TIME SERVER
OPTION CARDS
NETSILON
Installation guide
BODET SA
1 rue du Général de Gaulle
49340 Trementines, France
Tel. support France: 02.41.71.72.99
www.bodet-time.com
Fax France: 02.41.71.72.01
On receipt, ensure that the product has not been damaged during transportation and report any concerns to the carrier.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NETSILON and is the answer not in the manual?

Questions and answers

Related Manuals for Bodet NETSILON

Summary of Contents for Bodet NETSILON

  • Page 1 TIME SERVER OPTION CARDS NETSILON Installation guide BODET SA 1 rue du Général de Gaulle 49340 Trementines, France Tel. support France: 02.41.71.72.99 www.bodet-time.com Fax France: 02.41.71.72.01 On receipt, ensure that the product has not been damaged during transportation and report any concerns to the carrier.

  • Page 2: Table Of Contents

    GENERAL CONTENTS 1. GENERAL POINTS 1.1 Introduction 1.2 Recommendations list 2. INTRODUCTION 2.1 Checking the package 2.2 Saving the configuration 2.3 Safety 3. MECHANICAL INSTALLATION 4. ELECTRICAL CONNECTIONS 4.1 Option cards 5. QUICK CONFIGURATION 5.1 Access to the web server 5.2 Factory configuration 5.3 Loading the configuration 5.4 Option card detection 5.5 Removing an option card 6.

  • Page 3: General Points

    Switch off Netsilon then disconnect the power supply cable before removing the frame cover. Only install an option card when the power supply cable is disconnected. > > Fully return the product to its original state. There should be no surplus parts, and Netsilon should match its original appearance.

  • Page 4: Introduction

    2. INTRODUCTION This guide concerns the installation of one or more option cards. The operation and use of these option cards is presented in the full Netsilon guide (available from the website www. bodet-time.com). 2.1 Checking the package Carefully unpack and check the contents of the package. These should include: >...

  • Page 5: Mechanical Installation

    The installation method is identical regardless of the option card installed. One specific feature is to be noted for the Network option card (RJ45) and the network fiber option card (2 SFP) : connection to the Netsilon motherboard. To illustrate this particular case, the option card images are of a Network option card.
  • Page 6 Network option card (RJ45) and the Network Fiber option card (2 SFP). For other option cards, see point 7). 7) Close up the Netsilon device by refitting the black cover identically to its original condition. 8) Connect the power supply and turn the switch to ON (I).

  • Page 7: Electrical Connections

    1000 BaseLX LC-Duplex Fiber connector Wavelength = 1310 nm We recommend using BODET modules SX and LX. Other SFP MSA-compatible (Multi-Source Agreement) modules can be used but there is no guarantee that they will work (module RJ45 not compatible). >...
  • Page 8 The A and B outputs can be used to assign two separate time zones via the web server. > The power supply can be used to power a maximum of two Bodet DHF V1 transmitters. > A maximum of four AFNOR option cards may be installed.

  • Page 9: Quick Configuration

    , and the following window will appear for selection of the file to import: The file to be imported must have a “FileName.nets” extension 5.4 Option card detection To view the detection of an option card from the Netsilon web server, proceed as follows: 1) SYSTEM menu > Tools > Option cards:...

  • Page 10: Removing An Option Card

    5.5 Removing an option card If it is necessary to transfer or physically remove an option card from the Netsilon device, it is essential that it is also removed from the web server so as not to generate false alarms.
