CaterSense -01
GAS SUPPLY CONTROL with
REMOTE CT MONITORING
INSTALLATION and COMMISSIONING
INSTRUCTIONS
CS-INST1-0.01
Model: CaterSense 01
Page 1
07-11

Advertisement

loading
Need help?

Need help?

Do you have a question about the CaterSense -01 and is the answer not in the manual?

Questions and answers

Summary of Contents for CaterSense CaterSense -01

  • Page 1 CaterSense the Intelligent answer CaterSense -01 GAS SUPPLY CONTROL with REMOTE CT MONITORING INSTALLATION and COMMISSIONING INSTRUCTIONS CS-INST1-0.01 Model: CaterSense 01 Page 1 07-11...
  • Page 2: Table Of Contents

    Intelligent answer Product Overview The CaterSense system is based on a range of products and ancillary equipment designed to meet the ever changing requirements of the catering industry and associated regulations. The system comes in four basic modes, you have selected...
  • Page 3 PCBs has been unplugged at the main PCB end. Place the screws, snap-in clips, side panels and facia plate in a safe place until the back box has been fixed, wired and is ready for reassembly and set-up. CS-INST1-0.01 Model: CaterSense 01 Page 3 07-11...
  • Page 4: Fixing Details

    41mm DETAIL OF SLOT KNOCK-OUTS 1.04 Electrical connections The CaterSense system has two sets of terminals all mounted along the top edge of the main PCB circuit board. Terminals 1 to 22 are the smaller terminals (1.5 mm² cable) and are used for the sensors, inter-locking devices, remote speed and on/off control.
  • Page 6 Intelligent answer 1.05 System mode and set-up The CaterSense unit is a number of intelligent control solutions in one controller. Each of the solution types has a “Mode Code” which is set via a DIL switch mounted on the main PCB circuit board.
  • Page 7: Set-Up And Commissioning

    Intelligent answer 2.0 Set-up and Commissioning The set-up and commissioning of your CaterSense system is in two parts, Initial and Mode. 2.01 Initial Set-up Once all of the wiring has been completed and tested and the system is ready to be set-up and commissioned, the following sequence MUST be followed to ensure the CaterSense and system operate correctly.
  • Page 8: Mode Set-Up

    If the fan is monitored via an external source, and the "fan healthy" signal is provided from a volt-free contact, ensure that the contact is closed. PRESS GAS VALVE All other LEDs The set-up is now complete and the system is ready to run. CS-INST1-0.01 Model: CaterSense 01 Page 8 07-11...
  • Page 9: Functional Operation

    CaterSense the Intelligent answer 2.03 Functional Operation The operation of the CaterSense unit and system in this Mode is as follows: PRESS GAS VALVE GAS VALVE OPENS START RESET / GPT All other LEDs OR CLOSE "ENABLE" CONTACT 1 min...
  • Page 10: Troubleshooting

    Ensure fan is working correctly. Check running current with an ammeter. Use the diagnosis mode to establish any problems with set-up. The system must be reset by pressing "STOP" before it can be restarted. CS-INST1-0.01 Model: CaterSense 01 Page 10 07-11...
  • Page 11 Cause:- The system has been manually stopped by pressing SYSTEM STOP Solution:- Reset the system by pressing SYSTEM STOP a second time. If the above does not solve your problem, contact Trent Products. CS-INST1-0.01 Model: CaterSense 01 Page 11 07-11...
  • Page 12 This product should be returned to your distributor or to a local recycling service. Respect the local environment rules. TRENT PRODUCTS Trent House Dewsbury Road Fenton Stoke-on-Trent Tel: 01782 844688 Fax: 01782 844772 CS-INST1-0.01 Model: CaterSense 01 Page 12 07-11...
