Summary of Contents for TMB ProPlex IMS Universe Drive IP65
- Page 1 IMS Universe Drive IP65 Quick Start Guide TMB 24/7 Technical Support US/Canada: +1 818.794.1286 Toll Free: 1 877.862.3833 (877.TMB.DUDE) UK: +44 (0)20.8574.9739 Toll Free: 0800.652.5418 e-mail: techsupport@tmb.com...
- Page 2 Dimensions Overview...
- Page 3 Setup 1. Connect the 90-260V AC power to the power input Phoenix MSTB 2 terminal with Power IN markings next to it. 2. Connect the DMX signal input to the DMX input. 2.1. Use the Data Thru port to continue the IMS Universe Drive IP65 DMX data chain.
- Page 4 Connections...
-
Page 5: Lamp Control
WARM WHITE intensity 0% - 100% 000 ↔ 255 COLD WHITE intensity 0% - 100% The ProPlex IMS Universe Drive IP65 has two outputs. Up to 64 lamps may be connected to each output for a maximum of 128 lamps for each Universe Drive IP65. - Page 6 Cable Length / Lamp Spacing The following settings are recommended using IMS122CL3 cable. Settings may vary depending on cable type, IMS control data transfer rate, and other conditions. The settings below are examples of different scenarios and their tested results.
-
Page 7: Front Panel
Front Panel The POWER LED has two states: ON and OFF. • ON: Unit is receiving power. • OFF: Unit is not receiving power. The DMX INPUT LED has two states: OFF and BLINKING. • OFF: DMX input signal is not present. •... - Page 8 There are six available settings: 1) Short cables 2) Short cables with transcoding 3) Medium length cables 4) Medium length cables with transcoding 5) Long cables 6) Long cables with transcoding When the IMS Universe Drive IP65 is powered ON, the last active cable length setting will be used.
-
Page 9: Frequently Asked Questions
When the correct setting has been selected, wait a few seconds. The two side LEDs will stop blinking and the chosen setting is locked in. Note: 1) If one of the cable length setting LEDs is lit at full intensity and blinking, that means a setting with transcoding is selected. - Page 10 Please send returned merchandise prepaid and in the original packing. Freight call tags will not be issued for shipping the product to TMB, but TMB will pay the freight for return to the customer. Clearly label package with a Return Merchandise Authorization Number (RMA #).
- Page 11 1) Your name 2) Your address 3) Your phone number 4) The RMA # 5) A brief description of the symptoms ProPlex IMS Universe Drive IP65 Technical Specifications WEIGHT & DIMENSIONS ......................10.7 / 273 IDTH ......................
