- Page 1 MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual V1.0...
-
Page 2: Table Of Contents
Table of Content Ⅰ Description ..............................1 Ⅱ Features ................................1 Ⅲ MMIO EMB-HDSDI interface display .......................2 3.1 Overview ..............................2 3.2 Right panel..............................2 3.3 Left panel ..............................3 3.4 Front panel .............................4 Ⅳ Installation Guide ............................6 Ⅴ Technical specification..........................8 Ⅴ Contact ................................10... - Page 3 Gefei Tech. Co., Ltd. Gefei Tech. Co., Ltd assumes no responsibility or liability for any errors or inaccuracies that may appear in this publication. Revision Status Rev Date Description Dec. 10, 2013 Initial release of the MMIO EMB-HDSDI User Manual Firmware V1.0...
-
Page 4: Ⅰ Description
MMIO EMB-HDSDI Ⅰ Description MMIO EMB-HDSDI is a kind of embedder based on Mini-Box chassis. It can embed one analog audio stereo signal into a single serial digital signal, and output 1 serial digital signals with embedded audio. It supports SD-SDI, 1.5 Gbps HD-SDI and 3.0 Gbps HD-SDI for inputs and outputs. -
Page 5: Ⅲ Mmio Emb-Hdsdi Interface Display
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Ⅲ MMIO EMB-HDSDI interface display 3.1 Overview 3.2 Right panel LOOP SDI IN ： 12V 1A DC IN ： Power indicator, when the power works normally, the indicator shows green. -
Page 6: Left Panel
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual SD: 525i 60, 625i 50 HD: 720p 50Hz/59.94Hz/60Hz 1080i 50Hz/59.94Hz/60Hz 1080p 23.97Hz/24Hz/25Hz/29.97Hz/30Hz 1080p 50 Hz/59.94Hz/60 Hz ：BNC interface, support bypass SDI input with power on. SDI LOOP 3.3 Left panel... -
Page 7: Front Panel
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual 3.4 Front panel MODE SET: DIP switch, users can set DIP position to achieve more functions, the DIP specific meaning as following: DIP Switch Silence G1 CH1&CH2 G1 CH3&CH4 Select embedded G2 CH1&CH2... - Page 8 MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual G4 CH1&CH2 G4 CH3&CH4 Auto Note: Power switch UP=OFF DOWN=ON When the analog audio stereo are embedded to certain channels of SDI input, then other audio channels will have no audio any more. For instance, embed analog audio stereo to G1 CH1&2, so G1 CH3&4 and other audio groups have no audio.
-
Page 9: Ⅳ Installation Guide
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Ⅳ Installation Guide The unit is equipped with mini mounting bracket. And there are several screw holes on the bottom of unit for installing the mini bracket. Please see the pictures below. - Page 10 MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. 7 / 11...
-
Page 11: Ⅴ Technical Specification
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Ⅴ Technical specification Digital video input: Input interface: 1*HD/SD-SDI, BNC connection Impedance: 75Ω Format: SMPTE-259M-C；270Mb/s SMPTE-292M；1.485Gps SMPTE-425；2.970Gps Analog audio Input: Input interface: 2*3pin Impedance: 600Ω Digital video output: Output interface:... - Page 12 MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Rise time/Fall time: ≤270PS（20%-80%）(HD) 750~1500PS（20%-80%）(SD) Jitter: <0.2UI (100 kHz) Status indicator: Input signal status indicator Power indicator (Indicate by shining or extinguishing of the green LED) Power consumption: Power: 12VDC 1A...
-
Page 13: Ⅴ Contact
MMIO EMB-HDSDI 3G/HD/SD Signal & Analog Audio Embedder User manual Ⅴ Contact Technical support Tel: 010-58858188 Fax: 010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To find more information, please visit www.gefei-tech.com...
