LED RGB Light Strip w/ Bluetooth Controller
a
(1 ea.) LED RGB Light Strip, 20'
b
(1 ea.) Bluetooth Controller
c
(1 ea.) Installation Components (Contents on Next Page)
Caution: Please read through the instructions carefully. Before starting this
project, remove the system's positive and negative connections from the
battery or battery pack. This kit is designed for a 12V operation only. Operating
this kit at a higher voltage will void any and all warranties. Look behind each
drill location BEFORE YOU DRILL. Installer is responsible for damage (i.e.
drilling into a wiring harness, battery, fuel tank etc.). Do no attempt to activate
or control this device in a hazardous driving situation.
LGT-030
12V DC
Installation Instructions
Contents of LGT-030 LED RGB Light Strip Kit
Advertisement
Table of Contents
Summary of Contents for RHOX LGT-030
- Page 1 LGT-030 LED RGB Light Strip w/ Bluetooth Controller 12V DC Installation Instructions Contents of LGT-030 LED RGB Light Strip Kit (1 ea.) LED RGB Light Strip, 20’ (1 ea.) Bluetooth Controller (1 ea.) Installation Components (Contents on Next Page) Caution: Please read through the instructions carefully. Before starting this project, remove the system’s positive and negative connections from the...
- Page 2 Installation Components Contents of LGT-030 Wiring Kit Qty. Sub-Harness with In-line Fuse Holder and 5 Amp Fuse Self-Stick Clips Tools and Supplies Needed for Installation - Wire Cutters, Strippers and Crimpers - Light Duty Clamps - 20 Gauge Wire and Wire Connectors...
- Page 3 Permanently install the LED strip on a clean mounting surface by peeling the paper backing off of the adhesive and pressing the LED strip against the mounting surface. Further secure the LED strip in place using the provided self-stick clips and/or wire ties (not included). NOTE: For easier installation, only peel back 8-10”...
- Page 4 Bluetooth Controller Operation Download the “Happy Lighting” App on a smart device by scanning the QR code on the controller or searching for it in the App Store. NOTE: Android users may have “Enable Unknown Sources” under App Settings/Security to see “Happy Lighting” in the App Store. Disable once downloaded.
