- Page 1 CONSOLE SYSTEM JUAL Solar A/S JUAL WHEN THE SUN DOESN’T SHINE INSTALLATION GUIDELINE JUAL ROOF CONSOLE (Cold roof - Board Based Surface) Rev.2-2012 (Please be aware of the updates - www.jual.dk)
- Page 2 JUAL Solar A/S Installation Guideline Symbol description Manual handling Drill Driver with a Ø17 socket Torch Pay attention! Loosening operation Socket wrench with at 17 mm socket (anti clock wise rotation) Tightening operation Ø25 mm hole saw (clock wise rotation)
- Page 3 JUAL Solar A/S Installation Guideline JUAL Roof Console cold roof...
- Page 4 JUAL Solar A/S Installation Guideline Surface board drilling Pay attention! The Hole Saw must be capa- ble of sawing into the roofing membrane which may contain small pebbles. Ø 25 mm ← ←...
- Page 5 JUAL Solar A/S Installation Guideline Anchor / Adapter preassembly Ø 1-5 mm ← ←...
- Page 6 JUAL Solar A/S Installation Guideline Fixation of the Console with the Compression Ring Roof Console Tightening Pay Attention! The Connection Interface must be correctly aligned.
- Page 7 JUAL Solar A/S Installation Guideline Torching...
