPORTANT NOTES AND PRECAUTIONS FOR USE You have purchased one of our products for which we thank you We are confident that this new appliance, modern, functional and practical, made with top quality materials, will meet all your demands This new appliance is easy to use but before installing and using it, it is important to read this handbook through carefully. -
Page 4: Description Of The Appliance
2. DESCRIPTION OF THE APPLIANCE 1. SABAF Semi-Rapid gas burner (SR) 2. SABAF Rapid gas burner (R) 3. SABAF Wok Gas Burner 4. SABAF Auxiliary gas burner (Aux) 5. Gas burner control knob 6. Pan support for burners HB4801/HB4801B HB4802/HB4802B HB4803/HB4803B HB4804/HB4804B HB5801/HB5801B... -
Page 5: Instructions For The User: Use
1. SABAF-AE Wok gas burner (R) 2. SABAF-AE Rapid gas burner (R) 3. SABAF-AE Semi-Rapid gas burner (SR) 4. SABAF-AE Auxiliary gas burner (Aux) 5. Gas burner control knob HB5802A/HB5802A1 HB5802D/HB5802D1 HB5801A/HB5801A1 HB5801D/HB5801D1 Accessory Name Picture Quantity ( for reference only, physical unit maybe different) User Manual Installation clip Bracket... -
Page 6: Presentation
The burners are graduated in their size and rating to provide the exact heat required for every style of cooking. The burners can be equipped with safety thermocouples (Tc) for models HB4801 /HB4802 /HB4803 /HB4804 /HB5801 /HB5801A /HB5801D /HB5802A and HB5802D (see fig. 5). - Page 7 Automatic electrical ignition (only certain versions, see fig. 5, ref. AC) The command of lighting is integrated in the control knob. Press and turn counterclockwise the knob corresponding to the burner you wish to use, until it reaches to the “Full on” position (fig.1). Automatically the ignition spark shoots; keep the knob pressed until to happened lighting.
- Page 8 When a gas appliance is being used it produces heat and humidity in the room where it is installed. For this reason the room must be well ventilated, keeping the natural ventilation openings free (fig. 6) and switching on the mechanical aeration system (suction hood or electric fan, Figs. 7 and 8). If the cooker is used for a long time additional aeration may be necessary, for instance, opening a window, or a more effective aeration by increasing the power of the mechanical system if there is one.
- Page 9 4 burners 5 burners Circuit diagram Disposing of the device When disposing of the device, do not bring it to regular municipal waste containers. Instead, bring it to electrical and electronic waste recycling and reuse center. A relevant label has been put on the device, its instructions manual, or the package.
- Page 10 NOTE: This adjustment can only be performed by authorised service personnel. The minimum burner flame is factory adjusted for the gas type stated on the gas type label adjacent to the gas connection and should not require adjustment. Adjustment may be required if the hotplate has been converted from Natural gas to Universal LPG or vice versa.
-
Page 11: Instructions For The User: Cleaning And Maintenance
4. INSTRUCTIONS FOR THE USER: CLEANING AND MAINTENANCE Prior to any maintenance work or cleaning, disconnect the appliance from the electricity mains. The surface of the hob, pan supports, enamelled burner caps (C) and burner heads (T) (see fig. 5) need to be cleaned after each time they are used with warm soapy water, rinsed and then dried well to keep them in good condition. -
Page 12: Installation
connected in compliance with the above mentioned installation rules. Particular attention must be paid to the instructions given below for ventilation and aeration. This hotplate must be installed in accordance with: • AS 5601 - Gas Installations (for Australia) NZS 5261 – Code of Practice for the Installation of Gas Burning Appliances and Equipment (for New Zealand) Local gas fitting regulations AS/NZS 3000 –... - Page 13 HB4801/HB4802/HB4803/HB4804/HB5801/HB4801B/HB4802B/HB4803B/HB4804B/HB5801B HB5801A/HB5802A/HB5801D/HB5802D/HB5801A1/HB5802A1/HB5801D1/HB5802D1 Any adjoining wall surface situated within 200mm from the edge of any hob burner must be a suitable non- combustible material for a height of 150mm for the entire length of the hob. Any combustible construction above the hotplate must be at least 600mm above the top of the pan supports no construction shall be within 450mm above the top of the pan supports.
-
Page 14: Gas Connection
GAS CONNECTION Prior to connecting the appliance check that the data on the rating plate affixed to the bottom of the appliance, correspond to those of the gas mains. A duplicate Data Label is supplied to adhere in an accessible area next to the appliance. This appliance is suitable for Natural Gas and Universal LPG;... -
Page 15: Maintenance
hazardous overheating. • The appliance must be positioned so the plug is accessible. When connecting directly to the mains: Install a multipolar switch that can withstand the appliance load, with a minimum opening between the contacts of 3 mm. Remember that the earth wire must not be cut out by the switch. As an alternative, the electrical connection can also be protected with a high sensitivity RCD. -
Page 16: Technical Features
7. TECHNICAL FEATURES INJECTOR TABLE AND HEAT INPUT OF THE BURNERS (for the disposition of the hob burners, see on page 2) HB4801/HB4802/HB4803/HB4804/HB5801/HB4801B/HB4802B/HB4803B/HB4804B/HB5801B BURNERS TEST POINT PRESSURE DIAM. HEAT INPUT HEAT INPUT With Tc Without Tc INJECTOR MJ/h MJ/h N°... -
Page 17: Troubleshooting
8. TROUBLESHOOTING Servicing of the hotplates must only be done by an authorised service representative (see back of this booklet) and the hotplate must not be modified. Power must be disconnected before any servicing or maintenance is conducted. Abnormal conditions include: l...
