Summary of Contents for Gefei MMIO ADA
- Page 1 MMIO ADA Audio Distribution User Manual V1.0 www. gefei-tech.com [Gefei Tech. Co., Ltd]...
-
Page 2: Table Of Contents
Table of Content 1. Description......................1 2. Features ........................1 3. Interfaces on the panel ..................2 3.1 Top View ......................2 3.2 Right panel ........................ 2 3.3 Left panel ........................3 4.Technical Specifications: ..................6 5. Contact Us ......................7... - Page 3 Copyright Copyright © 2013 Gefei Tech. Co., Ltd All rights reserved. This document may not be copied in whole or in part. Trademarks Gefei-Tech，Magi，MIO，VIO，XIO，MVS，MRS are either registered trademarks or trademarks of Gefei Tech. Co., Ltd in China and/or other countries. Other trademarks used in this document are either registered trademarks or trademarks of the manufacturers or vendors of the associated products.
-
Page 4: Description
MMIO ADA audio distribution 1. Description Based on Mini MIO BOX platform, MMIO ADA is a high-quality distribution which can distribute one analog audio to four analog audio outputs, the mini-size unit of 96.7x65x28 mm. The LED lights on the Mini box indicate the status of input signal and power supply, in order to let the user know the status immediately. -
Page 5: Interfaces On The Panel
MMIO ADA audio distribution User manual 3. Interfaces on the panel 3.1 Top View 3.2 Right panel Audio IN Audio OUT4 DC IN： 12V 1A. Power socket with fixing lock PWR：Power indicator, the indicator shows green when the power works normal. -
Page 6: Left Panel
MMIO ADA audio distribution User manual Audio IN: 3pin interface. analog audio input. Audio OUT4: 3pin interface. It’s one of four distribution outputs. 3.3 Left panel Audio OUT1 Audio OUT2 Audio OUT3 Audio OUT1-3: Three 3pin interfaces are distribution outputs . -
Page 7: Installation Guide
MMIO ADA audio distribution User manual 4. Installation Guide The unit is equipped with mini mounting bracket. And there are several screw holes on the bottom of unit for installing the mini bracket. Please see the pictures below. 24mm 61.5mm... - Page 8 MMIO ADA audio distribution User manual Fix the bracket horizontally like this: Use these two screw holes to fix bracket to case. Use screw hole to fix unit to rack or back of monitor. © Gefei Tech. Co., Ltd 5 / 6...
-
Page 9: Technical Specifications
MMIO ADA audio distribution User manual 5. Technical Specifications: Input Analog audio input: Input interface: 3pin connection (balanced) Impedance: Ω Frequency response: 20Hz-20Khz <±0.25dB Output Analog audio output: Output interface: 3pin connection (balanced or unbalanced) Impedance: 600Ω Frequency response: 20Hz-20 KHz <±0.25dB... -
Page 10: Contact Us
Technical support Tel:010-58858188 Fax:010-58858189 Website www.gefei-tech.com E-mail：swang@gefei-tech.com Address Beijing Gefei Tech. Co., Ltd A-603 Power Creative Plaza NO.1 Shangdi E.Rd. Haidian District Beijing 100085 To Find More information , please visit www.gefei-tech.com © Gefei Tech. Co., Ltd 7 / 6...
