FRANCO BELGE COLIBRI Seriez User And Installer Instructions

FRANCO BELGE COLIBRI Seriez User And Installer Instructions

Output 14/21kw central heating hot water boiler
Hide thumbs

Advertisement

Quick Links

Download this manual
COLIBRI
Ref. 971.14.11.Z - Output 14kW
Ref. 971.21.11.Z - Output 21kW
Central heating hot water boiler
Natural draft vaporising pot burner.
CONTENTS
These instructions have been laid out as follows.
1-0
HEALTH AND SAFETY
2-0
APPLICABLE REGULATIONS
3-0
INTRODUCTION
3-0-1
MATERIALS REQUIRED
4-0
GENERAL INFORMATION
5-0
INSTALLATION AT A GLANCE
9-0
LIGHTING & COMMISSIONING
10-0
FAULT FINDING
User and Installer
Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the COLIBRI Seriez and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FRANCO BELGE COLIBRI Seriez

Summary of Contents for FRANCO BELGE COLIBRI Seriez

  • Page 1 COLIBRI Ref. 971.14.11.Z - Output 14kW Ref. 971.21.11.Z - Output 21kW Central heating hot water boiler Natural draft vaporising pot burner. User and Installer Instructions CONTENTS These instructions have been laid out as follows. HEALTH AND SAFETY APPLICABLE REGULATIONS INTRODUCTION 3-0-1 MATERIALS REQUIRED GENERAL INFORMATION...
  • Page 2 Reference 971.14.11Z 971.21.10Z Total Output (Max/Min) (kW) 4.5 to 14.1 6,5 to 21 Output to water (kW) 4 to 12.6 5.8 to 19 Output to space (cover closed) (kW) 0.4 to 1.5 0.7 to 2 Oil flow rates: Minimum (litres per hour) 0.45 0.66 Maximum (litres per hour)
  • Page 3 2-0 REGULATIONS The installation of an oil fired appliance must be carried out by a technically competent person, experienced in both solid fuel and oil fired installation and capable of installing, commissioning and servicing to the current requirements of the relevant local building regulations.
  • Page 4 COLIBRI REF. 971.14.11 Z - 971.21.11 Z 10. Silicone sealant. 11. Stadium air vent 12. Vermiculite loose fill 13. Cement. 14. Sharp sand. 15. Plugs and screws. 16. Switch fused neon isolator. (for time clock if fitted) 17 Suitable compression fittings. 4-0 GENERAL INFORMATION.
  • Page 5 COLIBRI REF. 971.14.11 Z - 971.21.11 Z 4-3 OIL FEED AND STORAGE REQUIREMENTS NOTE 28 Second Commercial Kerosene to B52869 Part 2: 1988 Class C2 is suitable for use with this appliance. 35 second versions are available. Installation of all oil feed pipework and storage equipment should be in line with -: B55410 Part 1 Steel oil storage tanks to B5799 Part 5, if there is any doubt consult the tank manufacturer.
  • Page 6 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Test for adequacy of air supply is to-: Set the oil fired appliance going, close all doors and windows in the room, turn on the extractor fan to its maximum capacity, light the open fire and let it get well established. Test for adequate maintenance of chimney vacuum on the appliance, both before and after the extractor fan is turned on, with the open fire going.
  • Page 7 COLIBRI REF. 971.14.11 Z - 971.21.11 Z If the appliance is fired up at full output it will run on full flame until it achieves the target water temperature, set by rotating the stat knob to the desired position, (clockwise to reduce temperature, anti clockwise to increase temperature) The flame then drops to its low fire position, from there on it will automatically modulate the flame from high to low in line with the heating load demand.
  • Page 8 COLIBRI REF. 971.14.11 Z - 971.21.11 Z l. PREPARE THE HEARTH Prepare the opening and or hearth . 4. DROP THE LINER DOWN THE CHIMNEY. 6A. FIT SUITABLE VENTILATION INTO THE APPLIANCE SITE SEE SEC 4-4. 7. RUN THE OIL SUPPLY. SEE SEC 4-3. Run the oil line and, remember that the KBB fire valve may well need in service replacement, an allowance must be made for this to be easily carried out, should the need arise.
  • Page 9 COLIBRI REF. 971.14.11 Z - 971.21.11 Z NOTE If during the lighting stage, excess oil is allowed to build up in the pot, the burner will race and generate quite loud audible vibrations, if this occurs don't panic, lift the oil cut off knob and wait a few minutes until the burner flame starts to reduce in size, at this stage depress the lever to restart the flow of oil so allowing the burner to run correctly at its low speed.
  • Page 10 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Flush at least 5 litres of oil through the line to check for contamination and to clear the oil line of installation debris and trapped air. Electrical- check for correct fusing, location and specification of any isolation devices. Ventilation - make sure that ventilation is provided in line with O.F.T.E.C requirements.
  • Page 11 COLIBRI REF. 971.14.11 Z - 971.21.11 Z 5. OIL WILL NOT ENTER THE POT 1. Check that the safety cut out lever has not been accidentally shut off. 2. If it is not possible to reset the safety cut out lever phone us for advice. In case of failure of the first float the second one catches the excess oil and trips the safety cut out lever, making it impossible to reset.
  • Page 12 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Fig. 3 – Schematic of flue gas flow Fig. 4 – 14kW Burner Fig. 5 – 21kW Burner...
  • Page 13 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Fig. 6 – Diagram for Parts List...
  • Page 14 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Fig. 8 – Fig. 9 - Fig.10 - C.C - S.S - V3V - V.E -...
  • Page 15 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Fig. 11 Fig. 12 Fig. 13 Fig. 14...
  • Page 16 COLIBRI REF. 971.14.11 Z - 971.21.11 Z Fig. 15 - Fig. 16 - Fig. 17 Fig. 19...
  • Page 17 COLIBRI REF. 971.14.11 Z - 971.21.11 Z...
