IMPORTANT: PLEASE READ BEFORE INSTALLATION
8/18/06
Creative Professional / E-MU USB 2.0 Audio/MIDI Interface
E-MU 0202 USB 2.0 / E-MU 0404 USB 2.0
Thank you for purchasing the E-MU 0202/0404 USB 2.0
Should you encounter any difficulty with the installation, please call E-MU Customer Support at:
North America: 405-743-0464
Europe (10:30-19:00 CET)
English: +353 1 433 3201
French: +353 1 433 3221
German: +353 1 438 0001
Japan: http://japan.creative.com/support/contact/
You should be aware of the following information before installing the E-MU USB Control Panel and
E-MU 0202/0404 USB 2.0 device drivers.
REGISTER YOUR E-MU PRODUCT
Register your product to enjoy benefits such as driver downloads, knowledge base FAQs and email/phone
support. Your serial number is located on the product. Take the time right now to copy this 18-digit number to
the inside cover of your "Getting Started Manual" for future reference.
There are 3 ways to register your product:
1. Start>Programs>Creative Professional>Product Registration
2. http://www.emu.com/register/
3. Call E-MU Technical Support

NOTES ON INSTALLATION

Please be sure to install the Software and Driver CD BEFORE you install the software from the Production
Tools CD. If these are installed in reverse order, the Production Tools CD may display errors with the DirectX
installation.
IF AT ANY TIME DURING THIS INSTALLATION YOU SEE NO RESPONSE: Use the Alt-Tab feature to select
other applications. One of them may be the Microsoft Digital Signature warning. It is possible for this warning
to appear behind the installation screen.
Make sure you have the latest Windows Service Packs from Microsoft (Windows XP - SP 2 or higher).
Disable onboard sound and uninstall all other sound cards. (If you wish to try using multiple sound cards in
your system, do so after you have confirmed that your E-MU 0202/0404 USB 2.0 is operating normally.)
IMPORTANT: PLEASE READ BEFORE INSTALLATION
PN: 02EM876106000
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E-MU 0202 USB 2.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Creative Professional E-MU 0202 USB 2.0

  • Page 1: Notes On Installation

    8/18/06 Creative Professional / E-MU USB 2.0 Audio/MIDI Interface E-MU 0202 USB 2.0 / E-MU 0404 USB 2.0 Thank you for purchasing the E-MU 0202/0404 USB 2.0 Should you encounter any difficulty with the installation, please call E-MU Customer Support at:...
  • Page 2: Note About Windows Logo Testing

    DO NOT USE AN UNPOWERED USB HUB WITH THE E-MU 0202 USB 2.0 If you plug your E-MU 0202 USB 2.0 into a USB hub, the hub must provide DC power for the 0202 USB 2.0 to properly function. NOTE ABOUT WINDOWS LOGO TESTING When you install the E-MU USB 2.0 Audio drivers, you will see a dialog box informing you that the driver has not...
  • Page 3 WINDOWS AUDIO DELAY PROBLEM Under rare circumstances, some audio applications may delay for several seconds before beginning to play audio. This hesitation is caused by a bug in Windows, and Microsoft has released a bug fix for it. This fix, which is known as “KB 918005,”...
  • Page 4: Anmerkungen Zur Installation

    WICHTIG! BITTE VOR DER INSTALLATION LESEN! 8/18/06 Creative Professional / E-MU USB 2.0 Audioschnittstelle Herzlichen Dank für den Kauf des E-MU 0202/0404 USB 2.0 Sollten bei der Installation Probleme auftreten, rufen Sie bitte den E-MU Customer Support unter folgender Nummer an:...
  • Page 5: Steinberg Wavelab Lite

    BENUTZEN SIE MIT DEM E-MU 0202 USB KEINEN USB HUB OHNE EIGENE SPANNUNGSVERSORGUNG. Wenn Sie Ihr E-MU 0202 USB 2.0 an einen USB Hub anschließen, muss dieser Gleichspannung liefern, damit das E-MU 0202 USB 2.0 korrekt funktioniert. HINWEIS ZUM WINDOWS LOGO TEST Während der Installation der E-MU USB 2.0-Treiber wird ein Dialogfeld angezeigt, in dem Sie darüber informiert...
  • Page 6 STEINBERG ASIO MULTIMEDIA BEI 96 KHZ UND 192 KHZ Bei Verwendung des Systems bei 96 kHz und 192 kHz empfehlen wir, den E-MU ASIO-Treiber nur mit ASIO- kompatiblen Programmen zu verwenden. WINDOWS-PROBLEM MIT AUDIO-VERZÖGERUNG Unter seltenen Umständen beginnt die Audio-Wiedergabe bei manchen Audio-Anwendungen erst nach einer Verzögerung von mehreren Sekunden.
  • Page 7: Remarques Sur L'installation

    à 18 chiffres sur la couverture intérieure de votre mode d'emploi, pour toute référence ultérieure. Vous pouvez enregistrer votre produit de 3 façons : 1. En sélectionnant le menu Démarrer>Tous les programmes>Creative Professional>Product Registration. 2. En visitant le site http://www.emu.com/register/ 3.
  • Page 8: Remarque Sur Le Logo De Test Windows

    à propos de ces applications sur le site Internet de leurs fabricants. Il se peut qu'il n'y ait pas d'assistance technique disponible dans certaines régions. Pour obtenir de plus amples renseignements consultez Menu Démarrer -> Programmes -> Creative Professional ->Nom du produit** Documents -> 3rd Party Support Info PROBLÈMES CONNUS...
  • Page 9 STEINBERG ASIO MULTIMEDIA À 96 KHZ ET 192 KHZ Lorsque vous travaillez à 96 kHz et à 192 kHz, il est recommandé de n'utiliser que le Driver E-MU ASIO avec les programmes compatibles ASIO. PROBLÈME DE RETARD AUDIO AVEC WINDOWS Dans certaines circonstances exceptionnelles, la lecture audio peut être retardée de plusieurs secondes dans vos applications.
  • Page 10: Notas Acerca De La Instalación

    IMPORTANTE: LEA ESTO ANTES DE LA INSTALACION 8/18/06 Creative Professional / USB 2.0 Interfaz Audio E-MU Felicidades y gracias por su compra del E-MU 0202/0404 USB 2.0. En caso de que observe cualquier tipo de problema durante la instalación, póngase en contacto con el departa- mento de atención al cliente de E-MU en estos números:...
  • Page 11 NO UTILICE NINGÚN HUB USB SIN CONEXIÓN A CORRIENTE CON EL E-MU 0202 USB 2.0 Si va a conectar su E-MU 0202 USB 2.0 a un hub USB, dicho hub deberá poder pasar corriente al 0202 USB 2.0 para que pueda funcionar correctamente.
  • Page 12 STEINBERG ASIO MULTIMEDIA A 96 KHZ Y 192 KHZ Cuando esté usando el programa a 96 kHz y 192 kHz, le recomendamos que utilice solo el driver E-MU ASIO en programas compatible con ASIO. PROBLEMA DE RETARDO AUDIO EN WINDOWS Bajo determinadas circunstancias muy concretas, algunos programas audio pueden producir un retardo de varios segundos antes de que comience la reproducción audio.
  • Page 13: Notas De Instalação

    IMPORTANTE: POR FAVOR, LEIA ANTES DA INSTALAÇÃO 8/18/06 Creative Professional / USB 2.0 Relação Audio E-MU Obrigado por adquirir o 0202/0404 USB 2.0 E-MU Caso você enfrente qualquer dificuldade com a instalação, por favor ligue para o suporte Técnico do E-MU: América do Norte: 405-743-0464...
  • Page 14 NÃO USE, COM O E-MU 0202 USB 2.0, UM HUB USB QUE NÃO SEJA ABASTECIDO COM ENERGIA Se você plugar seu E-MU 0202 USB 2.0 em um hub USB, o hub deve oferecer potência DC para o 0202 USB 2.0 para que se estabeleça um funcionamento adequado.
  • Page 15 STEINBERG ASIO MULTIMEDIA AT 96 KHZ AND 192 KHZ Quando operando em 96kHz e 192 kHz, recomendamos uso somente com o driver E-MU ASIO em programas de acordo com o padrão ASIO. PROBLEMA COM ATRASO DE ÁUDIO NO WINDOWS Sob raras circustâncias, algumas aplicações de áudio podem ter um atraso de alguns segundos antes de iniciar a execução de áudio.
  • Page 16 E-MU 0202/0404 USB 2.0 のインストールの前に : マザーボードに実装されているサウンド機能を無効に設定し、さ らに他のサウンドデバイスが装着されている場合、これらを全てアンインストールして下さい。これら他のサウンド 機能を使用したい場合、E-MU 0202/0404 USB 2.0 が正しく動作していることを確認してから、再度インストールし て下さい。 E-MU 0202 USB 2.0 では電源を持たない USB ハブは使用しないで下さい! E-MU 0202 USB 2.0 は USB バスパワーで駆動しますので、USB ハブに接続する場合、必ず適切な電源を持った USB ハブ を使用して下さい。USB バスパワー駆動の USB ハブに接続した場合、E-MU 0202 USB 2.0 が正しく動作しない恐れがあ ります。 重要 必ずインストールの前にお読み下さい!...
  • Page 17 Creative Technology Ltd. および E-MU Systems, Inc. では、同認定を受けていないデバイスドライバであっても、対応する OS において厳重なテストを行っており、その安全性を確認しております。従って警告が表示された場合でも、 [続行] ボタンをクリックしてそのままセットアップを続けていただいて何ら問題ありません。 PRODUCTION TOOLS BUNDLE CD-ROM に収録されたバンドルソフトウェアの テクニカルサポートについて ご購入いただいた Creative Professional E-MU 製品には、サードパーティ製ソフトウェアが付属していることがあります。 Creative ではこれらサードパーティ製ソフトウェアのサポートは行っておりません。何卒ご了承下さい。また各ソフト ウェアの開発会社では、これらのソフトウェアについての限定的な FAQ や E メールでのサポートなどを行っていますが、 お住まいの地域の代理店 / 販売店ではこれらのサポートを受けることはできません。 詳細については、Windows タスクバー上の[スタート]>[プログラム / 全てのプログラム]>[Creative Professional] >[< 製品名 >*Documents]>[3rd Party Support Information]の順にクリックして下さい。...
  • Page 18 WINDOWS によるオーディオの遅延問題 極限られた環境下において、オーディオソフトウェアでの再生時に数秒の遅れが発生する可能性があります。これは Windows のバグによるもので、Microsoft 社ではこのバグフィクスをリリースしています。この問題("KB 918005")を 解決するには、Microsoft 社のウェブサイト http://support.microsoft.com/kb/918005/ja を参照して下さい。 Microsoft 社のナレッジベースでは、この問題のタイトルは "Battery power may drain more quickly than you expect on a Windows XP SP2-based portable computer."(機械翻訳された上記の日本語ページでは "Windows XP SP2 ベースのポータ ブル コンピュータですばやく一掃できるのが必要だより、バッテリ電源は、すばやく一掃できます。")であり、オー ディオには関係していないように見えますが、実際にこのページからダウンロードできるアップデートで遅延問題は解決 します。 WINDOWS XP X64 環境下での STEINBERG WAVELAB LITE のインストーラ非互換性の問題 Windows XP x64 システムでは、WaveLab Lite のインストール時に非互換のエラーが表示されます。...
