  • Page 1 Bob’s Space Racers® Inc. © 2017 BSR-3000 427 15th Street, Daytona Beach, Florida 32117 Board Setup Phone - (386) 677-0761 Fax - (386) 677-0794 E-mail: tech@bobsspaceracers.com Table of Contents Setting up a Master Board. ……………………………. Page 2 Setting up a Unit Board ……………………………….. Page 4 Factory Reset …………………………………………..
  • Page 2: Press And Hold Enter (Figure

    AME POWER MUST BE ON TO PERFORM THIS OPERATION Please Note: Read all the instructions before performing any procedures. 1.1 Setting up a Master Board The only reason to setup a Master board is because the current Master board has a problem and the only board available is the Spare or Unit board.
  • Page 3: Figure

    The Master board now needs to have the default values of the options set. 1.1.11 Default Sample Option Sheet Figure 1.8 The option sheet sticker (Figure 1.8) is located on the Master’s plex cover. 1.1.12 Set the Default option’s values. Figure 1.8 illistrates that the default colomn is the third 1.1.13 colomn from the right.
  • Page 4 Figure 2.1 Take the Spare or newly purchased board (Figure 2.2) and install the board into the board 2.1.2 housing (Figure 2.3). Secure the BSR-3000 board with the 3/8-inch Nylon Hex Standoff (Figure 2.1.3 (Part No.: H0800029) 2.5) from the old board.
  • Page 5 AME POWER MUST BE ON TO PERFORM THIS OPERATION Please Note: Read all the instructions before performing any procedures. Plug in all the cables. See Figure 2.6. 2.1.4 Network Network Cables Cables Power Connector 1. Each connector is keyed. 2. Connections may vary per game. Figure 2.6 Go to the Master board and enter programming mode by mode pressing and holding the Select 2.1.5...
  • Page 6 Set the Spare Unit board’s ID according to the unit’s location. 2.1.8 Example: If you are replacing Unit #1 Unit Board change the Unit ID to 1, if you are replacing 2.1.9 Unit #2 Unit Board change the Unit ID to 2, and etc. Press the Right or Left button to change the Unit ID number.
  • Page 7: Factory Reset

    Take the Master or Unit board (Figure 3.1) and install the board into the board housing (Figure 3.1.1 3.2). Secure the BSR-3000 board with the 3/8-inch Nylon Hex Standoff (Figure 3.4) from the old board. 3.1.2 Figure 3.1 Figure 3.2...
  • Page 8: Table Of Contents

    Press and hold Enter (Figure 3.6). 3.1.4 Enter Figure 3.6 Plug in the power connector. See Figure 3.7. 3.1.5 Power Connector Figure 3.7 Continue holding Enter down through the screen turning Red and not flashing. The display will 3.1.6 show the program of the game. Example: WTR3K.V20 (Figure 3.8). Figure 3.8 When the display begins to flash Red and White with the program name WTR3K.V20 at the top 3.1.7...
