- Page 1 Sp. z o.o. solgaz.eu Assembly and instruction manual for GAS CERAMIC HOB to be built-in GNC - 4 WARNING! For your safety, please read the notes and suggestions presented further in this instruction manual.
- Page 2 The gas hob can be connected to the gas source only by an installer with qualifications to work with gas appliances. This device is not to be connected to exhaust pipes. The device should be installed and connected in accordance with applicable legal regulations.
-
Page 3: Table Of Contents
Thank you for your trust and purchase of the Solgaz automatic gas hob. Our technology is sure to inspire you to better cooking each day thanks to the hob's aesthetics, convenience and safety. Sincerely, SOLGAZ TABLE OF CONTENTS: GENERAL INFORMATION AND SAFETY INSTRUCTIONS ................4 1.1. -
Page 4: General Information And Safety Instructions
GENERAL INFORMATION AND SAFETY INSTRUCTIONS 1.1. Purpose of the device GNC type hobs are hobs for in-built installation, designed for preparation of dishes and use in households. The gas burners are equipped with temperature sensors, which assure maximum user safety and automatic, precise operations. -
Page 5: Hob Construction
1.3. Hob construction The ceramic plate (Fig. 1) features 4 special open gas burners, of which the 3 largest are equipped with temperature sensors. Burner operations are controlled electrically via a stepper motor. Built-in temperature sensors allow you to program a constant cooking temperature, boil water and protect the burner from working without a pot or pan. -
Page 6: Requirements For Hob Installation
Fig. 2 Side view (from the right) of the GNC hob 1 – thermal electrode (temperature sensor), 2 – cast iron grates for burners, 3 – burner caps, 4 – ignition electrode, 5 – burner body, 6 – burner ring, 7 – hub body REQUIREMENTS FOR HOB INSTALLATION All activities related to the assembly and connection of the hob to the gas and electrical distribution systems must be performed by a licensed installer qualified to... -
Page 7: Installation Of The Hob In A Kitchen Cabinet Countertop
distance of 750 mm. The hob is not adapted for connecting to exhaust gas pipes. It should be installed and connected in a manner compliant with current installation regulations. 2.2. Installation of the hob in a kitchen cabinet countertop The countertop, in which the gas hob is installed must be screwed in permanently to the cabinets or permanently connected with other furniture elements. -
Page 8: Gas System
Fig. 5 Installing the hob over an oven 1 – ventilation opening in the lower shelf; 2 – free space between the shelf and the back of the cabinet (air flow); 3 – ventilation opening under the countertop 2.3. Gas system The GNC –... -
Page 9: Electrical System
Please note: Laws in force in Poland prohibit the connection of gas appliances to LPG cylinders in buildings with a gas distribution system (Journal of Laws No. 75 Chapter 7). 2.4. Electrical system In order to ensure correct and safe use of the hob, an electrical power supply (230 V/50 Hz) needs to be run to the vicinity of the hob for connecting the power supply unit. -
Page 10: Maintenance And Inspections Of Hob Elements
point 1.2). It is also necessary to replace the hob's solenoid assembly and modify the controller software. This procedure can only be performed by an authorised service centre. 3.3. Maintenance and inspections of hob elements When operated in accordance with this instruction manual, and cleaned and maintained, a properly working hob does not require inspections. -
Page 11: Hob Control Panel
Hob control panel Fig. 6 Control panel – item 2. from Figure 1. 1 – switch indicator, 2 – lock indicator, 3 – hob on/off switch, 4 – hob panel lock, 5,6,7,8 – digital indicators of the set burner power, 9 –... -
Page 12: Residual Heat Indicator
This burner will not turn off, if there are no pots or pans, however, the other burners will. Please pay special attention to this. Descriptions for starting and using each of the available work modes are shown below: 4.4.1. Residual heat indicator When a burner is turned off, its elements and the grate remain hot. -
Page 13: Flame Size Stabilisation Function
will return to continuous operation in manual mode. A burner with the boiling programme activated cannot use the timer, booster and flame size stabilisation modes. You can use the stop'n go (pause) function, but this may disrupt the programme, as per the above. You can also use the control panel lock function. 4.4.4. -
Page 14: Timer Function
programme on a given burner or by touching the booster function sensor (item 17) for the selected burner. 4.4.6. Timer function The programme allows automatic shutdown of the hob. The working time can be set within a range from 1 to 99 minutes. The programmes work on every selected cooking zone and are independent of each other. -
Page 15: Turning The Controller Lock On And Off
4.4.8. Turning the controller lock on and off The controller lock protects the hob against accidental starting or a change in the power of the working burners. In order to prevent uncontrolled starts, switching off or changing the burner's power, use the controller lock, which is done as follows: Touch the sensor (key) with your finger item 4 Fig. -
Page 16: Regular Cleaning
Cleaning guide at www.solgaz.eu/czyszczenie 5.1. Regular cleaning. For cleaning ceramics, we recommend products shown at www.solgaz.eu/srodki- czystosci/ (however, it is forbidden to clean metal parts with such products, in particular the black aluminium strip, in which the exhaust grilles are located). These products remove all dirt from the ceramic plate, while being safe for it. -
Page 17: Procedure In Case Of Failures, Error Signals
Alarm states signalled by the hob controller inform the user about incorrect operation of the equipment. If the gas hob functions incorrectly, please stop using it and contact us between 8 am and 6 pm through our: Support Centre: serwis@solgaz.com.pl tel. 515 020 434 Customer service office: biuro@solgaz.com.pl tel. - Page 18 Manufacturer's declaration The manufacturer hereby declares that this product meets the essential requirements of the European directives listed below Directive 2006/95/EC Low voltage electrical equipment Directive 2004/108/EC Electromagnetic compatibility Directive 2009/142/EC on essential requirements for appliances burning gaseous fuels, and was marked with Connection certificate The gas ceramic hob has been properly connected to an active gas distribution system or gas...
-
Page 19: Warranty Card For The Gnc-4 Gas Ceramic Hob
WARRANTY CARD FOR THE GNC-4 GAS CERAMIC HOB factory No………………..date of manufacture......WARRANTY CONDITIONS In order to assure safe use and for this warranty to remain valid, the gas ceramic hob must be installed by an installer qualified for working on gas systems. Installation at the place of use is done at the user's expense. - Page 20 Contact details for the manufacturer's technical support are provided at the end of the warranty document and on the website of the warrantor www.solgaz.eu. After the warranty period, the manufacturer performs paid repairs, once the scope and costs of the repair are agreed with the interested party.
